Asia Coal Catalyst Company CC-88 Coal Catalyst for Improved Combustion and a Cleaner Environment patented product from the USA of introduced and distributed in Pakistan by TECHNOLOGY MANAGEMENT INT�L (PVT.) LTD CONSULTANCY SERVICE  PROJECT DEVELOPMENT & IMPLEMENTATION  HUMAN RESOURCE DEVELOPMENT T E C H M A

What is a Catalyst A compound or element that can increase the rate of a chemical reaction What does Coal Catalyst CC-88 do? Promotes the physical and chemical reactions that occur during combustion Releases more oxygen to the carbon contained in the coal

The Function of CC-88 Combustion Catalyst

The Function of CC-88 Combustion Catalyst

Benefits of using CC-88 Improves Combustion Efficiency, Lowers Fuel Consumption and Increases Steam Production Overall Emissions Reduction Prevents, Reduces and Removes Slag Build-up 1. 2. 3. Improved combustion savings range from 2% to greater than 15% Reduces emissions of SOx, NOx and CO 50-85% of SOx, 45-85 % of NOx and nearly Eliminate Slag by changing boiler combustion zone chemistry through the use of CC-88 95%-100% of CO (Depending upon Fuel GCV /Dosing)

Benefits of using CC-88 Reduce the use of Excess Air 4. 5. Amount of air reduced will depend upon the level of reactivity of the catalyst and the coal being burned Reduces the formation of NOx emissions as well as reduce the amount of flue gases passing through the system, improving the efficiencies of the heat exchanger and electrostatic precipitator Improves Ash Quality for Ash Resale Higher quality ash with less carbon content which can be used utilized in the production of cement or as an aggregate in concrete mixing CC-88 Nominal Feed Rate = 0.5kg CC-88 to 1MT Coal

CC-88 Injection Methods Screw Feeder Unit A screw feeder mechanism provides precise and accurate range to control the feed rate of CC-88. A load cell is used as part of the weighing system to obtain weighing accuracy. The screw rotates at a controlled rate to feed the CC-88 to the boiler at a precise Kg per MT rate.

Dense Phase Transporters For larger boilers CC-88 is injected directly into the boiler furnace or combustion chamber using a dense phase transporter that uses pneumatics (pressurized air) to control the exact dosage of CC-88. CC-88 Injection Methods

CC-88 Return on Investment Fuel Longer equipment life Fewer outages Ash disposal SO2 scrubbers Lower emissions CSR Savings and Benefits CC-88 Injection System Expenses

Agrico Chemical F. W. Woolworth Otis Elevator Newell Companies, Inc. Kraft Company Kaiser Aluminum & Chemical Johns-Manville Products Illinois Bell Telephone GTE Automatic Electric Greer Laboratories General Mills General Electric Ford Motor Company Continental Bank American Brick Company City of Chicago Chicago Housing Authority Cargill Corporation Capital Chemical Company Boeing Aircraft Company Blue Cross/Blue Shield Bell & Howell Appleton Paper, Inc. Amoco Oil Company American Red Cross American Home Food Company CC-88 Coal Catalyst Clients

Results of 8 day Trial at Sadaqat Limited 20 TPH Coal Fired Boiler  8% Reduction in Coal Consumption  8% Reduction in Harmful Emissions  4% Reduction in Unburnt Carbon Results achieved from an 8 day trial at 0.5 kg and 1.0 kg injection of CC-88 4 days each respectfully Manufacturer recommends injection of CC-88 at 1.0 kg for 90 days and thereafter a reduction to 0.5 kg  Currently unmeasurable benefits of reduction in boiler downtime due to significant reduction in Maintenance Costs Manufacturer recommends injection of CC-88 at 1.0 kg for 90 days and thereafter a reduction to 0.5 kg

Contact of Principal Asia Coal Catalyst Company 421 Seventh Ave., 5th Floor New York, NY 10001 Evan Lipstein Chief Executive Officer Phone: 212-688-5600 Email: corporate@coalcatalyst.com Peter Smith, President of Asia Coal Catalyst Company Previously worked in the air pollution control industry for over 40 years with companies such as Air Preheater and Research-Cottrell. Experience with heat transfer, electrostatic precipitators, fabric filters, wet and dry scrubbers and furnace limestone injection for SO2 control.

? Discussion
