by 2 wires digital intercom October 2016 April 2015
Specification & features. Capacidad del sistema: Outdoor units. Digital repeater. Summary Indoor units. Kits range. ++Modules. Diagrams.
Specification & features
Specification Characteristics: Características principales: - Digital transmission of audio, video and data. - 2 wires, non polarized BUS. - Up to 32 (23) monitors in a system (expandable using RD-GB2). - Up to 4 entry panels Nexa. - Up to 200 meters distance: from panel to last monitor. - Suitable for retrofit, very flexible with cable type. - Easy to program through dip switches. Benefits: Saves time and installation mistakes. Installation costs saving. More profit for all parties.
Specification Units System INTERCOM Memory RING TONES CALL module LANGUAGE FORWARD LAND LINE MEMORY Extra Panel/camer Image cameras CALL FORWARD as self Video GSM activation Bus relay
Outdoor panels
Nexa Panels Nexa code Nexa inox JAZZ Nexa aluminium Surface villa panel
Nexa Panels Characteristics: - Inox and aluminium versions available, from Nexa series. - Single or double buttons. Permanent light on name tags. - Visual signalization of panel status for hearing aided people. - Vocal messages in 5 different languages for people with low visión (option to upload custom messages for local languages). - Wide angle camera (105º). - Automatic camera leds activation in low light conditions. - Communication and volume adjustments with no need to open the panel. Call is in progress Communication started Door is open System is busy
Nexa Panels – mechanical parts NEXA Aluminium Mechanical PARTS Embedding box Frames Modules Accessories
Nexa Panels – mechanical parts Assembling
Nexa Panels – mechanical parts NEXA INOX Mechanical PARTS Embedding box Frames Modules Accessories
Nexa Panels – mechanical parts Assembling
Video module – EL632/GB2 Villa Up to 16 monitors per family. Up to 2 family houses. Características principales: - Operative modes Up to 4 monitors per apartment. Building Up to 32 (23) monitors in a system. 18 monitors case of 7 inches. - Door panel code programming, (00-03) through dip switches - 2 relays for door lock. 2 exit buttons input (one per relay). - 12Vdc output to power CV-14/DC door lock. - NO/NC relays. - Plug to connect EL610D module, buttons extension. AP1 - Two call buttons included in the module. EL642/GB2 AP2 audio only, - Wide angle camera (105º). available! - White Leds activated only in low light conditions. In case of using 2 exit - Vocal messages for panel status confirmation. buttons, add one power supply. - Visual signalization of panel status through leds.
Settings- Panels Panel EL632/GB2 Dip 1-2: set panel address. 00 , 01, 02, 03. binary. Dip 3: set double ( Off ) or single (On) button panels. Dip 4: Off in villas, On in buildings. Dip 5: Set door reléase time to 5sec ( On ) or 1 sec (Off). Dip 6: Set to ON to configure vocal message language and relay status, turn back to off after set. Building – single Villa mode Building - double 0 - 1 0 0 16 15 - 31 Dip 1 to 8 define the code of the button, depending on the EL610D EL632/GB2 setting (villa or building – Dip 4).
Settings- Panels Panel connections
Settings- Panels Panel EL610D Dip 1 to 8 define the code of the button.
Configuración Settings- Panels Direcciones módulos EL610D pulsadores doble code 0 code 1 code 1 code 9 code 10 code 10 code 8 code 7 code 8 code 6 code 6 code 5 code 4 code 4 code 3 code 2 code 2 code 11
Configuración Settings- Panels Direcciones módulos EL610D pulsadores doble code 20 code19 code 20 code 18 code 17 code 18 code 16 code 15 code 16 code 14 code 13 code 14 code 12 Code 21 code 12 code 30 code 29 code 30 code 28 code 27 code 28 code 25 code 26 code 26 code 23 code 24 Code 24 code 22 code 31 Code 22
Configuración Settings- Panels Direcciones módulos EL610D pulsadores individual code 0 code 0 code 5 code 5 code 4 code 4 code 3 code 3 code 2 code 2 code 1 code 1
Configuración Settings- Panels Direcciones módulos EL610D pulsadores individual code 10 code 10 code 9 code 9 code 8 code 8 code 7 code 7 code 6 code 6 code 15 code 15 code 14 code 14 code 13 code 13 code 12 code 12 code 11 code 11
Configuración Settings- Panels Direcciones módulos EL610D pulsadores individual code 20 code 20 code 19 code 19 code 18 code 18 code 17 code 17 code 16 code 16 code 25 code 25 code 24 code 24 code 23 code 23 code 22 code 22 code 21 code 21
Configuración Settings- Panels Direcciones módulos EL610D pulsadores individual code 30 code 30 code 29 code 29 code 28 code 28 code 27 code 27 code 26 code 26 code code code code code code code code code 31 code 31
Video module – EL632/GB2A Visual signals for DDA 105º Camera 3,5 inch TFT display compliance SD card slot Night vision leds Induction loop plug Dip battery Detachable connectors EL610D connector / N3301/GB2 keypad module Push button 1 Push buton 2
Video module – EL632/GB2A Up to 16 monitors per family. Villa Up to 2 family houses. Características principales: Up to 4 monitors per apartment. Building Up to 32 (23/18) monitors in a system. buttons panel Up to 4 telephones per apartment. Building Up to 128 telephones in a system. - Operative modes buttons panel Audio only Up to 4 monitors per apartment. Building Up to 128 monitors in a system. buttons panel RD-GB2 required Mixed system Up to 4 monitors per apartment. Building Up to 256 monitors in a system code panel RD-GB2 required. 32 monitors 256 mixed system router 128 telephones AP1 256 mixed system AP2 Additional characteristics. Gateway - Connector for LCD display module. EL642/GB2 A audio - Connector for N3301/GB2 keypad module. only, available! In case of using 2 exit - Connector for inductive loop module for DDA compliance. buttons, add one power supply.
