Convolutional Neural Networks 08, 10 & 17 Nov, 2016 J. Ezequiel Soto S. Image Processing 2016 Prof. Luiz Velho Convolutional Neural Networks 1

Summary & References 08/11 ImageNet Classification with Deep Convolutional Neural Networks 2012, Krizhevsky et. al. [source] 10/11 Going Deeper with Convolutions 2015, Szegedy et. al. [source] 17/11 Painting Style Transfer for Head Portraits using Convolutional Neural Networks 2016, Selim & Elgharib [source] + CS231n: Convolutional Neural Networks for Visual Recognition Sanford University Course Notes + Very Deep Convolutional Networks for Large-Scale Image Recognition 2015, Simonyan & Zizzerman [source] Convolutional Neural Networks 2

ImageNet Classification with Deep Convolutional Neural Networks Krizhevsky et.al. 2012 Convolutional Neural Networks 3

Outline ● Motivation ● Data ● Architecture – ReLU Nonlinearity – Parallel GPU training – Local Response Normalization – Overlapping Pooling ● Reducing Overfitting – Data augmentation – Dropout ● Learning details ● Results ● Discussion Convolutional Neural Networks 4

Motivation ● Object recognition → Machine Learning Methods ● Improved performance: – Larger datasets – Powerful learning methods – Better techniques vs. overfitting ● MNIST digit recognition [e<0.3% ~ human] ● Evolution of labeled large image datasets: – NORB, CIFAR – LabelMe: ~100k segmented & labeled images – ImageNet: >15M labeled hi-res images in 22k categories ● Still not enough to specify such a complex problem: we need prior knowledge... Convolutional Neural Networks 5

Motivation ● Models with large learning capacity → Convolutional Neural Networks. ● CNN assumptions (strong & correct): – Stationarity of statistics – Locality of pixel dependencies ● CNNs pros: – Variable capacity (depth and breadth) – Fewer connections and parameters than usual, but still a lot... – Easier to train ● CNNs cons: – Prohibitively expensive to apply in large scale to high-resolution images ● Applicability → GPU with optimized 2D convolutions → Large enough datasets like ImageNet for training without overfitting Convolutional Neural Networks 6

Motivation ● It was one of the largest CNN trained with the ImageNet dataset for the ILSVRC Challenges, and the results set a new state of the art for the task. ● Highly optimized GPU implementation of 2D convolutions publicly available code. ● Reduction of training time and strategies to control overfitting. ● Specific architecture: 5 Conv + 3 FC layers. ● Network limits established by existing hardware. Convolutional Neural Networks 7

ImageNet Large-Scale Visual Recognition Challenge (ILSVRC) ILSVRC Challenges 2010 Classification with 1000 categories Classification 2011 Classification + localization Classification Classification + localization 2012 Fine-grained classification (100+ categories dogs) * WINNER: Krizhevsky et.al. 2012 PASCAL-style detection on fully labeled data for 200 categories 2013 Classification with 1000 categories Classification + localization with 1000 categories PASCAL-style detection on fully labeled data for 200 categories Classification + localization with 1000 categories 2014 * WINNERs: GoogLeNet, Szegedy et.al. 2015 VGG, Simonyan & Zisserman, 2015 Object detection for 200 fully labeled categories Object localization for 1000 categories 2015 Object detection from video for 30 fully labeled categories Scene classification for 401 categories Object localization for 1000 categories Object detection for 200 fully labeled categories 2016 Object detection from video for 30 fully labeled categories Scene classification for 365 scene categories Scene parsing for 150 stuff and discrete object categories Source: http://image-net.org/challenges/LSVRC/ Convolutional Neural Networks 8

Data ● ImageNet: >15M labeled hi-res images in ~22k categories. ● ILSVRC uses a subset of about 1.2M in 1000 categories. ● Used labels of the 2010 set for training. ● Error reporting: top-1 and top-5. ● Variable resolution images → down-sampled to fit 256 x 256. ● Centered raw RGB values of the pixels. Convolutional Neural Networks 9

Architecture ● 8 learned layers: – 5 convolutional (Conv) – 3 fully connected (FC) → → → → → Conv1 Conv2 Conv3 Conv4 Conv5 FC1 FC2 FC3 Convolutional Neural Networks 10

ReLU Nonlinearity ● Non-saturating activation function: max(0,x) ● Neurons: Rectified Linear Units (ReLU) ● Faster training → Figure: test on a 4-deep max ( 0, x ) tanh ( x ) CNN on CIFAR-10, no regularization, different optimal learning rates. ● Is this the best? PreLu, ELU? Open debate... Convolutional Neural Networks 11

