Computer Programming II Algorithm Analysis and Sorting Techniques

Algorithm A sequence of well-defined instructions, which with a finite number of steps solves a problem or calculation. Components ● Sequence: a succession of instructions ● Selection: if , switch (not in Python) ● Iteration: Count ( for) or condition ( while) loops ● Abstraction: functions This week you have been working on constructing algorithms using recursion

Algorithm: Sorting There are many algorithms that can solve the same problem A common problem to solve in CS is sorting of lists and there are many different ways to go about it ● Selection sort ● Shell sort ● Heap sort ● Quick sort ● … Some more efficient (and effective) than others

Sorting: The ineffective way def bogo_sort(a_list): while (is_sorted(a_list)== False): shuffle(a_list)

Bogosort: Visualisation https://youtu.be/aSH-7EICngo

Sorting: The inefficient way def bubble_sort(a_list): n = len(a_list) for i in range(n - 1): for j in range(0, n - i - 1): if a_list[j] > a_list[j + 1]: a_list[j], a_list[j + 1] = a_list[j + 1], a_list[j]

Bubble Sort: Visualisation https://youtu.be/R-WHcRdxaEk

Sorting Your first assignment contains two common sorting solutions ● Insertion sort ● Merge sort These can also be algorithmically implemented in different ways since they are ideas of how to solve a particular problem

Sorting: Insertion - The Idea 1. Iterate from a_list[1] to a_list[n] 2. Compare the current element (key) to its predecessor. 3. If the key element is smaller than its predecessor, compare it to the elements before. Move the greater elements one position up to make space for the swapped element.

Insertion Sort: Iterative def insertion_sort(a_list): length = len(a_list) for i in range(1, length): value = a_list[i] while a_list[i - 1] > value and i > 0: a_list[i], a_list[i - 1] = a_list[i - 1], a_list[i] i -= 1

Insertion Sort: Recursive def insertion_sort_rec(a_list, n): if n <= 1: return insertion_sort_rec(a_list, n - 1) last = a_list[n - 1] i = n - 2 while i >= 0 and a_list[i] > last: a_list[i + 1] = a_list[i] i = i - 1 a_list[i + 1] = last

Insertion Sort: Visualisation https://youtu.be/sl1PeLOzxQI

Sorting: Merge - The Idea 1. Find the middle point to divide the array into two halves 2. Do a recursive call for the first half 3. Do a recursive call for the second half 4. Merge the two halves sorted in step 2 and 3

Merge Sort: Visualisation https://youtu.be/fuCYYoRejc0

Time Complexity of Algorithms Visually, we can see how differently these algorithms work How do we choose which approach to use for a particular problem? We can of course analyse them by running them a large number of times, take the average time and compare them

Time Complexity of Algorithms However, the time might vary a lot depending on ● CPU power ● RAM efficiency ● Programming language ● Amount of data to manipulate ● The structure of the input data ● Type of input to the algorithm

Time Complexity of Algorithms So how do we compare if there are so many variables? We get an approximation of their efficiency by considering the change in performance as the number of operations increases as a function of the number of elements we provide the algorithm That is, how does the algorithm perform with a larger input size compared to a smaller input size, given that everything else is constant? Studying the time complexity of an algorithm is defined as asymptotic analysis

Linear Search Algorithm def search(x, a_list): for i in a_list: if i == x: return True return False

Asymptotic Analysis: Cases for linear search l = [7, 2, 4, 1, 5, 3, 9] search(7, l) The search ends immediately: Best case scenario l = [7, 2, 4, 1, 5, 3, 9] search(9, l) The search has to iteration through all indices: Worst case scenario l = [7, 2, 4, 1, 5, 3, 9] search(6, l) The search has to iteration through all indices: Worst case scenario

Asymptotic Notation O Ordo or Big O (upper bound) Signifies the worst case scenario Ω Omega (lower bound) Signifies the best case scenario Θ Theta (upper and lower bound) Signifies the average case

