MERDBASERT AKVAKULTUR 2011/2012-N Cage Farming Aquaculture 2011 2012 AKVA group-Cage Farming-N-08.11 w w w .akvagroup.com
A new role based control system... - dedicated information to relevant user Dedicated access... Exam ple roles... Within the organization, roles are created for various job functions and This is the highest level of the permissions to perform certain opera- hierarchy providing access to tions are assigned thereafter. all levels of the company. When a user is set-up in the system All production data compiled and assigned a role, a set of functions, is to show key information. are automatically made accessible. This level provides a fast over- • Automatic functionality is set-up view of the present situation Production of user level access and vector of development. Managem ent • Automatic set-up of external Full access to all sites and systems. Automatically calculated KPI’s. All production data in one database. alarm system • Automatically define relevant inform ation for the roles Com m unication clients iControl provides the site management team with iControl is a multiplatform system detailed information about that provides monitoring and control the operational status. access to the operation through a All subsystems of can easily set of communication clients such as be evaluated, compared your mobile phone. and analyzed. Site Manager Real-time performance check. Easy navigation and production control. Full customization of modules. iControl gives farm technicans dedicated logging and control of physical parameters that Desktop client may infmuence fjsh welfare, thus allows fast reaction to scenarios falling outside the normal production. Farm Technician Intelligent alarm and event system. Full control of light and feed systems. Manage and control all cameras. W eb client Mobile client Personal access rights iControl provides the maintanace All user have a personal user account team with dedicated logging of where they are able to defjne access all parameters associated with rights, language settings and what the equipment on site. information is displayed in the system. Maintenance Manager Monitor the status of all equipment. Proactive maintenance planning. Production environment analysis. 18 19
Cages - the world´ s leading cage supplier AKVA group is the world’s leading supplier of both plastic and steel cages. Polarcirkel, the most recognized brand in aquaculture, invented the plastic cage concept in Norway in 1974, and has since supplied more than 42,000 cages worldwide. The renowned Wavemaster steel cages originated in Ireland in 1985, and more than 12,000 cages have since been delivered globally. In order to ensure the highest possible quality, competitive pricing and on-time deliveries, the cages and components are manufactured in many different regions. All cages are installed by professional installation teams, and serviced by professional AKVA group service technicians. AKVA group invests heavily in innovative and professional R&D in order to remain the leading supplier of cages; not only to improve products in the short term, but also to look into the future of tomorrow’s demands for cage technology. w w w .akvagroup.com 28 29
All-Plastic-Cages: A well proven concept in Polarcirkel Cages flexible cage design for extreme conditions... Experience is a crucial success factor in the fish farming business. AKVA group (Polarcirkel) invented the plastic cage in 1974, and has since supplied more than 42.000 Polarcirkel Cages and 12.000 Polarcirkel Boats. The cages are made from raw materials especially suited for the dynamic loads of the sea, and are available in a wide range New PIM Bracket design provides of models, shapes and sizes to suit superior strength. individual needs. Strong and rigid HDPE Many have tried to copy these products, hand rails. but none have managed to match the genuine Polarcirkel designs and quality builds. Plastic cages started out as small single pipe circles, but now our largest models approach 200m circumference, and with floating pipes of 500mm diameter. Both circular and square cage systems are available. Combined with AKVA group´ s global sales and service network, the The Polarcirkel cages Polarcirkel Cage is well proven and include smart solutions for A secondary redundancy recognized worldwide. fully integrated walkways, safety chain placed inside sinker tube systems, safety the outer floating pipe is Safe Polarcirkel w alkw ays floatation and system optional. redundancies. In order to increase crew safety on fish farms, another Polarcirkel innovation was launched in 1999; the integrated Polarcirkel quality and certifjcation Polarcirkel Walkways. The anti-skid All Polarcirkel Cages are manufactured and assembled walkway panels fit securely between in accordance with AKVA group’s Quality Assurance the two floating pipes, forming a System (ISO 9001) which is certifjed by DNV stable and safe working surface. (Det Norske Veritas). All cages in Norway are designed The PE pressure moulded panels are in accordance with NS9415 (Norwegian Standard 9415 held in place with strong and flexible for cage farming equipment to prevent fjsh escape). continuous PE tubing inter-locking the panels to the PIM brackets. Polarcirkel Cage History Polarcirkel 500mm cage - a safe and Newspaper photo presenting the Photos showing today’s large 500mm stable platform designed for extreme first Polarcirkel cage in 1974. cages compared to the 225mm “Gigante” cage 15 years ago! weather conditions. 31 30
Polarcirkel cage sizes Polarcirkel Cages - designed for rough conditions... The most popular models are the circular cages in 315, Strong Polarcirkel PI M Brackets 400, 450 and 500mm floating pipes with circumferences Extensive use of PE (Polyethylene) in our PIM (Pressure Injection from 90-160m. Moulded) brackets eliminates corrosion, minimizes expensive and difficult maintenance, and substantially increases cage lifespan compared to steel brackets. This is especially important in areas with high salinity, warm water temperatures and choppy seas. Only strong and high quality PE is used for Polarcirkel brackets, while many suppliers use weak and low quality rotationally moulded Medium and Low Density Polyethylene. This makes the Polarcirkel brackets superior in terms of structural strength, durability and UV resistance. This is especially important in high energy offshore farm sites and areas with high UV radiation from the sun. For areas prone to icing, such as Norway and Canada, another critical advantage of the Polarcirkel HDPE brackets is that they will not ice up as steel brackets do. Icing is a dangerous safety problem for all floating structures, including cages. Heavy ice overloads the cage, reduces Proven Sinker Tube concept stability and jeopardizes overall cage integrity. As the name indicates, As cages grew bigger and nets became the Polarcirkel cages are well suited for extreme arctic conditions! harder and harder to control in strong All Polarcirkel Cage designs are carried out by our professional R&D currents, Polarcirkel invented the sinker department. Independent marine engineering consultants are also tube concept in 1989. A concept that involved in advanced static and dynamic load calculations to ensure all later has been adopted as an industry standard. The Polarcirkel Sinker Tube designs meet or exceed expected real life loads as well as applicable consists of a 200-280mm heavy walled industry standards. PE pipe filled with steel wires (typically 20-70 kg/ m). It is supported by strong ropes fastened through the stainless steel sleeve in the PIM brackets. Polarcirkel PIM-500 Bracket Long life - built to withstand extreme conditions above and below the surface Forget corrosion! Photo showing Polarcirkel cages are known for their AKVA groups proven sinker tube system A wide range of flexible Polarcirkel All the weight of the net and sinker When harvesting, the net volume is uses a vertical rope. No metal parts, a Polarcirkel bracket after ten years cages are designed for extreme weather strong railings and high reserve buoyancy, tube system is supported by the reduced by lifting vertical ropes of the which is crucial in case of sudden such as chain and shackles, can there- in saltwater! conditions, such as here on Norway’s floating pipe - NOT by the handrail. sinker tube system. This leaves fore cause damage to the net. stormy coastline at 70° North. excessive net loads or icing. no load on the handrails. 33 32
