WATER PARK SLIDES 340 www.proteam-me.com
Free fall water slides 343 Open & closed turning slide 344 High speed float slides 345 High speed open & colosed slides 346 Water play station 347 Multi racer slides 350 Thriller slides 351 Funnel Slides 352 Spider Slides 353 341 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES WATER PARK SLIDES WATER PARK SLIDES 49 th We offer the widest range of water park equipment and introduce the latest technology Years and innovative products. of Excellence WE PROVIDE International quality at competitive price Customized and innovative designs Assured quality and on time delivery Personalized service Guaranteed customer satisfaction COMPLETE SOLUTION •Designing and planing •Themetization •Consulting •Manufacturing •Installation •After Sale Services •Turnkey Development 342 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES FREE FALL WATER SLIDE FREE FALL WATER SLIDE 49 Width of slide 0.92 m th Height 6m-18m Years of No of rider 1 Excellence Rider capacity 150to 270/h Transport Medium Body Exit Pool/Sofa landing Water Requirement 1500LPM 848 3 6 5 921 710 BODY WAVE SLIDES BODY WAVE SLIDES Width of slide 0.92 m Height 6m-18m No of rider 1 Rider capacity 150to 270/h Transport Medium Body Exit Pool/Sofa landing Water Requirement 1500LPM 343 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Open body turning slide OPEN BODY TURNING SLIDE 49 th Years Width of slide 0.92 m of Excellence Height 3m-12m No of rider 1 Rider capacity 150to 270/h Transport Medium Body Exit Pool/Sofa landing Water Requirement 1500LPM 848 3 6 5 921 710 850 BODY TUNNEL SLIDE Width of slide 0.87 m 5 2 Height 3m-12m 4 No of rider 1 Rider capacity 150to 270/h Transport Medium Body 920 Exit Pool/Sofa landing Water Requirement 1500LPM 0 2 9 344 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES High speed float slides HIGH SPEED FLOAT SLIDES 49 th Width of slide 1.4m Years of Height 9m-18m Excellence No of rider 1-2 Rider capacity 240to 340/h Transport Medium Float Exit Pool/Sofa landing Water Requirement 2500LPM 1400 700 1400 300 345 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES High Speed Open and closed float slide 49 th HIGH SPEED OPEN AND CLOSED FLOAT SLIDE Years of Excellence Width of slide 1.3m Height 9m-18m No of rider 1-2 Rider capacity 150to 250/h Transport Medium Float Exit Pool/Sofa landing Water Requirement 2500LPM 1800 2438 0 1400 1800 0 460 9 0 0 0 0 1400 7 9 1400 300 0 0 7 850 BODY BOWL TORNADO Width of slide 0.87m Dia of bowl 6.2m Height 6m-9m No of rider 1 Rider capacity 150/h 425 Transport Medium Body Exit Pool Landing Water Requirement 2500LPM FAMILY SLIDE Width of slide 2.4m Height 3m-6m No of rider 4-8 Rider capacity 240-300/h Transport Medium Body Exit Pool Landing Water Requirement 1500LPM 346 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Water Play Station WATER PLAY STATION 49 th SIGNATURE Years of Excellence Age Group 5-60 Years Equipment and area 39m-42m Minimum pool area 42m/45m Maximum slide elevation 10.1 Maximum structure elevation 13.1 No of slide 9 Total feature including jets 200 Minimum Required water flow 20,000LPM 347 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Water Play Station WATER PLAY STATION 49 th 1 PLATFORM Years of Excellence Age Group 3-12 Years Equipment and area 7m-5m Minimum pool area 10m/8m Maximum slide elevation 1.05 Maximum structure elevation 6m No of slide 2 Total feature including jets 5 Minimum Required water flow 1500 LPM 2 PLATFORM Age Group 3-12 Years Equipment and area 13m-6m Minimum pool area 16m / 9m Maximum slide elevation 2.1 Maximum structure elevation 5.1m No of slide 3 Total feature including jets 8 Minimum Required water flow 3000 LPM 348 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Water Play Station 49 7 PLATFORM th Years Age Group 5-60Years of Excellence Equipment and area 23m-14m Minimum pool area 26m / 17m Maximum slide elevation 6.3m Maximum structure elevation 9.3m No of slide 5 Total feature including jets 55 Minimum Required water flow 10,000 LPM 8 PLATFORM Age Group 5-60Years Equipment and area 27m-18m Minimum pool area 30m / 21m Maximum slide elevation 5.2m Maximum structure elevation 8.2m No of slide 6 Total feature including jets 60 Minimum Required water flow 12000 LPM 12 PLATFORM Age Group 5-60Years Equipment and area 28m-28m Minimum pool area 31m / 31m Maximum slide elevation 6.3m Maximum structure elevation 9.3m No of slide 8 Total feature including jets 75 Minimum Required water flow 12000 LPM 349 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Multi racer slide 49 MULTI RACER SLIDE th Years Width of slide 0.67m of Excellence No of Lanes 3-7 Height 9-12m No of rider 1 per lane Rider capacity 10-120 per lane Transport Medium Head first matt Exit Pool sofa landing Confirms ASTM/EN Water Requirement per lane 1000LPM 650 5 2 2 350 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Thriller Slide 49 THRILLER SLIDE th Years Width of slide 3m of Excellence Height 9-18m 3000 No of rider 4 per lane Rider capacity 170-270 per lane 0 0 0 Transport Medium Raft 1 Exit Pool sofa landing Water Requirement Per lane 3500LPM 3000 1000 351 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Funnel Slide 49 FUNNEL SLIDE th Years Width of slide 12m of Excellence Height 9-18m 1400 No of rider 2 per lane Rider capacity 150-270 per lane 300 Transport Medium Raft Exit Pool sofa landing Water Requirment Per lane 3000LPM 1400 0 0 7 352 www.proteam-me.com
WATER PARK SLIDES WATER PARK SLIDES Spider Slide 49 SPIDER SLIDE th Years Width of slide 0.91m of Excellence Height 9-18m No of rider 1 per lane Rider capacity 170-270 per lane Transport Medium Matt / Head down first Exit Pool sofa landing Water Requirment Per lane 1500LPM 850 650 850 THUNDER BOWL Width of slide 1.3m Dia of Bowl 12m Height 12-15m No of rider 2 Rider capacity 240-300/hr Transport Medium Float Exit Pool sofa landing Water Requirment Per lane 8000LPM 353 www.proteam-me.com
