A High Performance Packet Core for Next Generation Cellular Networks - PowerPoint PPT Presentation

A High Performance Packet Core for Next Generation Cellular Networks Zafar Qazi + Melvin Walls , Aurojit Panda + , Vyas Sekar, Sylvia Ratnasamy + , Scott Shenker + + 1 Explosive Cellular Growth Many Diverse Devices: Signaling tra


  1. A High Performance Packet Core for Next Generation Cellular Networks Zafar Qazi + Melvin Walls , Aurojit Panda + , Vyas Sekar, § Sylvia Ratnasamy + , Scott Shenker + + § 1

  2. Explosive Cellular Growth Many Diverse Devices: Signaling tra ffi c growth: 3B IoTs by 2019* 50% faster growth than data + Demanding applications 3/4 of data tra ffi c will be video* Cisco visual networking index* Nokia Study + 2

  3. Evolved Packet Core (EPC) Data Tra ffi c Signaling Tra ffi c Voice Tra ffi c EPC 1 Internet EPC 2 … IP Multimedia System (IMS) EPC 3 Radio Access Network 3

  4. Existing Cellular Core Cannot Keep Up! Concerns from Operators Industrial E ff orts Academic Studies 4

  5. EPCs are factored based on functions Component-1 Component-2 Component-N user-1 user-1 user-1 . … . . . . . . . . user-k user-k user-k Distributed user state 5

  6. P erformant EPC ( PEPC ) PEPC : EPC functions factored around state An abstraction of independent and customizable EPC slices 6

  7. Rest of the Talk … • Scalability challenges • Design of PEPC • Implementation and Evaluation 7

  8. Traditional EPCs Signaling Function Mobility Management Entity (MME) Data Gateways EPC Serving Gateway (S-GW) Packet Data Network Gateway (P-GW) Backend servers Subscriber Database Policy Server Home Subscriber Server (HSS) Policy and Charging Rules Function (PCRF) Implemented as hardware appliances Statically provisioned at a few central locations 8

  9. User state in EPC Update State Type MME S-GW P-GW Frequency Per-user w+r w+r w+r per-signaling_event QoS/policy state User id w+r w+r w+r per-signaling_event User location w+r w+r NA per-signaling_event Per-user control w+r w+r w+r per-signaling_event tunnel state Per-user data w+r w+r w+r per-signaling_event tunnel state Per-user NA w+r w+r per-packet bandwidth counters 9

  10. Distributed User State is Problematic! user signaling • Performance overheads + high complexity user 1 tra ffi c user 2 MME - Frequent cross component synchronization … user n • Migration is hard GTP-C - Distributed user state user data user 1 tra ffi c • Customization is hard user 2 S-GW … - Distributed user state + distributed computation user n GTP-C user 1 user 2 P-GW … user n 10

  11. Rest of the Talk … • Scalability challenges • Design of PEPC • Implementation and Evaluation 11

  12. Existing EPC vs. PEPC PEPC Existing EPCs user Slice 1 signaling signaling user 1 state tra ffi c tra ffi c MME R R user 2 state user 1 state data tra ffi c user R R data user 1 state tra ffi c S-GW Slice 2 user 2 state signaling tra ffi c R R user 2 state data user 1 state P-GW tra ffi c R R user 2 state 12

  13. PEPC Slice Control Thread user signaling traffic shared state user data traffic Data Thread Separation of control and data thread —> avoid HOL blocking • Processing time for signaling messages > 10X higher • Control and data threads assigned to separate cores 13

  14. PEPC Slice Control Thread user signaling traffic RW RW R R user N user N user 1 user 1 shared control counter control counter state state state state state user data traffic R R RW RW Data Thread Partition shared state at two levels —> reduces contention • By user • Per-user state whether control or data thread writes to it • Use fine grained locks —> up to 5X improvement over coarse grained locks 14

  15. PEPC Server signaling Slice 1 tra ffi c signaling R R user 1 state data tra ffi c tra ffi c R R • Pause + snapshot user state x u —> simplifies state migration m e data signaling Slice N D tra ffi c tra ffi c • Modify slice data/control flow R R user N state data —> simplifies customization tra ffi c R R Scheduler Proxy Manage Slices Interface with Manage Migration backend servers 15

  16. Rest of the Talk … • Scalability challenges • Design of PEPC • Implementation and Evaluation 16

  17. Implementation • Data plane functions - GPRS Tunnelling Protocol (GTP) - Policy and charging enforcement function • Signaling functions - Implements, S1AP, the protocol used to interface with the base stations - Supports state updates for attach request • Support for e ffi cient state migration across slices • PEPC uses the NetBricks * programming framework * Panda et al. NetBricks: Taking the V out of NFV. OSDI’16 17

  18. PEPC Customization/Optimization Examples • Two level user state storage user 1 user 2 user 3 user 4 Active devices Attached but Inactive devices Improves state lookup performance for data packets • Customization for a class of IoT devices (like smart meters) • Devices that run a single application • Reduce state and customize data processing 18

  19. Evaluation and Methodology • How does PEPC compare with other vEPCs? • How scalable is PEPC with increasing signaling tra ffi c? • How scalable is PEPC is with increasing state migrations? • Benefits of PEPC’s customization/optimizations? • Methodology - DPDK based tra ffi c generator - Replays cellular data and signaling tra ffi c traces - Traces from OpenAirInterface and ng4T 19

  20. Baselines • Industrial#1: An industrial software EPC implementation - DPDK based - Ran as a process inside the host OS, not inside a VM/Container - S-GW/P-GW on one server, and MME on an another server • OpenAirInterface (OAI): An opensource EPC software - Ran as a process inside the host OS - Ran all EPC functions on the same server • OpenEPC on Phantomnet: Software EPC implementation - MME, S-GW, P-GW on di ff erent servers 20

  21. Data plane performance comparison 7 6 Data-plane throughput 250K users 5 10K attach-requests/s (Mpps) 4 3 2 1 0 OAI OpenEPC Industrial#1 PEPC PEPC can sustain data plane throughput (~6 Mpps) for 1:10 signaling to data ratio In contrast, Industrial#1 throughput drops significantly (0.1 Mpps) for more than 1:100 signaling to data ratio 21

  22. PEPC Customization Benefits 40 Improvement in data plane 35 30 throughput (%) 25 20 15 10 5 0 5 25 50 75 100 % of stateless IoT devices For smart meter like devices, can achieve up to 38% improvement 22

  23. Scalability with State Migrations 100 Drop in data plane throughput (%) • State migration across 80 60 two slices within a server 40 20 0 1 10 100 1000 10000 100000 Number of migrations per second Less than 5% drop in data plane throughput with 10K migrations per sec 23

  24. Related work • SDN based cellular designs - SoftCell [ CoNEXT’13 ], SoftMoW [ CoNEXT’15 ] • Virtual EPCs - KLEIN [ SOSR’16 ], SCALE [ CoNEXT’15 ] 24

  25. Summary • Existing EPC systems cannot keep up with cellular growth - Key reason: user state is distributed • New system architecture: PEPC - Refactoring of EPC functions based on user state - Enables horizontal slicing of EPC by users into independent and customizable slices • PEPC performs 3-7x better and scales well with increasing user devices, signaling tra ffi c, and state migrations 25
