Bringing Security and Multi- tenancy to Kubernetes

Lei (Harry) Zhang

About Me

• Lei (Harry) Zhang @resouer
• #CNCF member, #Microsoft MVP
• Previous: VMware, Baidu
• Feature Maintainer of Kubernetes
• HyperCrew: https://hyper.sh/
• Publication: Docker & Kubernetes Under the Hood
• Phd Candidate #Large-scale cluster scheduling and management

A survey about “boundary”

• Are you comfortable with Linux containers as an effective boundary?
• Yes, I use containers in my private/safe environment
• No, I use containers to serve the public cloud

As long as we care security…

• We have to wrap containers inside full-blown virtual machines
• But we lose cloud-native deployment
• Slow startup time
• Huge resources wasting
• Memory tax for every container
• …

dream reality

Revisit container

• Container Runtime
• The dynamic view and boundary of

your running process

• Container Image
• The static view of your program, data,

dependencies, files and directories

namespace cgroups

FROM busybox ADD temp.txt / VOLUME /data CMD [“echo hello"] Read-Write Layer & /data “echo hello”

read-only layer

/bin /dev /etc /home /lib / lib64 /media /mnt /opt /proc / root /run /sbin /sys /tmp / usr /var /data /temp.txt

/etc/hosts /etc/hostname /etc/resolv.conf

read-write layer

/ t e m p . t x t

json

json

init layer

FROM busybox ADD temp.txt / VOLUME /data CMD [“echo hello"]

Docker Container

HyperContainer

Secure Kubernetes from runtime level

HyperContainer

• Container Runtime
• RunV
• https://github.com/hyperhq/runv
• A OCI compatible hypervisor based runtime implementation
• Control daemon
• https://github.com/hyperhq/hyperd
• Container Image
• Docker Image Spec

Combine the best parts

• Portable and behaves like a Linux container
• $ hyperctl run -t busybox echo helloworld
• sub-second startup time*, ~12MB memory cost
• Fully isolated sandbox with an independent guest kernel
• $ hyperctl exec -t busybox uname -r
• 4.4.12-hyper (or your provided kernel)
• security, backward compatibility, maturity

See: http://hypercontainer.io/why-hyper.html

HyperContainer is a Pod

• That’s how HyperContainer fits into the Kubernetes philosophy
• Wait, why Pod is so important?

Pod: lesson learned from Borg

• Should sample.war be packaged with Tomcat?

Pod: lesson learned from Borg

• InitContainers: one or more containers started in

sequence before the pod's normal containers are started.

• Share volumes, perform network operations, and

perform computation prior to the app containers.

So, Pod is

• The group of super-affinity containers
• The atomic scheduling unit
• The process group in container cloud
• Do right things
• without modifying your container image
• Kubernetes = Spring Framework
• Pod = IoC

Pod log app infra container volume init container

Pod is not easy to simulate

• log super affinity app
• Requirement:
• app: 1G, log: 0.5G
• Available:
• Node_A: 1.25G, Node_B: 2G
• What happens if app scheduled to Node_A?

HyperContainer is a Pod

• Linux container based runtimes
• wraps and encapsulates several app containers into a logical group
• Hypervisor container based runtime
• hypervisor serves as a natural boundary of Pod

HyperContainer is a Pod

• Container Runtime Interface
• create sandbox Foo --> create container C --> start container

C

• stop container C --> remove container C --> delete sandbox

Foo

• Sandbox
• Normally: the infra container
• HyperContainer: hypervisor
• with HyperKernel
• a HyperStart process as PID 1
• setup mnt namespace, launch apps from the images etc

Hypernetes

Kubernetes with HyperContainer Runtime

Hypernetes

• Also: h8s
• Kubernetes + HyperContainer runtime
• officially supported by using kubernetes/frakti
• Multi-tenant network and persistent volumes
• battle tested Neutron + Cinder plugin

Multi-tenant Network

• Goal:
• leveraging tenant-aware neutron network for Kubernetes
• following the network plugin workflow
• Non-goal:
• break k8s network model or hack k8s code

Define the Network

• Network
• a top class api object
• each tenant (created by Keystone) has its own Network
• Network mapping to Neutron “net”
• a Network Controller is responsible to manage Network lifecycle

Example

kubelet

SyncLoop

controller-manager

ControlLoop

kubelet

SyncLoop

proxy proxy

network pod replica namespace service job deployment volume petset …

etcd

scheduler

api-server

Desired World Real World

Call Neutron to create/delete network

Kubernetes Network Model

• Container reach container
• all containers can communicate with all other containers without NAT
• Node reach container
• all nodes can communicate with all containers (and vice-versa) without NAT
• IP addressing
• Pod in cluster can be addressed by its IP

How h8s fits that?