Parallel GPU training ● GTX 580 GPU (3GB) limits training capability ● 1.2M images for training ● CNN: Spread across 2 GPU units ● Communication only in certain layers: 3 → 4 and FC – Easy with modern GPUs: common access to memory ● Communication reduces error with respect to completely independent columns by 1.7% (top-1) and 1.2% (top-5) GPU 1 GPU 2 Convolutional Neural Networks 12

Local Response Normalization ● ReLUs don’t require input normalization ● Local normalization → generalization ● Average over neighboring kernels at the same spatial position (x,y) ● Lateral inhibition inspired in real neurons (biology) ● “Brightness normalization” ● Reduces error in 1.4% (top-1) and 1.2% (top-5) ● Parameters obtained trough a validation set… k=2, n=5, α =10 -4 , β =0.75 Convolutional Neural Networks 13

Overlapping Pooling ● Pooling summarizes the output of neighboring groups of neurons in the same kernel ● Grid: spaced by s units of z × z averaging units ● Common pooling in CNNs: s = z ● Overlapping pooling: s < z ● This implementation has s = 2, z = 3 ● Reduction of error by 0.4% (top-1) and 0.3% (top-5) ● Observed result during training: overfitting is more difficult to occur Convolutional Neural Networks 14

LRN Pooling Convolutional Neural Networks 15

Architecture Model: Maximize the multinomial logistic regression objective Maximize the average across training cases of the log-probability of the correct label under the prediction distribution ~60 million parameters → → → → → Conv1 Conv2 Conv3 Conv4 Conv5 FC1 FC2 FC3 96 Ker 256 Ker 384 Ker 384 Ker 256 Ker 4096 neurons 11 × 11 × 3(s4) 5 × 5 × 48 3 × 3 × 256 3 × 3 × 192 3 × 3 × 192 each LRN LRN dropout Convolutional Neural Networks 16

Fitting filters and neurons W: input volume size F: receptive field size (filter / kernel) S: stride P: zero padding Neurons = (W – F + 2P)/S + 1 In this CNN: (224 – 11 + 0)/4 + 1 = 52.25 !!! → (224 – 11 + 3)/4 + 1 = 54 OK ● CS231n: claims error in the paper or unreported zero-padding Convolutional Neural Networks 17

Reducing Overfitting ● 60 M parameters / 1.2 M training images for 1000 classes impose 10 bits of constraints in the mapping from image to label → Not enough to prevent overfitting ● Data augmentation = artificially enlarge training set with label preserving transformations – Image translation and horizontal reflection Training over random 224 × 224 patches and its reflections → 2048x training set size → Test with four corners and central patch 10x test chance – Changes in the intensity and color of illumination: Alter color intensities with PCA of of the 3×3 covariance color matrix I ’xy = [I Rxy , I Gxy , I Bxy ] + [p1, p2, p3][ α 1 λ 1 , α 2 λ 2 , α 3 λ 3 ] T Each α i is a random Gaussian computed each training use of the image Convolutional Neural Networks 18

Reducing Overfitting Convolutional Neural Networks 19

Reducing Overfitting ● Dropout: Zero the output of each neuron during training with a probability of 0.5 (turn off: during forward feed and back-propagation) – Combine the predictions of many models is effective but it is too expensive – Similar results strategy that costs about 2x the time of training – Reduce co-adaptation of neighboring neurons – Forced to learn more robust features – Test time: multiply all outputs by 0.5! – Dropout inhibits substantial overfitting – Doubles time of convergence Convolutional Neural Networks 20

Learning details ● Stochastic gradient descent (L: loss function) – Batch (D i ) size: 128 images – Momentum: 0.9 – Weight decay: 0.0005 – Learning rate: ϵ ● Initialization: – Weights ~ N(0,0.01) – Biases = 1 for Conv2, Conv4, Conv5, all FC; = 0 everywhere else → accelerated initial learning with non-zero ReLU – Learning rate 0.01 and divide by 10 when validation error rate stops improving (3 times until termination) ● Training: 90 cycles trough all 1.2 M images (6 days / 2 NVIDIA GTX 580) Convolutional Neural Networks 21

Results ● ILSVRC 2010 ● ILSVRC 2012 (*Pre-training Conv6: ImageNet 2011 Fall, 15M images in 22k categories) Convolutional Neural Networks 22

Results ● Data connected learned kernels Conv1: – Frequency / orientation selective filters – GPU specialization (independent of initialization) Convolutional Neural Networks 23

Results Euclidean distance groups by Examples of classified 4096-dimensional feature images: even with not vectors of last hidden layer centered objects (not equal to L2 on pixels) → Generate auto-encoders? Convolutional Neural Networks 24
