Catalytic Peroxide Bleaching Kraft Pulp OH 2 Transition metal - PowerPoint PPT Presentation

Overview of Catalytic Peroxide Bleaching Kraft Pulp OH 2 Transition metal centered activators O O R N N Fe OH 2 N N R O O O Mo O O O OH 2 TAML O peroxomolybdate H N N N Cu II O N N O Mn Mn N N Cu-dpa N N O O


  1. Overview of Catalytic Peroxide Bleaching Kraft Pulp

  2. OH 2 Transition metal centered activators O O R N N Fe OH 2 N N R O O O Mo O O O OH 2 TAML O peroxomolybdate H N N N Cu II O N N O Mn Mn N N Cu-dpa N N O O ……. Bi-nuclear Mn complexe Fabian, Tappi J. 2008, 8 Argyropoulos, Tappi J. 2002, 1(2), 1 Rahmawati, Chem. Eng. J, 2005, 112, 167

  3. Transition metal centered activators Peroxomolybdate complexes Peroxometalates ox Pulp O 2 Bleached pulp Peroxometalates red [MoO(O 2 ) 2 (OH)(H 2 O)] - - Formation of peroxometalates under acidic conditions - Enhanced electrophilic character of peroxo oxygens Ball and stick model of diperoxomolybdate anions - Preferably act on aliphatic C-C double bond Op=peroxo oxygens, Ot= double bond oxygen, O1, O2=other oxygens (e.g. H 2 O, OH-) Fabian, Tappi J. 2008, 8

  4. Transition metal centered activators O O O Mo +H 2 O 2 Peroxomolybdate complexes O - O Lignin model compounds: O O isoeugenol (left), eugenol and creosol(right) O H 2 O 2 Mo O HO H 2 O H 2 O O O O O O O Mo O Fabian, Tappi J. 2008, 8 O O Mo HO H 2 O O HO H 2 O H. L. XIE et al., Chem. Biochem. Eng. Q. 2008, 22 (1) 25

  5. Formation of Hexenuronic Acid (HexA) O O O O HO HO n n OH - O O HO HO -CH 3 OH HO HO H 3 CO O O HOOC HOOC - HexA is generated from 4-O-methyl-D-glucuronic acid in xylan during alkaline pulping - HexA actively reacts with permanganate, thus affecting the kappa number determination - Contributes to higher demand for bleaching chemicals

  6. Delignification and HexA Removal T ( ℃ ) Stage Charge pH Time (h) Q 6% EDTA ~5 70 1 P 10%H 2 O 2 ~5.5 80 3 PMo 10%H 2 O 2, 300ppm Mo ~5.5 80 3 10%H 2 O 2, 300ppm Mo, PMoSi ~5.5 80 3 100ppm Silicate EP 10%H 2 O 2 , 10% NaOH ~11 70 2

  7. Vanadium peroxo complexes Oxygen transfer from peroxovanadium complexes to hydrocarbons from various possible active species Experimental Details - Pine kraft pulps (kappa=16.2) - Q stage: 1.6% consistency, 0.5% DTPA, 50 ℃ , 30min, pH~4.5 - P stage: 10% consistency, 0.2% DTPA, 0.05% MgSO 4 , varying charges of H 2 O 2 , NaOH, varying reaction time Suchy et al. Pulping Conference, 2008, 1277

  8. Vanadium peroxo complexes Optimum Conditions - Pine Kraft pulps - Activator charge: 0.5% - Temperature: 80 ℃ - Retention time: 2h - Peroxide and alkaline charge: 3% Improvements - Kappa number reduction: 16.2-6.3 (61%reduction) - ISO brightness: 5.7% rise

  9. H N H 2 O 2 -copper/pyridine systems N N Cu II Cu(II), Cu(II)-dpa Cu(II)-dpa Kappa Viscosity loss reduction Cu(II) 24.3% 7.6% Cu(II)/Q 28.0% 11.1% Cu(II)-dpa 26.2% 0.6% Cu(II)-dpa/Q 29.9% 1.1% - High selectivity for delignification by Cu(II)-dpa complexes Experimental Details - Oxygen-prebleached kraft pulp (OKP) - Cu stage: Cu/dpa ratio=1:1, 1% H 2 O 2 OKP-Oxygen delignified pine kraft pulp 5% csc, pH~10, 60 ℃ ,4h - Q stage: 0.5% EDTA, 5% csc, 80 ℃ Rahmawati, Chem. Eng. J, 2005, 112, 167

  10. H 2 O 2 -copper/pyridine systems  2+ - + 2Cu +H O +2OH 2Cu +O +2H O 2 2 2 2  + 2+ - Cu +H O Cu +OH + OH 2 2 - Fenton reaction: produce hydroxy radicals in the presence of free metal ions - Cu-dpa has altered the redox potential to prevent hydroxy radical production Production of hydroxyl radicals with Cu(II) and Cu(II)-dpa Rahmawati, Chem. Eng. J, 2005, 112, 167

  11. Nitrogen Centered Peroxide Activators: TAED O CH 3 O CH 3 O O H 2 O 2 NH N CH 3 + 2 OH HN H 3 C N pH 8-9 H 3 C O O O CH 3 O CH 3 DAED PAA TAED R. Patt, Tappi Pulping Conference Proceedings, 1998, 1, 111 TAED-Tetra acetic ethylenediamine - Colorless, odorless, nontoxic and nonmutagenic compound and was widely used since 1980s - Generate PAA or peracetate anion in-situ, which is more powerful oxidants than peroxide - Benefits can be achieved under milder bleaching conditions (e.g. lower alkalinity, low temperature)