• Network can be assigned to one or more

Namespaces

• Pods belonging to the same Network can

reach each other directly through IP

• a Pod’s network mapping to Neutron “port”
• kubelet network plugin is responsible for Pod

network setup

Example

kubelet

SyncLoop

kubelet

SyncLoop

proxy proxy

1 Pod created

etcd

scheduler

api-server

Example

kubelet

SyncLoop

kubelet

SyncLoop

proxy proxy

2 Pod object added

etcd

scheduler

api-server

Example

kubelet

SyncLoop

kubelet

SyncLoop

proxy proxy

3.1 New pod object detected 3.2 Bind pod with node

etcd

scheduler

api-server

Example

kubelet

SyncLoop

kubelet

SyncLoop

proxy proxy

4.1 Detected pod bind with me 4.2 Start containers in pod

etcd

scheduler

api-server

Design of kubelet

InitNetworkPlugin Choose Runtime docker, rkt, hyper/remote InitNetworkPlugin

HandlePods {Add, Update, Remove, Delete, …}

NodeStatus Network Status status Manager PLEG

SyncLoop

Pod Update Worker (e.g.ADD)

• generale Pod status
• check volume status (talk later)
• call runtime to start containers
• set up Pod network (see next slide)

volume Manager

PodUpdate

image Manager

Set Up Pod Network

kubestack

A standalone gRPC daemon

• 1. to “translate” the SetUpPod request to the Neutron network API
• 2. handling multi-tenant Service proxy

Service

$ iptables-save | grep my-service

• A KUBE-SERVICES -d 10.0.0.116/32 -p tcp -m comment --comment "default/my-service: cluster IP" -m tcp --dport 8001 -j KUBE-SVC-KEAUNL7HVWWSEZA6
• A KUBE-SVC-KEAUNL7HVWWSEZA6 -m comment --comment "default/my-service:" --mode random -j KUBE-SEP-6XXFWO3KTRMPKCHZ
• A KUBE-SVC-KEAUNL7HVWWSEZA6 -m comment --comment "default/my-service:" --mode random -j KUBE-SEP-57KPRZ3JQVENLNBRZ
• A KUBE-SEP-6XXFWO3KTRMPKCHZ -p tcp -m comment --comment "default/my-service:" -m tcp -j DNAT --to-destination 172.17.0.2:80
• A KUBE-SEP-57KPRZ3JQVENLNBRZ -p tcp -m comment --comment "default/my-service:" -m tcp -j DNAT --to-destination 172.17.0.3:80

portal 10.10.0.116:8001 random mode rules backend rule_1 backend rule_2 172.17.0.2.:80 172.17.0.3.:80

OnServiceUpdate OnEndpointsUpdate

Multi-tenant Service

• Default iptables-based kube-proxy is not tenant aware
• Endpoint Pods and Nodes with iptables rules are isolated into different

networks

• Hypernetes uses a built-in HAproxy as the Service portal
• to proxy all Service instances within same namespace
• the same OnServiceUpdate and OnEndpointsUpdate process
• ExternalProvider
• a OpenStack LB will be created as Service
• e.g. curl 58.215.33.98:8078

Kubernetes Persistent Volume

Host path Cinder volume plugin Pod Pod

mountPath mountPath

attach mount

Volume Manager

desired World reconcile

• Get mountedVolume from actualStateOfWorld
• Unmount volumes in mountedVolume but not in

desiredStateOfWorld

• AttachVolume() if vol in desiredStateOfWorld and not

attached

• MountVolume() if vol in desiredStateOfWorld and not

in mountedVolume

• Verify devices that should be detached/unmounted are

detached/unmounted

• Tips:
• 1. -v host:path
• 2. attach VS mount
• 3. Totally independent from container

management

Persistent Volume with HyperContainer

• Enhanced Cinder volume plugin
• Linux container:
• 1. full OpenStack cluster
• 2. query Nova to find node
• 3. attach Cinder volume to host path
• 4. bind mount host path to Pod containers
• HyperContainer:
• directly attach block devices to Pod
• thanks to the hypervisor based Pod boundary
• eliminates extra time to query Nova

Host vol Enhanced Cinder volume plugin Pod Pod

mountPath mountPath

attach vol

desired World reconcile

Volume Manager

PV Example

• Create a Cinder volume
• Claim volume by reference its

volumeID

Container Runtime Interface

Future of CRI

• Keep Docker as the only one default container runtime
• ocid, rktlet, hyperd
• Frakti: the Remote Container Runtime Kit
• https://github.com/kubernetes/frakti
• welcome to tryout, star and fork

“if image becomes non-standard”

• e.g. Docker image becomes somehow Docker specific
• Don’t worry, kubelet.imageManager is moving to runtime specific
• but then k8s will probably choose
• NO DEFAULT runtime

Node Node

Full Topology

Node kubestack Neutron L2 Agent kube-proxy kubelet Cinder Plugin Pod Pod Pod Pod KeyStone Neutron Cinder Master Object: Network Ceph Object: Pod Object: …

Summary

• A new way to build secure and multi-tenant Kubernetes
• Kubernetes + HyperContainer + Neutron Plugin + Cinder Plugin + Keystone
• Roadmap
• Graduate HyperContainer runtime on k8s upstream
• Neutron CNI plugin
• Project URL: https://github.com/hyperhq/hypernetes
• Tip: https://hyper.sh is totally built on Hypernetes, try it out :)

END

Lei (Harry) Zhang @resouer