Video module – EL632/GB2A Procedure to change mode Dip 4 Mode Mode number Operating mode Leds Turn Off 1 PSU OFF Villa P,1 P2 1 Set dip 6 to Off Buttons – 32 units ON Building Audio and video 2 Buttons , 128 telephones, Building ON Turn ON Audio only. PSU Buttons, 128 units. 3 ON Building Audio and video RD-GB2-required Set dip 6 to ON 4 ON Building Buttons, general panel Press P1 for 6 seconds 5 ON Code panel – 32 units Building Audio and video Each press change the 6 ON Code panel , 128 telephones, Building operating mode Audio only. Code panel, 128 units. 7 ON Building Audio and video Set dip 6 to Off RD-GB2-required 8 ON Building Code panel, general panel
Settings- Panels Panel EL610D – Single button Buttons codes EL610D dip switch configuration 0
Settings- Panels Panel EL610D – double button Buttons codes EL610D dip switch configuration 1 0
Kits Jazz Jazz entry panel Presentación Wide angle camera 170º FISH-EYE White leds, automatic activation. Metal rainshield Function Leds Backlit card holder Proximity Access control Metal button (1 or 2 buttons panel) Dimensions : 90(An) x 185(Al) x 24(P) mm
Video module – EL632/GB2A MÓDULOS DIGITALES Presentación Nexa code panel Display Keypad Proxy module Induction loop MÓDULO TECLADO MÓDULO MÓDULO Possible combinations PROXIMIDAD CODIFICADO TFT COLOR 3,5” BUCLE INDUCTIVO
Video module – EL632/GB2A DDA compliance - It exists a long cable to link the video module and the buttons module.
Distances 1 GB2 can reach 200 meters from the entry panel Door panel switcher. up to the latest monitor considering a point to point distance measurement. C Max. distances. B A FA-GB2/A Use RAP-2150 2 wires cable from Golmar to assure the best performance and to reach the maximum D distaces.
Digital repeater
Digital Repeater - Repeater mode. Allow to extend cable lenght twice. RD-GB2 - Router mode. Allows up to 8 risers. Router Repeater Up to riser 8 Riser 3 FA-GB2/A RD-GB2 FA-GB2/A FA-GB2/A RD-GB2 Riser 2 Repeater 2 FA-GB2/A RD-GB2 Riser 1 Riser 2 Riser 3 Riser 1 FA-GB2 FA-GB2/A FA-GB2/A FA-GB2/A FA-GB2/A RD-GB2 2 2 RD-GB2 Up to riser 7 RD-GB2 RD-GB2 FA-GB2/A
Digital Repeater Repeater Door panel switcher. When using a digital repeater RD-GB2, it can be reached up to 280 meters to the last monitor. Monitors placed always after the Digital Repeater***. Vesta2 Vesta2 FA-GB2/A FA-GB2/A RD-GB2 1m 140m 140m
Conexión módulo RD-GB2 amplificador Digital Repeater ESQUEMA Repeater
Digital Repeater Esquema 1 edificio (+32) Router 06 05 04 03 02 01 02 06 05 01 04 03 02 01 ?
Digital Repeater Router Do not connect to ground Connect to ground
Digital Repeater Esquema Placa General (+32) y Parciales (32) Gateway 06 05 06 05 06 05 03 03 04 03 04 04 01 01 02 02 01 02 01 02 ? ? 03 ? ?
Conexión módulo RD-GB2 edificio Digital Repeater ESQUEMA Gateway Do not connect to ground Connect to ground
Conexión módulo RD-GB2 edificio Digital Repeater ESQUEMA Software
Conexión módulo RD-GB2 edificio Digital Repeater ESQUEMA Software
