Bellerophon: Tactical Theorem Proving for Hybrid Systems Nathan - PowerPoint PPT Presentation

Nov 15, 2023 •273 likes •964 views

Bellerophon: Tactical Theorem Proving for Hybrid Systems Nathan Fulton , Stefan Mitsch, Brandon Bohrer, Andr Platzer Carnegie Mellon University Cyber-Physical Systems Cyber-Physical Systems combine computation and control. Hybrid Systems

  1. Bellerophon: Tactical Theorem Proving for Hybrid Systems Nathan Fulton , Stefan Mitsch, Brandon Bohrer, André Platzer Carnegie Mellon University

  3. Cyber-Physical Systems Cyber-Physical Systems combine computation and control. Hybrid Systems model combinations of discrete and continuous dynamics.

  4. Bellerophon Verifying hybrid systems is hard.

  5. Bellerophon Verifying hybrid systems is hard. Bellerophon demonstrates how to tackle hybrid systems with tactics:

  6. Bellerophon Verifying hybrid systems is hard. Bellerophon demonstrates how to tackle hybrid systems with tactics: ● Build on a sound core.

  7. Bellerophon Verifying hybrid systems is hard. Bellerophon demonstrates how to tackle hybrid systems with tactics: ● Build on a sound core. ● Implement high-level primitives for hybrid systems proofs.

  8. Bellerophon Verifying hybrid systems is hard. Bellerophon demonstrates how to tackle hybrid systems with tactics: ● Build on a sound core. ● Implement high-level primitives for hybrid systems proofs. ● Automate common constructions (for ODEs and control software)

  9. Bellerophon Theorem Bellerophon Conceptual Proof Hybrid Systems LOC Steps Axiom Applications Static Safety 12 71 30,355 Passive-Friendly 45 140 68,620 Safety Orientation Safety 15 108 173,989 Pass Intersection 234 440 61,878 Liveness

  10. KeYmaera X: Trustworthy Foundations Interactive Reachability Analysis Bellerophon combinator language ➢ Bellerophon standard library for hybrid systems ➢ Demonstration ➢ Bellerophon for Automation and Tooling Conclusions & Resources

  11. Trustworthy Foundations KeYmaera X enables trustworthy automation for hybrid systems analysis: ● A well-defined logical foundations, ● implemented in a small trustworthy core ● that ensures correctness of automation and tooling .

  12. Trustworthy Foundations Hybrid Programs a=a 0 a=t a := t b=b 0 b=b 0 c=c 0 c=c 0 ... ...

  13. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ...

  14. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ... If P is true: no change ?P If P is false: terminate

  15. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ... a ∪ b If P is true: no change ?P If P is false: terminate

  16. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ... a ∪ b If P is true: no change ?P If P is false: terminate

  17. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ... a ∪ b If P is true: no change ?P If P is false: terminate a* a ...a...

  18. Trustworthy Foundations Hybrid Programs a;b a=a 0 a=t a := t a;b b=b 0 b=b 0 c=c 0 c=c 0 a b ... ... a ∪ b If P is true: no change ?P If P is false: terminate x=F(0) ... x’=f a* a ...a... x=x 0 ⋮ ... x=F(T) ...

  19. Trustworthy Foundations Reachability Specifications [a]P “after every execution of a, P” <a>P “after some execution of a, P”

  20. Trustworthy Foundations Reachability Specifications [a]P “after every execution of a, P” <a>P “after some execution of a, P” init → [{x := u(x); x’ = f(x)}*]safe

  21. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; {x’ = v, V’ = f(v,g,r), t’=1 v’=f(v,g,r) x & 0≤x & t≤T} }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  22. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; {x’ = v, V’ = f(v,g,r), t’=1 v’=f(v,g,r) x & 0≤x & t≤T} }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  23. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; {x’ = v, V’ = f(v,g,r), t’=1 v’=f(v,g,r) x & 0≤x & t≤T} }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  24. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; {x’ = v, V’ = f(v,g,r), t’=1 v’=f(v,g,r) x & 0≤x & t≤T} }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  25. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; { x’ = v, V’ = f(v,g,r) , t’=1 v’=f(v,g,r) x & 0≤x & t≤T} }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  26. Trustworthy Foundations Hello, World { {?Dive ∪ r := r p }; t:=0; {x’ = v, V’ = f(v,g,r), t’=1 v’=f(v,g,r) x & 0≤x & t≤T } }* Control : Continue diving if safe, else open parachute. Plant : Downward velocity determined by gravity, air resistance.

