  1. Week 9 - Monday

  2.  What did we talk about last time?  Mipmapping  Summed area tables  Anisotropic filtering

  3.  We have been using BasicEffect to achieve most of our shading  BasicEffect gets so much done that it's tempting not to move any further  But more complex effects can be achieved by writing shader code ourselves  To start, open up the MonoGame pipepline, right-click on the Content folder, and choose Add > New Item  Choose Effect from the wizard and name it something that ends with .fx

  4.  We need to declare the variables we are going to use at the top of the file  These usually include at least the following (which are already given in the template) float4x4 World; float4x4 View; float4x4 Projection; float4x4 WorldInverseTranspose;  We're also going to add an ambient and diffuse light float4 AmbientColor = float4(1, 1, 1, 1); float AmbientIntensity = 0.1; float4 DiffuseLightDirection = float4(0.7071f, 0.7071f, 0, 0); float4 DiffuseColor = float4(1, 1, 1, 1); float DiffuseIntensity = .5;

  5.  We also have to define structures to take the input and the output  These vary because different vertex formats include different data (position, normals, colors, texture coordinates) struct VertexShaderInput { float4 Position : POSITION0; float4 Normal : NORMAL0; }; struct VertexShaderOutput { float4 Position : POSITION0; float4 Color : COLOR0; };  The simplest possible input and output would have position only  The POSITION0 is called a semantic  Semantics are used to tell the shader what the purpose of a variable is so that it can pass the right data in and out

  6.  The job of the vertex shader is, at the very least, to transform a vertex from model space to world space to view space to clip space  It can also do normal and color calculations VertexShaderOutput VertexShaderFunction(VertexShaderInput input){ VertexShaderOutput output; float4 worldPosition = mul(input.Position, World); float4 viewPosition = mul(worldPosition, View); output.Position = mul(viewPosition, Projection); float4 normal = mul(input.Normal, WorldInverseTranspose); float lightIntensity = dot(normal, normalize(DiffuseLightDirection)); output.Color = saturate(DiffuseColor * DiffuseIntensity * lightIntensity); return output; }

  7.  The pixel shader must find the final color of the pixel fragment  This pixel shader uses a diffuse shading model  The computed lighting is added to the ambient lighting float4 PixelShaderFunction(VertexShaderOutput input) : COLOR0 { return saturate(input.Color + AmbientColor * AmbientIntensity); }

  8.  You're allowed to name your vertex and pixel shaders anything you want  You specify which you're going to use in a technique  At this level, techniques only have one pass, but it is possible to use multiple techniques to achieve interesting effects technique Diffuse { pass Pass1 { VertexShader = compile VS_SHADERMODEL VertexShaderFunction(); PixelShader = compile PS_SHADERMODEL PixelShaderFunction(); } }

  9.  You have to load the shader like other content effect = Content.Load<Effect>("Diffuse");  Then, we run a loop similar to the earlier one, setting the parameters for the effect object foreach( ModelMesh mesh in model.Meshes ) { foreach (ModelMeshPart part in mesh.MeshParts) { part.Effect = effect; effect.Parameters["World"]. SetValue(mesh.ParentBone.Transform * world); effect.Parameters["View"].SetValue(view); effect.Parameters["WorldInverseTranspose"]. SetValue(Matrix.Transpose(Matrix.Invert(mesh.ParentBone.Transform * world))); effect.Parameters["Projection"]. SetValue(projection); } mesh.Draw(); }

  10.  Image textures are the most common, but 3D volume textures can be used  These textures store data in a ( u , v , w ) coordinate space  Even volume textures can be mipmapped  Quadrilinear interpolation!  In practice, volume textures are usually used for fog, smoke, or explosions  3D effects that are inconsistent over the volume

  11.  A cube map is a kind of texture map with 6 faces  Cube maps are used to texture surfaces based on direction  They are commonly used in environment mapping  A ray is made from the center of the cube out to the surface  The component with the largest magnitude selects which of the 6 faces  The other components are used for ( u , v ) coordinates  Cube maps can cause awkward seams when jumping between faces

  12.  You will never need to worry about this in this class, but texture memory space is a huge problem  There are many different caching strategies, similar ones used for RAM:  Least Recently Used (LRU) : Swap out the least recently used texture, very commonly used  Most Recently Used (MRU) : Swap out the most recently used texture, use only during thrashing  Prefetching can be useful to maintain consistent frame rates

  13.  JPEG and PNG are common compression techniques for regular images  In graphics hardware, these are too complicated to be decoded on the fly  That's why the finished MonoGame projects have pre-processed .tkb files  Most DirectX texture compression divides textures into 4 x 4 tiles  Two 16-bit RGB values are recorded for each tile  Each texel uses 2 bits to select one of the two colors or two interpolated values between them

  14.  Ericsson texture compression (ETC) is used in OpenGL  It breaks texels into 2 x 4 blocks with a single color  It uses per-pixel luminance information to add detail to the blocks  Normal maps (normals stored as textures) allow for interesting compression approaches  Only x and y components are needed since the z component can be calculated  The x and y can then be stored using the BC5 format for two channels of color data

  15.  A procedural texture is made by computing a function of u and v instead of looking up a texel in an image  Noise functions are often used to give an appearance of randomness  Volume textures can be generated on the fly  Values can be returned based on distance to certain feature points (redder colors near heat, for example)

  16.  Textures don't have to be static  The application can alter them over time  Alternatively, u and v values can be remapped to make the texture appear to move  Matrix transformations can be used for zoom, rotation, shearing, etc.  Video textures can be used to play back a movie in a texture  Blending between textures can allow an object to transform like a chameleon

  17.  The lighting we have discussed is based on material properties  Diffuse color  Specular color  Smoothness coefficient m  A texture can be used to modify these values on a per-pixel basis  A normal image texture can be considered a diffuse color map  One that affects specular colors is a specular color map (usually grayscale)  One that affects m is a gloss map

  18.  Alpha values allow for interesting effects  Decaling is when you apply a texture that is mostly transparent to a (usually already textured) surface  Cutouts can be used to give the impression of a much more complex underlying polygon  1-bit alpha doesn't require sorting  Cutouts are not always convincing from every angle

  19.  Bump mapping  BRDFs

  20.  Make sure you're solid on bump mapping from Chapter 6  Read Chapter 7 (at a high level)  Finish Assignment 3  Due tonight by midnight!  Work on Project 2
