Will it blend ? Java agents and OSGi Slides revision : 20190923- ea 7 - PowerPoint PPT Presentation

Will it blend ? Java agents and OSGi Slides revision : 20190923- ea 7 c 311 1 Welcome 2 About me 3 Outline Quick demo Java agents primer Usage scenarios OSGi integration Integration testing Testing demo 4 Quick demo 5 Java agents


  1. Will it blend ? Java agents and OSGi Slides revision : 20190923- ea 7 c 311 1

  2. Welcome 2

  3. About me 3

  4. Outline Quick demo Java agents primer Usage scenarios OSGi integration Integration testing Testing demo 4

  5. Quick demo 5

  6. Java agents primer 6

  7. Java instrumentation APIs Provides services that allow Java programming language agents to instrument programs running on the JVM . java.lang.instrument Javadoc , Java SE 8 7

  8. Static agents # loaded at application startup $ java - javaagent : agent . jar - jar app . jar Premain - Class : org . example . my . Agent import java . lang . instrument .*; public class Agent { public static void premain ( String args , ⏎ Instrumentation inst ) { inst . addTransformer ( new ClassFileTransformer () { /* implementation elided */ }); } } 8

  9. Dynamic agents // dynamically attached to a running JVM VirtualMachine vm = VirtualMachine . attach ( vmPid ); vm . loadAgent ( agentFilePath ); vm . detach (); Agent - Class : org . example . my . Agent import java . lang . instrument .*; public class Agent { public static void agentmain ( String args , ⏎ Instrumentation inst ) { inst . addTransformer ( new ClassFileTransformer () { /* implementation elided */ }); } } 9

  10. Class transformation public interface ClassFileTransformer { byte [] transform ( ClassLoader loader , String className , Class < ? > classBeingRedefined , ProtectionDomain protectionDomain , byte [] classfileBuffer ) throws IllegalClassFormatException ; } 10

  11. Java bytecode public static void main ( java . lang . String []); Code : 0: getstatic #16 ⏎ // Field java / lang / System . out : Ljava / io / PrintStream ; 3: ldc #22 ⏎ // String Hello , world 5: invokevirtual #24 ⏎ // Method java / io / PrintStream . println :( Ljava / lang / String ; 8: return 11

  12. Bytecode generation libraries Apache Commons BCEL ByteBuddy CGLib Javassist ObjectWeb ASM 12

  13. Bytecode generation with Javassist public byte [] transform (...) throws ... { ClassPool classPool = ClassPool . getDefault (); CtMethod method = classPool . getMethod ( ⏎ Descriptor . toJavaName ( className ), " main "); method . insertAfter (" System . out . println " + ⏎ "(\"... hello yourself !...\");"); byte [] newClass = method . getDeclaringClass () ⏎ . toBytecode (); method . getDeclaringClass (). detach (); return newClass ; } 13

  14. Usage scenarios 14

  15. When to use agents 1. Code outside of your control 2. No better platform facilities exist 3. ( Usually ) Cross - cutting concerns 15

  16. Agent examples 1. Monitoring ( logging , tracing , error reporting ...) 2. Profiling 3. Debugging 4. Mocking libraries 5. Code reload / Hot swap 16

  17. OSGi integration 17

  18. Mind the classloader - ClassPool defaultPool = ClassPool . getDefault (); - CtClass cc = defaultPool . get ( ⏎ - Descriptor . toJavaName ( className )); + ClassPool classPool = new ClassPool ( true ); + classPool . appendClassPath ( new LoaderClassPath ( loader )); + classPool . insertClassPath ( new ByteArrayClassPath ( ⏎ + Descriptor . toJavaName ( className ), classfileBuffer )); 18

  19. Carefully manage dependencies New requirements typically fail since they are not defined by the bundle Bundles can be processed at build - time Patching Import - Package DynamicImport-Package: * 19

  20. OSGi alternatives - Weaving Hooks  Simplified deployment - OSGi bundle  Simple registration via OSGi whiteboard  Handles updated bundle package imports  OSGi - only solution 20

  21. Integration testing 21

  22. Packaging challenges Java agents ... must be packaged as a Jar file , with a specific manifest not trivially attached to the current process usually a one - way deal , no support for rolling back class changes 22

  23. Custom test launchers " unit " tests launch Java process with custom agents attached require separate communication channel with java agent no out - of - the - box support for code coverage and other tools 23

  24. Bootstrapping the test // 1. which java ? String javaHome = System . getProperty (" java . home "); Path javaExe = Paths . get ( javaHome , " bin ", " java "); // 2. which jar ? String ja = findAgentJar (); // 3. which classpath ? String classPath = buildClassPath (); // 4. launch ProcessBuilder pb = new ProcessBuilder ( javaExe . toString (), "- javaagent :" + ja , "- cp ", classPath , TestApplication . class . getName () ); 24

  25. Verifying side e ff ects Path stdout = Paths . get (" target ", " stdout . txt "); Path stderr = Paths . get (" target ", " stderr . txt "); pb . redirectInput ( Redirect . INHERIT ); pb . redirectOutput ( stdout . toFile ()); pb . redirectError ( stderr . toFile ()); 25

  26. Adding code coverage ProcessBuilder pb = new ProcessBuilder ( javaExe . toString (), "- javaagent :" + codeCoverageAgent , "- javaagent :" + ja , "- cp ", classPath , TestApplication . class . getName () ); 26

  27. OSGi integration testing // note - must run in a forked container @ RunWith ( PaxExam . class ) public class OsgiIT { @ Configuration public Option [] config () throws IOException { return options ( junitBundles (), ⏎ vmOption ("- javaagent :" + agentJar ) ); } @ Test public void callTimesOut () throws IOException { assertTrue ( agentReallyWorks ()); } } 27

  28. Testing demo 28

  29. Resources https :// docs . oracle . com / javase /8/ docs / api / java / lang / instrum summary . html https :// www . javassist . org / https :// sling . apache . org / documentation / bundles / connectio agent . html 29

  30. 30
