AST TRACKING SOLUTIONS V2.0_May2010
System Based on AST’s DataNet • DataGate – tracking server software Can be AST based or end user installed – Available with full end to end encryption – • DataHost – user interface software Allows full control of Assets and messaging – • Web based browser Gives web based monitoring with limited functions –
AST DataNet Structure
Asset Networks • Iridium SBD • Globalstar (SPOT) • VPN (VSAT, BGAN, Fleet BB) • Thuraya • GSM (GPRS) • Inmarsat C, Mini C, D, D+, Isatm2m • AST’s onsatmail email package
DataHost Screen Shot
Hardware Units • VMS Lite Iridium SBD based tracking unit with inbuilt GPS. Fully programmable over air from DataHost • Tracker i50B Fully programmable Iridium SBD/GPRS/WiFi unit with inbuilt GPS three Com ports for messaging and communications. I/O ports user interfaces • AST SDB Pro tracker Small foot print programmable tracker • Field Tracker 2000 Small personal tracker with two way messaging • Globalstar SPOT Distress and tracking unit • Mini C Inmarsat based tracking unit • GSM/GPRS units BlackBerry, Enfora,TrimTrac Pro
Functionality • Full report generation on all or single assets • Control of assets • Alerting to and from assets • Distress alerting to mobile phone (SMS) • Messaging to and from assets • Geofencing options • Polling functions • Data export for other GIS applications
Report Generation
Report Formats
Report Formats
i50b Tracker
Iridium/GPRS compatible hardware Accelerometer chip measures “G” • forces Engine computer interface • Three external serial COM ports • 8 I/O ports • Internal Iridium modem (optional) • Internal GPRS modem (optional) • The Tracker i50b designed by 12 channel GPS • Datalink is probably the Delayed power off • most advanced mobile data terminal available. A Sleep mode • Garmin nuvi add-on option SCADA ready • will be available in 2009 Emergency alert capability • allowing two-way text messaging. Dual network capability • Wi-Fi port •
i50B Tracker FEATURES • 50 channel GPS receiver (supports GPS and GALILEO signals) – Internal satellite and cellular modems with dual operation (optional) – Internal Wi-Fi modem (optional) – Three external RS-232 serial ports (only two available when using internal Wi-Fi) – Sleep mode with adjustable timeout and periodic wakeup timer – Wide input voltage range with load dump protection – Battery voltage monitoring – Four digital inputs plus Ignition input – Four digital outputs – Two analog inputs – Switched power output for driving external devices – Internal flash memory for permanent storage of unit settings – Internal data buffer with backup battery eliminates data loss – Internal three-axis accelerometer with auto leveling – External J1708 engine interface (optional) – Panic alert mode – SCADA ready – Remotely programmable –
VMS Lite Iridium SBD Built in 12 ch. GPS Alternative Antenna’s 12 Volt DC operation Fully Programmable Optional Com port Optional Distress Button
Iridium Field Tracker 2000 Automated transmission of unit position at user-settable intervals. • Two-way text message communication using the Iridium satellite • system, ensuring every message is successfully sent Internal rechargeable battery, with several charge options • including solar charging Ability to send an alert notification signal Alerts can be routed to • your organization's command centers or monitored through an optional add-on service. Two-way communication ensures you can tell the person monitoring what the alert is for Manual and quick-start sheet to get you up and running quickly • Optional cold-weather battery kit for extreme cold operation • Simple configuration of the Field Tracker 2000 using on-screen • menus Easy user configuration of optional settings through the secure • User Web site Small size :- 150mm x 80mm x 50mm • Inbuilt antenna • Waterproof •
AST SBD Pro Utilises SBD protocol for lowest airtime costs • Integrated GPS, UTC time and temperature • User-configurable event reporting • External sensors can be monitored and reported • Monitor Voltage, Current, Fault Modes, Low Battery • Wide range power input: 9 to 32VDC • Compact, rugged, and water resistant design • Certifications and approvals: Iridium, CE and IEC 60945 • Features and Equipment • Simple text-based configuration scripts get you up and • running quickly Reporting intervals can range from 15 seconds to 1 year • Configurable over-the-air or via serial interface • Digital and analog input/output interfaces for ultimate • flexibility Low power modes for battery/solar operation •
iMDT-2000 Messaging Terminal (GPRS/Iridium/CDMA/D+) The iMDT-2000 is a low cost yet very adaptable mobile terminal which can deliver two-way text messaging, GPS location reporting, and other additional services unique to each client. With a total of four serial COM ports the MDT can operate over multiple wireless networks including satellite. The iMDT-2000 will connect to the SkyHawk (Globalstar), i50b,DSL-9612 (Iridium) and the PDT-100 (MSAT-1) for satellite operation. It is also available with internal GSM-GPRS modem. The iMDT-2000 will also connect to the Lone Worker safety system and other devices.
GARMIN two-way In the transportation of freight, time is money! Drivers getting lost on route costs both time and fuel, and in today's economy the fleet manager must run an efficient operation. By selecting AST’s DataNET "back end" software and a Garmin nuvi Fleet Management Terminal such as the 765, drivers will be able to take the shortest and quickest route to any address with turn by turn visual track and Garmin nuvi units will work with voice directions. Enfora and i50B Tracker units The power of the DataNET software allows the dispatcher to select a destination point on a map and to transmit the location over a cellular or satellite link to the vehicle, where the Garmin unit will calculate the vehicle's current location and the best route to the destination point and display it for the driver to follow. DataNET will also allow two-way text messages to be exchanged between the dispatch desk and the driver. The driver can send a choice of "canned" messages. The GPS location of the vehicle is automatically sent to the dispatcher's computer mapping display.
Globalstar SPOT Uses Globalstar simplex service Battery operation Tracking Mode Distress mode
ONSATMAIL Peter Notley October 2009
New additions for 2009 in onsatmail • Signal level monitoring for Iridium connections • SMS calling notify (set in call settings) • GPS input for tracking and >kml log files for Google earth visuals • Usernet groups for broadcast messages within groups • Position centred Grib files using GPS input • Crew calling support, cost centre (in onsatmail Pro)
BlackBerry Tracking • Blackberry with installed tracking application • Works on BlackBerry’s with inbuilt GPS (Curve 8900 etc.) • Tracking and covert alert facility
Enfora • The Enfora Mini MT is a fully certified quad- band integrated platform that provides complete GSM/GPRS functionality for mobile tracking applications. Its integrated GPS capabilities include tracking of up to 14 satellites and location reporting through SMS and GPRS.
TrimTrac Pro • Complete packaged end-user device No external connections or antenna GSM Quad band. Indoor and outdoor position reports via SMS Battery-powered or connect to vehicle power monitor up to three types of inputs
www.satcomms.com