Asymptotic Notation O(1) Constant time O( n ) Linear time O( n 2 ) Quadratic time

Operations Elements

Asymptotic Analysis: Cases for linear search l = [7, 2, 4, 1, 5, 3, 9] search(7, l) The search ends immediately: Ω(1) l = [7, 2, 4, 1, 5, 3, 9] search(9, l) The search has to iteration through all indices: O(n) l = [7, 2, 4, 1, 5, 3, 9] search(6, l) The search has to iteration through all indices: O(n) Average: Θ(n)

Bubble Sort Algorithm def bubble_sort(a_list): n = len(a_list) for i in range(n - 1): for j in range(0, n - i - 1): if a_list[j] > a_list[j + 1]: a_list[j], a_list[j + 1] = a_list[j + 1], a_list[j]

Asymptotic Analysis: Cases for bubble sort In bubble sort, when the input array is already sorted, the time taken by the algorithm is linear i.e. the best case: Ω( n ) But, when the input array is in reverse condition, the algorithm takes the maximum time (quadratic) to sort the elements i.e. the worst case: O( n 2 ) When the input array is neither sorted nor in reverse order, then it takes average time: Θ( n 2 )

Time Complexity: Sorting Algorithms Algorithm Time Complexity Best Average Worst Ω( n 2 ) θ( n 2 ) O( n 2 ) Selection Sort θ( n 2 ) O( n 2 ) Bubble Sort Ω( n ) θ( n 2 ) O( n 2 ) Insertion Sort Ω( n ) Heap Sort Ω( n log n ) θ( n log n ) O( n log n ) O( n 2 ) Quick Sort Ω( n log n ) θ( n log n ) Merge Sort Ω( n log n ) θ( n log n ) O( n log n )

Time Complexity Will two algorithms with a time complexity of O( n 2 ) always perform the same? When would you use a more inefficient algorithm over an efficient one? Is asymptotic analysis really necessary when CPUs are so fast as they are today?

Time Complexity Will two algorithms with a time complexity of O( n 2 ) always perform the same? No, the notation only expresses how the particular algorithm performs given an increase in its input

Time Complexity Will two algorithms with a time complexity of O( n 2 ) always perform the same? No, the notation only expresses how the particular algorithm performs given an increase in its input When would you use a more inefficient algorithm over an efficient one? When the gain in efficiency is no worth the extra complexity

Time Complexity More important to run a program correctly than fast Make no sacrifices for minimal gains in efficiency ● Do not sacrifice clarity ● Do not sacrifice simplicity ● Do not sacrifice modifiability If your code runs slow: Find a better algorithm!

Time Complexity Will two algorithms with a time complexity of O( n 2 ) always perform the same? No, the notation only expresses how the particular algorithm performs given an increase in its input When would you use a more inefficient algorithm over an efficient one? When the gain in efficiency is no worth the extra complexity Is asymptotic analysis really necessary when computer are so fast as they are today?

Time Complexity With increased computational power, we tend to compute even more data For example ● Physics: aerodynamics, weather forecasting ● Biology: bioinformatics, genome sequencing ● Real-time systems: robots, self-driving cars, cellular base stations ● Animation: computer games, film CGI ● Image stabilisation of moving pictures ● Information: search engines

Extra For those of you interested more in how to analyse time complexity, I recommend this video explaining how to analyse your code: https://www.youtube.com/watch?v=D6xkbGLQesk&list=PLBZBJbE_rGRV8D7XZ0 8LK6z-4zPoWzu5H&index=7 I’ve also included a few more slides showing visualisations of sorting algorithms here for those who enjoy watching them :)

Shell Sort: Visualisation https://youtu.be/NfQQGVN9fI4

Selection Sort: Visualisation https://youtu.be/EgWnJrpjpF4

Quick Sort: Visualisation https://youtu.be/tTt3F9PwTJ8

Heap Sort: Visualisation https://youtu.be/PlnoGtcmYXE
