B8104 B8100 Dual Flush 1.1 Gallon/ 4 Liter Flush System F lush System Presentation Introduction of EcoFlush How EcoFlush works Sub - Assemblies Features and Benefits Flush Valve Technology Trouble Shooting Technical Support Pressurized


  1. B8104 B8100 Dual Flush 1.1 Gallon/ 4 Liter Flush System F lush System

  2. Presentation Introduction of EcoFlush How EcoFlush works Sub - Assemblies Features and Benefits Flush Valve Technology Trouble Shooting Technical Support

  3. Pressurized Flushing System B8100 meets all HET Requirements Minimum 20% Reduction in Water Consumption and Waste Water Discharge No Flapper leakage! No Tank Sweating!

  4. It Works How It

  5. How It Works How Ecoflush Works 1. Water Flows into the Vessel passing through the lower supply, Pressure Relief Valve with Backflow Prevention. The lower supply assembly reduces water pressure that is above 50psi to ensure perfect operation.

  6. How It Works 2. Fully Charged Ready to Flush

  7. How It Works 3 . The F The F lush lush

  8. Jetted Bowl Design This powerful flushing action drives the waste from the bowl while thoroughly cleaning the bowl. The combined elements of air and water dramatically improve drain-line carry, & virtually eliminate sewer stoppages.

  9. Anti-Siphon Back Flow Prevention Upper Assembly Air Inducer Full Flush Partial Flush Vessel 1.6 Gallons 1.1 Gallons 6 Liters 4 Liters Discharge Extension and Drain Pressure Regulator Relief Valve Flush Valve Cartridge Supply Line to Upper Lower Inlet Assembly Supply Assembly

  10. B8100 Parts

  11. Flush Control Valve Technology EcoFlush Features Silent Flush Engineered to make the system one of the quietest in the world. Feather Touch™ The Flush Control Valve is water activated for a Feather Touch Activation. Fully ADA compliant. Ideal for small children and seniors.

  12. Trouble Shooting

  13. Trouble Shooting

  14. Trouble Shooting

  15. Trouble Shooting

  16. Trouble Shooting

  17. Trouble Shooting

  18. Trouble Shooting

  19. Meets All Plumbing Codes & Standards EcoFlush pressure vessels are IAPMO approved & certified under ANSI/ASME A112.119.14 – ASSE 1037-99 & CSA B45 & B125 testing standards. IAPMO Certified for North America Life-cycle tested over 150,000 flushes 29 Years at 14 flushes/day

  20. Toll Free Customer Service Toll Free Customer Service Backed by a 10 Year Limited Warranty Well Established Warranty and Replacement Parts Program Toll Free Customer Service Line (800) 391-9821
