Changepoint detection for time series prediction Allen B. Downey - PowerPoint PPT Presentation

Changepoint detection for time series prediction Allen B. Downey Olin College of Engineering 1 My background: Predoc at San Diego Supercomputer Center. Dissertation on workload modeling, queue time prediction and malleable job


  1. Changepoint detection for time series prediction Allen B. Downey Olin College of Engineering 1

  2. My background: � Predoc at San Diego Supercomputer Center. � Dissertation on workload modeling, queue time prediction and malleable job allocation for parallel machines. � Recent: Network measurement and modeling. � Current: History-based prediction. 2

  3. Connection? � Resource allocation based on prediction. � Prediction based on history. � Historical data characterized by changepoints (nonstationarity). 3

  4. Three ways to characterize variability: � Noise around a stationary level. � Noise around an underlying trend. � Abrupt changes in level: changepoints. Important difference: � Data prior to a changepoint is irrelevant to performance after. 4

  5. Example: wide area networks � Some trends (accumulating queue). � Many abrupt changepoints. • Beginning and end of transfers. • Routing changes. • Hardware failure, replacement. 5

  6. Example: parallel batch queues � Some trends (daily cycles). � Some abrupt changepoints. • Start/completion of wide jobs. • Queue policy changes. • Hardware failure, replacement. 6

  7. My claim: � Many systems are characterized by changepoints where data before a changepoint is irrelevant to performance after. � In these systems, good predictions depend on changepoint detection, because old data is wrong. Discussion? 7

  8. Two kinds of prediction: � Single value prediction. � Predictive distribution. • Summary stats. • Intervals. • P ( error > thresh ) • E [ cost ( error )] 8

  9. If you assume stationarity, life is good: � Accumulate data indefinitely. � Predictive distribution = observed distribution. But this is often not a good assumption. 9

  10. If the system is nonstationary: � Fixed window? Exponential decay? � Too far: obsolete data. � Not far enough: loss of useful info. 10

  11. If you know where the changepoints are: � Use data back to the latest changepoint. � Less information immediately after. 11

  12. If you don’t know, you have to guess. P ( i ) = prob of a changepoint at time i Example: � 150 data points. � P (50) = 0 . 7 � P (100) = 0 . 5 How do you generate a predictive distribution? 12

  13. Two steps: � Derive P ( i +) : prob that i is the latest changepoint. � Compute weighted mix going back to each i . Example: P (50) = 0 . 7 P (100) = 0 . 5 P ( ⊘ ) = 0 . 15 P (50+) = 0 . 35 P (100+) = 0 . 5 13

  14. Predictive distribution = 0 . 50 · ed f (100 , 150) ⊕ 0 . 35 · ed f (50 , 150) ⊕ 0 . 15 · ed f (0 , 150) 14

  15. So how do you generate the probabilities P ( i +) ? Three steps: � Bayes’ theorem. � Simple case: you know there is 1 changepoint. � General case: unknown # of changepoints. 15

  16. Bayes’ theorem (diachronic interpretation) P ( H | E ) = P ( E | H ) P ( E ) P ( H ) � H is a hypothesis, E is a body of evidence. � P ( H | E ) : posterior � P ( H ) : prior � P ( E | H ) is usually easy to compute. � P ( E ) is often not. 16

  17. Unless you have a suite of exclusive hypotheses. P ( H i | E ) = P ( E | H i ) P ( H i ) P ( E ) � P ( E ) = P ( E | H j ) P ( H j ) H j ∈ S In that case life is good. 17

  18. � If you know there there is exactly one changepoint in an interval... � ...then the P ( i ) are exclusive hypotheses, � and all you need is P ( E | i ) . Which is pretty much a solved problem. 18

  19. What if the # of changepoints is unknown? � P ( i ) are no longer exclusive. � But the P ( i +) are. � And you can write a system of equations for P ( i +) . 19

