21 st Century Antibiotics Gram Negative Antibiotic Gram Positive - PowerPoint PPT Presentation

21 st Century Antibiotics Gram Negative Antibiotic Gram Positive Antibiotic Plasmid Library Software 21 st Century Antibiotics Gram Negative Antibiotic Gram Positive Antibiotic Plasmid Library Software We can engineer better Gram-negative


  1. 21 st Century Antibiotics Gram Negative Antibiotic Gram Positive Antibiotic Plasmid Library Software

  2. 21 st Century Antibiotics Gram Negative Antibiotic Gram Positive Antibiotic Plasmid Library Software

  3. We can engineer better Gram-negative antibiotics using synthetic biology Engineered probiotic Problems with • traditional antibiotics: activated when pathogen is detected • wipe out normal gut flora • specific for Gram- • taken after symptoms negative organisms are obvious • works before symptoms • widespread resistance • novel therapeutic

  4. Engineered probiotic detects and destroys Gram-negative pathogens anti-toxin toxin Probiotic Detects Pathogen toxin anti-toxin Essential Probiotic Components • Cell chassis • Protein secretion system • Inducible toxin/antitoxin system Probiotic Expresses Toxin and Antitoxin anti-toxin toxin X Probiotic Secretes Toxin

  5. The Type VI Secretion System punctures the cell wall of target Gram-negative cells and injects proteins T6SS bacteria cytoplasm target bacteria cytoplasm

  6. The Type VI Secretion System punctures the cell wall of target Gram-negative cells and injects proteins T6SS bacteria cytoplasm target bacteria cytoplasm

  7. Fosmid containing T6SS does not express in E. coli Promoter Region 50kb Type VI Secretion Fosmid

  8. Engineered fosmid directs expression of the T6SS in E. coli P. aeruginosa E. coli E. coli Uninduced Induced Type VI Type VI Protein Protein in E. coli Positive Control protein

  9. Tse2Tsi2 is a toxin/antitoxin system recognized by the T6SS

  10. Toxin/Antitoxin is induced in response to an example bacterially-produced small molecule BioBrick F2620 Toxin/Antitoxin Operon Image created via TinkerCell

  11. Toxin/Antitoxin is induced in response to an example bacterially-produced small molecule BioBrick F2620 Toxin/Antitoxin Operon

  12. Engineered probiotic detects and destroys Gram-negative pathogens anti-toxin toxin Probiotic Detects Pathogen toxin anti-toxin Essential Probiotic Components  Expressed Type VI secretion in E. coli, fosmid available  Characterized, BioBricked and submitted Tse2/Tsi2 Probiotic Expresses Toxin and Antitoxin anti-toxin toxin X Probiotic Secretes Toxin

  13. 21 st Century Antibiotics Gram Negative Antibiotic  Characterized, BioBricked, and submitted Tse2/Tsi2  Submitted Fosmid containing T6SS  Expressed Type VI secretion in E. Coli Gram Positive Antibiotic Plasmid Library Software

  14. No Anthrax (live or dead) was used in this project!

  15. Removing Bacillus anthracis protective coat makes it vulnerable to immune system Protected Anthrax Decapsulation Vulnerable Anthrax

  16. Redesign CapD to break down protective coat Transpeptidation Hydrolysis (Native) (Desired)

  17. * CapD auto-cleaves to reveal active site * CapD Inactive CapD Inactive Enzyme N C * Self Cleavage Active Enzyme * C’ N’ Active Active Enzyme CapD : Key Catalytic Residue N C *

  18. Avoiding auto-cleavage: redesigning CapD to produce enzyme in active state Circular Permutation C * N * Active Inactive CapDCP CapDCP CapD_CP CapD N C Genetically encoded peptide linker : Key Catalytic Residue *

  19. CapDCP is easy to express and quantify! CapD CapDCP * Active Enzyme Inactive Enzyme * Active Enzyme Active Enzyme : Key Catalytic Residue *

  20. CapDCP shows enzymatic activity! CapD CapDCP * Active Enzyme Inactive Enzyme * Active Enzyme Active Enzyme Transpeptidation Hydrolysis k cat� (hr-1) Km� (nM) kcat� (hr-1) Km� (nM) CapD 27.2� ± � 1.5 22.1� ± � 2.9 1.8� ± � 0.3 2.4� ± � 1.4 CapD_CP 67.2� ± � 7.5 23.2� ± � 5.4 4.0� ± � 0.1 0.6� ± � 0.1 : Key Catalytic Residue *

  21. Using FoldIt to design a better anthrax destroyer Mutate FoldIt: Developed by the Baker and Popović Labs at the University of Washington

