Current Prismashield Current Prismashield Gear mounted directly to - PowerPoint PPT Presentation

Current Prismashield Current Prismashield Gear mounted directly to reflector/gear tray assembly, has to be removed to mount luminaire via 4 non captive screws. E t Extruded aluminium luminaire d d l i i l i i body with polycarbonate end caps.


  1. Current Prismashield Current Prismashield Gear mounted directly to reflector/gear tray assembly, has to be removed to mount luminaire via 4 non captive screws. E t Extruded aluminium luminaire d d l i i l i i body with polycarbonate end caps. (not suitable for certain metro applications) Cornice mount Gear tray visible through prismatic lens. Only 1 cable through wiring Polycarbonate prismatic lens capability only. (not suitable for certain metro applications, not mounted in ridged frame) Surface mount Only 1 cable entry No cable management Lens fixed via 6 captive point on rear p option/accessory option/accessory screws (3 each end)

  2. Rail & Metro Opportunities pp • Investment across Europe I E • Large end users & projects • Network Rail N t k R il • London Underground • Olympics 2012 Olympics 2012 • Crossrail text here

  3. Existing UK Customers g

  4. Typical Applications yp pp

  5. TM TM • T8/T5 fluorescent • Improved optical control • Glass lens option for metro application • Prismatic polycarbonate lens • Hinged door and reflector Hi d d d fl • IP65+ • Integrated DIN rail feature I t t d DIN il f t

  6. Features & Benefits � Two Lens Types “Prismatic polycarbonate and opaque glass lenses provide application flexibility with optical control”. CMS � Infill panels, cable management system, emergency gear and Accessory DALI Control option DALI Control option. Infill Infill Accessory “Provides the customer with a complete ‘Lighting Solution’” Luminaire � Versatile product ensuring simple and straight forward � Versatile product ensuring simple and straight forward installation. “Designed to be installer friendly “ � Hinging door and reflector assemblies allowing access to the lamp and gear. “Ease of Maintenance . Ensures product longevity.”

  7. Characteristics A ‐ Extruded aluminium body available in 3 different lengths – 600mm, 1200mm & 1500mm. B ‐ Pressure die casting LM6 aluminium end caps Robust and anti corrosive end caps. Robust and anti ‐ corrosive. A C ‐ Laminated opaque glass lens providing C Section 12 (London Underground) compliant luminaire. D D ‐ Clear Prismatic polycarbonate lens Clear Prismatic polycarbonate lens (internal prisms) provides even lens Illumination and vandal resistant option – IP659

  8. Characteristics Characteristics E ‐ Completley removable hinged door Assembly via 2 x security screws for both glass and poly versions allowing easy and glass and poly versions, allowing easy and safe access to lamp and gear for maintenance F ‐ Tooless hinged aluminium reflector F assembly that provides a symmetric or asymmetric lighting distribution. IP rating is achieved with a one piece gasket G ‐ providing a constant seal against optical lens. H ‐ Single or twin T5 and T8 lamps options. LED option to follow. Note – Image shows PSE mounted to Cable Management System and with Infill.

  9. Characteristics I ‐ Integrated DIN ‐ rail onto back extrusion allows termination anywhere along body length to suit installer flexibility. J ‐ Gear mounted directly to extrusion to allow dissaption of heat away from the gear set. K ‐ Hinged lamp and reflector assembly allows tooless access to gear and DIN ‐ rail during installation and maintenance. g (no need to remove lamps) L ‐ Tooless spring latch allowing access to gear M ‐ Only 2 x captive screws securely fix door l l f due to ridged extruded aluminium sides and cast aluminium ends. Note – Image shows PSE mounted to Cable Management System and with Infill.

  10. Characteristics N ‐ Extruded aluminium infill panel Accessories/ allows mounting end to end in continuous runs for through g wiring without compromising luminaire IP. O ‐ Twin Ø20mm knock outs in each end to ensure simple through wiring and loop in/loop out. P ‐ Infill panel accessories can be cut to length onsite and clipped into place allowing ease of installation. Retaining strap supplied for infill panel to Q ‐ Q ensure safety when maintained or in failure mode.

  11. Characteristics R ‐ Luminaire and infill panel accessory can be mounted directly to cable management system (S). S ‐ Extruded aluminium Cable Management System accessory extrusion in 3m lengths. Three isolated channels for power, communication, emergency and controls cables to be channelled separately & neatly. T ‐ Moveable cable retention clips ensure cables are not dangling or trapped during Installation process Installation process. U ‐ Infill/CMS mitre joint accessory allowing variable 0 ‐ 90 O mounting on site and strong accurate joint. V ‐ Infill and Cable Management System end plate accessories available to finish end of run neatly.

  12. Ease of Installation � CMS & Infill Panel Accessories ‘Cable Management System’ and ‘Infill Panels’ supplied in lengths that can be g y f pp g Cut to size on site to aid installer flexibility. � Hinged Door Assembly � Hinged Door Assembly Complete hinged door assembly allows safe access to reflector assembly. Door assembly can be replaced easily if required via two screws . � Hinged Reflector Assembly Complete toolless hinged reflector assembly allows access to gear compartment compartment .

  13. Optics p � Two Distributions Symmetric and Asymmetric Options Available y y p � T5 and T8 Lamps Available Single and Twin options for both lamp types. LED version to follow. Single and Twin options for both lamp types. LED version to follow.

  14. Marketing Support g pp Metro + Rail Application brochure being developed with being developed with relevant case studies. Available May 2010 Dedicated Prismashield Elite Brochure Elite Brochure. Available now.

  15. Sales Samples p Luminaire recessed into case. 2 x Sample demo cases available with luminaire and segment of Cable Management System. One in Northern region and one in the Southern region. 2 x Sample demo cases will also be available for the International Sales Teams. 1 x Sample case will be held at HQ with the complete luminaire with Cable management and Infill. Cut out segment to Section of Cable Management remove product easily. System included. y

  16. Website Downloadable PDF Installation sheets Gallery of product shots Animated video illustrating key features. Key features & benefits

  17. Marketing Support g pp