  20. � P ( i + ) = P ( i + |⊘ ) P ( ⊘ ) + P ( i + | j ++ ) P ( j ++ ) j<i � P ( j ++ ) is the prob that the second-to last changepoint is at i . � P ( i + | j ++ ) reduces to the simple problem. � P ( ⊘ ) is the prob that we have not seen two changepoints. � P ( i + |⊘ ) reduces to the simple problem (plus). Great, so what’s P ( j ++ ) ? 20

  21. � P ( j ++ ) = P ( j ++ | k + ) P ( k + ) k>j � P ( j ++ | k + ) is just P ( j + ) computed at time k . � So you can solve for P ( + ) in terms of P ( ++ ) . � And P ( ++ ) in terms of P ( + ) . � And at every iteration you have a pretty good estimate. � Paging Dr. Jacobi! 21

  22. Implementation: � Need to keep n 2 / 2 previous values. � And n 2 / 2 summary statistics. � And it takes n 2 work to do an update. � But, you only have to go back two changepoints, � ...so you can keep n small. 22

  23. 4 � Synthetic series data with two 2 changepoints. x[i] 0 � µ = − 0 . 5 , 0 . 5 , 0 . 0 -2 � σ = 1 . 0 -4 � P ( ⊘ ) = 0 . 04 1.0 P(i+) cumulative probability P(i++) 0.5 0.0 0 50 100 150 time 23

  24. 150 � The ubiquitous data annual flow (10^9 m^3) Nile dataset. 100 � Change in 1898. 50 � Estimated probs can be 0 1880 1900 1920 1940 1960 mercurial. 1.0 P33(i+) cumulative probability P66(i+) P99(i+) 0.5 0.0 1880 1900 1920 1940 1960 time 24

  25. 4 � Can also detect data change in 2 variance. 0 � µ = 1 , 0 , 0 -2 � σ = 1 , 1 , 0 . 5 -4 � Estimated P ( i + ) 1.0 cumulative probability P(i+) is good. P(i++) � Estimated 0.5 P ( i ++ ) less certain. 0.0 0 50 100 index 25

  26. � Qualitative behavior seems good. � Quantitative tests: • Compare to GLR for online alarm problem. • Test predictive distribution with synthetic data. • Test predictive distribution with real data. 26

  27. Changepoint problems: � Detection: online alarm problem. � Location: offline partitioning. � Tracking: online prediction. Proposed method does all three. Starting simple... 27

  28. Online alarm problem: � Observe process in real time. � µ 0 and σ known. � τ and µ 1 unknown. � Raise alarm ASAP after changepoint. � Minimize delay. � Minimize false alarm rate. 28

  29. GLR = generalized likelihood ratio. � Compute decision function g k . � E [ g k ] = 0 before the changepoint, � ... increases after. � Alarm when g k > h . � GLR is optimal when µ 1 is known. 29

  30. CPP = change point probability n � P ( i + ) P ( changepoint ) = i =0 � Alarm when P ( changepoint ) > thresh . 30

  31. � µ = 0 , 1 15 � σ = 1 GLR � τ ∼ Exp (0 . 01) CPP mean delay 10 � Goodness = lower mean delay for same false alarm rate. 5 0 0.0 0.1 0.2 false alarm probability 31

  32. � Fix false alarm 25 rate = 5% GLR (5% false alarm rate) � Vary σ . 20 CPP (5% false alarm rate) mean delay � CPP does well 15 with small S/N . 10 5 0 0.0 0.5 1.0 1.5 sigma 32

  33. So it works on a simple problem. Future work: � Other changepoint problems (location, tracking). � Other data distributions (lognormal). � Testing robustness (real data, trends). 33

  34. Related problem: � How much categorical data to use? � Example: predict queue time based on size, queue, etc. � Possible answer: narrowest category that yields two changepoints. 34

  35. Good news: � Very general framework. � Seems to work. � Many possible applications. 35

  36. Bad news: � Need to apply and test in real application. � n 2 space and time may limit scope. 36

  37. � More at allendowney.com/research/changepoint � Or email downey@allendowney.com 37
