Capacity Allocation for Big Data Applications in the Cloud 27 th - PowerPoint PPT Presentation

Capacity Allocation for Big Data Applications in the Cloud 27 th April 2017 QUDOS 2017@ICPE Workshop, LAquila Michele Ciavotta Eugenio Gianniti Danilo Ardagna DICE Horizon 2020 Project Grant Agreement no. 644869 Funded by the Horizon 2020


  1. Capacity Allocation for Big Data Applications in the Cloud 27 th April 2017 QUDOS 2017@ICPE Workshop, L’Aquila Michele Ciavotta Eugenio Gianniti Danilo Ardagna DICE Horizon 2020 Project Grant Agreement no. 644869 Funded by the Horizon 2020 http://www.dice-h2020.eu Framework Programme of the European Union

  2. Outline o Background and motivations o D-SPACE4Cloud Tool o Experimental results o Conclusions and future work Danilo Ardagna

  3. Background o Data intensive applications (DIAs) hosted on public Clouds o The goal is to optimize resource allocation at design time, taking into account quality of service constraints Danilo Ardagna

  4. D-SPACE4Cloud Tool Innovation : The problem : o Design space exploration has o Minimize costs and suggest the optimal deployment architecture been increasingly sought in traditional multi-tier applications, that provides QoS guarantees but not in the design of DIAs Impact & stakeholders: What does the tool do? o Designers and operators make o Automatic analysis of multiple more informed decisions about candidate alternative the technology to use configurations to identify the minimum cost one o Reduce costs of a shared cluster running multiple DIAs Danilo Ardagna

  5. Reference System Danilo Ardagna

  6. Complete Optimization Problem X min ( σ τ i s i + π τ i R i ) (P1a) x , ν , s , R i ∈ C X ( ν , s , R ) ∈ arg min ( σ τ i s i + π τ i R i ) (P1g) subject to: i ∈ C subject to: X x ij = 1 , ∀ i ∈ C (P1b) η i j ∈ V ∀ i ∈ C (P1h) s i ≤ R i , 1 − η i X P i, τ i = P ij x ij , ∀ i ∈ C (P1c) ν i = R i + s i , (P1i) ∀ i ∈ C j ∈ V T ( P i, τ i , ν i ; H i , Z i ) ≤ D i , ∀ i ∈ C (P1j) X σ τ i = σ j x ij , ∀ i ∈ C (P1d) ν i ∈ N , ∀ i ∈ C (P1k) j ∈ V ∀ i ∈ C (P1l) R i ∈ N , X π τ i = π j x ij , ∀ i ∈ C (P1e) (P1m) s i ∈ N , ∀ i ∈ C j ∈ V x ij ∈ { 0 , 1 } , ∀ i ∈ C , ∀ j ∈ V (P1f) o Many integer variables and constraints make the problem intractable with exact methods o We split the problem in two layers Danilo Ardagna

  7. Local Search Motivations o The mathematical programming problem is written with a raw performance prediction formula o The optimum should also be accurate, hence we rely on simulation models o There is the need to explore the design space o The initial guess might turn out to be infeasible o The initial guess might be overprovisioned Danilo Ardagna

  8. D-SPACE4Cloud Architecture Danilo Ardagna

  9. Local Search Method o Apply hill climbing per class varying the VM allocation o Evaluate the optimal configuration returned by (P1) to choose the climbing direction o Remove instances if feasible o Add more VMs if infeasible o Stop after reaching the local optimum Danilo Ardagna

  10. Simulation Models Validation o TPC-DS benchmark, datasets ranging from 250 GB to 1 TB o Experiments run on Amazon EC2, Cineca, Flexiant, with cluster sizes ranging from 20 to 240 cores o Overall, 27,000 CPU hours worth of experiments Danilo Ardagna

  11. Optimal Cluster Cost R1 — H10 R1 — H20 0.9 2 0.8 1.5 Cost [ e /h] Cost [ e /h] 0.7 CINECA CINECA 0.6 1 m4.xlarge m4.xlarge 0.5 0.5 0.4 0.3 00 0 5e+06 1e+07 1.5e+07 2e+07 2.5e+07 3e+07 5e+06 1e+07 1.5e+07 2e+07 2.5e+07 3e+07 Deadline [ms] Deadline [ms] Danilo Ardagna

  12. Conclusions o D-SPACE4Cloud minimizes the overall cost under QoS constraints o The tool supports a search technique to compare various providers and offerings o Since we rely on accurate simulation models, we can reasonably trust the optimal configuration returned Danilo Ardagna

  13. Future Work o Exploit machine learning and insight on the problem to improve heuristics efficiency o Consider private or hybrid Clouds by adding capacity constraints o Address other technologies: Spark and Storm Danilo Ardagna

  14. Thanks! www.dice-h2020.eu Danilo Ardagna