  27. Trustworthy Foundations Reachability Specifications (Dive & g>0 & …)→ [{ {?Dive ∪ r := r p }; {x’ = v, V’ = f(v,g,r) & 0≤x} v’=f(v,g,r) x }*] (x=0→m≤v)

  28. Trustworthy Foundations Reachability Specifications (Dive & g>0 & …)→ [{ {?Dive ∪ r := r p }; {x’ = v, V’ = f(v,g,r) & 0≤x} v’=f(v,g,r) x }*] (x=0→m≤v) If the parachuter is on the ground, their speed is safe (m≤v≤0)

  29. Introduction to Differential Dynamic Logic Dynamical Axioms [x:=t]f(x) ↔ f(t) [a ; b]P ↔ [a][b]P [a ∪ b]P ↔ ([a]P & [b]P) [x’=f&Q]P → (Q → P) ...

  30. Introduction to Differential Dynamic Logic Trusted Core AXIOM BASE Q.E.D. KeYmaera X Core [x:=t]f(x) ↔ f(t) [a;b]P ↔ [a][b]P [a ∪ b]P ↔ ([a]P & [b]P) [x’=f&Q]P → (Q → P) ...

  31. Introduction to Differential Dynamic Logic Trustworthy Implementations Automated Bellerophon Tooling Analyses AXIOM BASE Q.E.D. [x:=t]f(x) ↔ f(t) KeYmaera X Core [a;b]P ↔ [a][b]P [a ∪ b]P ↔ ([a]P & [b]P) [x’=f&Q]P → (Q → P) ...

  32. Introduction to Differential Dynamic Logic Prover Core Comparison

  33. Bellerophon Bellerophon enables interactive verification and tool development:

  34. Bellerophon Bellerophon enables interactive verification and tool development: ● A standard library of common proof techniques.

  35. Bellerophon Bellerophon enables interactive verification and tool development: ● A standard library of common proof techniques. ● A combinator language/library for decomposing theorems and composing proof strategies.

  36. Bellerophon Standard Library Tactic Meaning Applies propositional reasoning exhaustively. prop Symbolically executes discrete, loop-free programs. unfold Applies loop invariance axiom to position i. loop(J, i) Reasoning principles for differential equations. dI,dG,dC,dW

  37. Bellerophon Standard Library Tactic Meaning 1000+ Applies propositional reasoning exhaustively. prop Symbolically executes discrete, loop-free programs. unfold Applies loop invariance axiom to position i. loop(J, i) Reasoning principles for differential equations. dI,dG,dC,dW

  38. Bellerophon Combinators Tactic Meaning 1000+ Applies propositional reasoning exhaustively. prop Symbolically executes discrete, loop-free programs. unfold Applies loop invariance axiom to position i, extends J with constants. loop(J, i) Reasoning principles for differential equations. dI,dG,dC,dW Combinator Meaning A ; B Execute A on current goal, then execute B on the result. A | B Try executing A on current goal. If A fails, execute B on current goal. A * Run A until it no longer applies. A<( B 1 ,B 2 , … ,B N ) Execute A on current goal to create N subgoals. Run B i on subgoal i.

  39. Bellerophon Isolating Interesting Questions (Dive & g>0 & …)→ [{ }*] (x=0→m≤v)

  40. Bellerophon Isolating Interesting Questions (Dive & g>0 & Loop invariant holds initially …)→ (Dive & g>0 J & …)→ [{ J →[ Loop invariant is preserved prop ; loop(J,1) ]J J → }*] (x=0→m≤v) Loop invariant implies safety x=0→m≤v

  41. Bellerophon Isolating Interesting Questions (Dive & g>0 & Loop invariant holds initially …)→ (Dive & g>0 J & …)→ [{ J →[ Loop invariant is preserved prop ; loop(J,1) ]J J → }*] (x=0→m≤v) Loop invariant implies safety x=0→m≤v

  42. Bellerophon Isolating Interesting Questions (Dive & g>0 & …)→ (Dive & g>0 J & …)→ [{ J →[ J & Dive & r=r a → [x’=v,v’=...]J prop ; loop(J,1) u n f o l d J & r=r p → ]J [x’=v,v’=...]J J → }*] (x=0→m≤v) x=0→m≤v

  43. Bellerophon Isolating Interesting Questions (Dive & g>0 & …)→ (Dive & g>0 J & …)→ [{ J →[ J & Dive & r=r a → [x’=v,v’=...]J prop ; loop(J,1) u n f o l d J & r=r p → ]J [x’=v,v’=...]J J → }*] (x=0→m≤v) x=0→m≤v

  44. Bellerophon Isolating Interesting Questions prop ; loop(J, 1) <( QE, /* Real arith. solver */ QE, unfold ; <( … /* parachute open case */ … /* parachute closed case */ ) )