  12. In-situ Generated Peracetc Acid (PAA) O O pKa~8.25 C O OH H 3 C O - C O H 3 C   + - Nucleophilic Electrophilic Nucleophilic site site site pH<8.25 pH>8.25 Neil et al, TAPPI International Pulp Bleaching Conference, 2002 - TAED works best at pH 10~10.5, but still effective at pH~8 - Disproportionation of PAA at medium alkalinity  - - AcOO +AcOOH AcOH+AcO +O 2 - Improve pulp properties by reducing fibre degradation caused by longer, less efficient bleaching

  13. Effectiveness of TAED on different pulps With TAED treatment - pH, TAED charge influence the optical and physical properties of each pulp type - Both H 2 O 2 and PAA produce quinones(methoxy- hydroquinone) and vanillin derivatives (e.g. homovanillic acid, veratric acid) - Increase in bulk and improvement of color reversion, with a possible brightness tradeoff (9% loss~8% increase) Jeffery, TAPPI J. 2006, 5(9), 27

  14. TAED oxidation kinetics Reaction of acetovanillone with peroxide Conditions - C(acetovanillone)=0.12mmol/L C(H 2 O 2 )=12mmol/L - Peroxide system pH~11.0-11.5, 60 ℃ - TAED assisted system pH~7.9-8.3, 60 ℃ , TAED/H 2 O 2 =0.5 lnC=-kt+lnC 0 - TAED assisted system (rate constant k=0.34min-1) proceeds 100 times faster than that without TAED (k=0.0035min-1) Hu et al. J. Wood. Chem. Tech, 2006, 26, 165

  15. pH dependence of TAED/H 2 O 2 systems - A higher pH (~10.8) is desired to increase production of peroxyacetic acid at the beginning of the reaction - A much lower pH (~8) is required to minimize decomposition of the peroxyacetic acid and improve its bleaching efficiency at the second phase - Optimium pH ~8.3 Hu et al. J. Wood. Chem. Tech, 2006, 26, 165

  16. DMD Activated peroxide bleaching OH H O R R 1 O + H C O C O R O SO 3 R O SO 3 2 O 3 SOO O slow R O R 3 Lignin Oxidized lignin O C C -SO 42- R O R O SO 3 D. S. Argyropoulos, R. M. Berry, Holzforschung, 1998, 52(5), 499 Dimethyldioxirane (DMD) - DMD can be generated from acetone and peroxymonosulfate (PMS) in-situ . - Activated Oxygen (AO), effective in transferring a single activated oxygen atom onto aromatic and unsaturated substrates. - Advantageous compared with ClO 2 , O 2 , H 2 O 2 which can only oxidize phenolic hydroxyl groups

  17. DMD Activated peroxide bleaching Pulp delignification in-situ generation of DMD General Conditions - Acetone/oxone (2KHSO 5 ·KHSO 4 ·K 2 SO 4 ) ratio, 1.5 - Temperature, 25 ℃ - Retention time, 60-110min - 10% consistency oxidants decomposition - 1.5~2.5 AO charge on o.d. pulp Schematic of the reactions of delignification and - pH 7-7.5 (bicarbonate or phosphate) chemical decomposition during in situ dimethyldioxirane bleaching Zhou et al. BioResources, 2010, 5(3), 1779

  18. DMD Activated peroxide bleaching - Spruce kraft pulp - Bicarbonate buffer - Delignification conditions: AO charge: 1.5% on o.d. pulp final csc: 10% acetone/AO ratio: 1.5 Temperature: 25 ℃ phosphate ( ● ) and bicarbonate ( ▲ ) buffers -The presence of bicarbonate has maximized the delignification efficiency in pH 7~8 J. Bouchard et al. Holzforschung, 1998, 52(5),499

  19. DMD Activated peroxide bleaching Experimental Details -Birch kraft pulp -M stage: varying acetone/oxone molar ratio, pH~7-7.5, 25 ℃ , 60min, csc 10% -E stage: 8% NaOH, 70 ℃ , 60min, csc 10% -Ep stage: 0.8% H 2 O 2 , the other conditions are the same as E stage -Op stage: O 2 0.3Mpa, 100 ℃ , 60min, csc 10%, 2% NaOH, 0.8% H 2 O 2 , 0.5%MgSO 4 , 3% NaSiO 3 -Q stage: 0.5% EDTA, pH~5, 70 ℃ , csc10%, 60min -P stage: 3% H 2 O 2 , 2% NaOH, 0.5% MgSO 4 , 3% NaSiO 3 , 70 ℃ , csc10%, 70min -A stage: 2.5% H 2 SO 4 , 0.6% sodium hexametaphosphate, 25 ℃ , csc 10%, 60min - The optimum AO charge in this condition is considered to be ~2.5% - DMD reduced viscosity loss in a great extent Zhou et al. BioResources, 2010, 5(3), 1779

  20. DMD Activated peroxide bleaching - DMD is both effective and selective as a delignifying agent but not as a brightening agent - The stage M made it possible to achieve a high DP and cellulos content, but the brighteness is still far away from 90%ISO D. S. Argropoulos, Can. J. Chem. 1996, 74, 232