  22. Designed, built, & tested 87 variants 1.4 Succeeded in altering the reaction specificity 1.2 Transpeptidation Relative to CapD_CP CapD_CP CapDCPNFDelta 1 L40W T20S, L40D N23K 0.8 T20S F24Y S143K 0.6 CapD T20S, L40R, N81Q L40R 0.4 T20S,T59S_M61S M61S T20S, L40F T59N L40S L40A 0.2 F24H, R356K F24H T20C F24H, L40R, Improved T2S T59N_M61S T2V Variant 0 0 0.2 0.4 0.6 0.8 1 1.2 1.4 Hydrolysis Relative to CapD_CP

  23. Michaelis-Menten profile shows 10 fold switch in reaction specificity

  24. 21 st Century Antibiotics Gram Negative Antibiotic  Characterized, BioBricked, and submitted Tse2/Tsi2 c  Submitted Fosmid containing T6SS  Expressed Type VI secretion in E. Coli Gram Positive Antibiotic  Created and characterized 87 CapD_CP mutants  BioBricked and submitted CapD, CapD_CP, and best variant  Collaboration to test best variant on live Anthrax Plasmid Library Software

  25. 21 St Century Antibiotics Gram Negative Antibiotic  Characterized, BioBricked, and submitted Tse2/Tsi2  Submitted Fosmid containing T6SS  Expressed Type VI secretion in E. Coli Gram Positive Antibiotic  Created and characterized 87 CapD_CP mutants  BioBricked and submitted CapD, CapD_CP, and best variant  Collaboration to test best variant on live Anthrax Plasmid Library Software

  26. Protein Expression Vectors

  27. Protein Expression Vectors pSB3K3 + pSB3K3 f1 origin 3kb 2 kb 1.5 kb

  28. psb1A3 expression cassettes with gfp

  29. WikiDust makes interactive diagrams that link directly to the parts registry TinkerCell developed by the Sauro Lab at the University of Washington WikiDust

  30. PartsRobot simplifies the BioBrick submission process PartsRobot

  31. 21 st Century Antibiotics Gram Negative Antibiotic  Characterized, BioBricked, and submitted Tse2/Tsi2  Submitted Fosmid containing T6SS  Expressed Type VI secretion in E. Coli Gram Positive Antibiotic  Created and characterized all CapD_CP mutants  BioBricked and submitted CapD, CapD_CP, and best variant  Collaboration to test best variant on live Anthrax Plasmid Library  3 New BioBricks (F1 origin, new LacI, new T7 promoter)  4 New BioBrick protein expression cassettes  Characterized existing Registry promoters Software  WikiDust Allows users to quickly generate diagrams that link to the parts registry – BBF RFC 68  PartsRobot simplifies registry submission process

  32. Acknowledgements from the 2010 UW iGEM Undergrads Faculty Space Donations • David Baker • Alan Weiner • Joseph Mougous • Dominic Chung • Herbert M Sauro • Ling Liu • Eric Klavins Advisors UW Microbiology Department • Ingrid Swanson UW Biochemistry Department • Michal Galdzicki UW MCB Department • Justin Siegel Arthur Friedlander at USAMRIID • Josh Bishop Michael Jacobs at UW • Matthew Smith • Rob Egbert • Jeremy Mills • Deepak Chandran • Joe Harrison

  33. Questions? Gram Negative Antibiotic  Characterized, BioBricked, and submitted Tse2/Tsi2  Submitted Fosmid containing T6SS  Expressed Type VI secretion in E. Coli Gram Positive Antibiotic  Created and characterized all CapD_CP mutants  BioBricked and submitted CapD, CapD_CP, and best variant  Collaboration to test best variant on live Anthrax Plasmid Library  3 New BioBricks (F1 origin, new LacI, new T7 promoter)  4 New BioBrick protein expression cassettes  Characterized existing Registry promoters Software  WikiDust Allows users to quickly generate diagrams that link to the parts registry – BBF RFC 68  PartsRobot simplifies registry submission process

  34. Assay utilizes synthetic fluorescent peptide Q F F PDG Linker Q Catalytic knockout confirms active site chemistry

  35. Mass Spec Verifies Start Methionine Removed Expected weight of CapD_CP without Methionine=55285Da, with Methionine=55417Da. Our mass spec detected a peak at 55274.8Da (no Methionine) well within the 0.02% error limit for our mass spec

  36. Circular Permutation ~526 351 526 Linker 1 1 352

  37. Notes • Pixilate PacMan • Switch focus to removing tarnspeptidation not increasing hydrolosys • Get new protein expression efficiency • Change anthrax slide to get rid of mariners and Yankees

  38. Tse2 toxicity
