186 SULLIVAN STREET EXTERIOR WORK APPLICATION LPC 19-38221 May 2, - PowerPoint PPT Presentation

186 SULLIVAN STREET EXTERIOR WORK APPLICATION LPC 19-38221 May 2, 2019 ARMAND LEGARDEUR ARCHITECT 242 West 30th Street, Suite 1500 New Y ork, NY 10001 Existing Conditions Designation Images 186 Sullivan Street May 2, 2019 1 Sullivan


  1. 186 SULLIVAN STREET EXTERIOR WORK APPLICATION LPC 19-38221 May 2, 2019 ARMAND LEGARDEUR ARCHITECT 242 West 30th Street, Suite 1500 New Y ork, NY 10001

  2. Existing Conditions Designation Images 186 Sullivan Street May 2, 2019 1

  3. Sullivan Street - Context Sullivan Street - Context 186 Sullivan Street May 2, 2019 2

  4. 170 Sullivan Street 174 Sullivan Street 178 Sullivan Street 180 Sullivan Street 182 Sullivan Street 184 Sullivan Street MacDougal Street - Context 96 MacDougal Street 92-94 MacDougal Street 88-90 MacDougal Street 186 Sullivan Street May 2, 2019 3

  5. Existing Street Facade Proposed Street Facade 186 Sullivan Street May, 2, 2019 4

  6. Existing Front Door Assembly Proposed Front Door Assembly 186 Sullivan Street May 2, 2019 5

  7. Existing Rear Facade Proposed Rear Facade 186 Sullivan Street May 2, 2019 6

  8. Existing Rear Facades 186 Sullivan Street May 2, 2019 7

  9. Street Facade - Upper Wall SCOPE OF WORK SUMMARY Lulworth Blue F&B No. 89 Street Façade Painting �� Repaint wall to match existing colors: o Upper Wall: Farrow & Ball 89 “Lulworth Blue” o Lower Wall and T rim: Benjamin Moore PM-2 “White” �� Paint entry doorway: o Frame, sidelights and transom: Benjamin Moore PM-2 “White” o Door: Benjamin Moore CC-964 “Blue Grotto” Street Facade - Lower Wall & Trim Rear Façade Painting White �� Wall: Benjamin Moore HC-12 “Concord Ivory” BM PM-2 �� T rim: Benjamin Moore PM-2 “White” Street Facade - Front Door Blue Grotto BM CC-964 Rear Facade - Wall Concord Ivory BM HC-12 Mock-up - Existing/Proposed Street Facade Upper Wall Colors Proposed Paint Colors 186 Sullivan Street May 2, 2019 8
