Using NVIDIA Index in ALYA MultiPhysics Christopher Lux (NV), Vishal - PowerPoint PPT Presentation

www.bsc.es Interactive HPC: Large Scale In-Situ Visualization Using NVIDIA Index in ALYA MultiPhysics Christopher Lux (NV), Vishal Mehta (BSC) and Marc Nienhaus (NV) May 8 th 2017 Barcelona Supercomputing Center Marenostrum 4 13.7


  1. www.bsc.es Interactive HPC: Large Scale In-Situ Visualization Using NVIDIA Index in ALYA MultiPhysics Christopher Lux (NV), Vishal Mehta (BSC) and Marc Nienhaus (NV) May 8 th 2017

  2. Barcelona Supercomputing Center Marenostrum 4 • 13.7 PetaFlop/s • General Purpose Computing ▪ 3400 nodes of Xeon, 11 PF/s • Emerging Technologies ▪ Power 9 + Pascal  1.5 PF/s ▪ Knights Landing and Knights Hill  0.5 PF/s ▪ 64bit ARMv8  0.5 PF/s 2

  3. Research at BSC EARTH SCIENCES COMPUTER SCIENCES To influence the way To develop and implement machines are built, global and regional state- programmed and used: of-the-art models for short- programming models, performance tools, Big Data, term air quality forecast computer architecture, energy and long-term climate efficiency applications LIFE SCIENCES CASE To develop scientific and To understand living engineering software to organisms by means of efficiently exploit super- theoretical and computing capabilities computational methods (biomedical, geophysics, atmospheric, energy, (molecular modeling, social and economic genomics, proteomics) simulations) 3

  4. ALYA System: Large Scale Computational Mechanics 4

  5. 5

  6. ALYA HPC Context 6

  7. ALYA HPC Context 7

  8. ALYA RED 8

  9. Computational Cardiac Model Applications ▪ Pacemaker applications ▪ Computational analysis of malfunctioning tissue patches ▪ Computational Drug testing on cardiac tissue. 9

  10. Computational Cardiac Model 10

  11. Pacemaker Application 11

  12. Pacemaker Application 12

  13. Computational Drug Testing 13

  14. INTERACTIVE HPC: LARGE SCALE IN-SITU VISUALIZATION USING NVIDIA INDEX IN ALYA MULTIPHYSICS Christopher Lux (NV), Vishal Mehta (BSC) and Marc Nienhaus (NV) May 8 th 2017

  15. NVIDIA INDEX Scalable, Interactive Visual Computing GPU-cluster aware solution High-quality and scalable visualization of large-scale datasets In-situ visualization Commercial software Available and deployed in production 15

  16. SCALABILITY AS ENABLER NVIDIA HPC Clusters NVIDIA Quadro VCA or DGX-1 NVIDIA Quadro Workstation Performance, dataset size, number of pixels, visual quality … 16

  17. Scientific Data Visualization 17

  18. Time-Varying Data Visualization 18

  19. Time-Varying Data Visualization Simulation data source: A Numerical Study of High-Pressure Oxygen/Methane Mixing and Combustion of a Shear Coaxial Injector , 19 Nan Zong & Vigor Yang, AIAA 2005

  20. In-Trans and In-Situ Visualization 20

  21. Computational Heart 21

  22. BACKGROUND 22

  23. DISTRIBUTED PARALLEL RENDERING Sort-Last Rendering (multi-GPU) [..] [..] * image compositing 23

  24. DISTRIBUTED PARALLEL RENDERING Sort-Last Rendering (Cluster of multi-GPU Nodes) Cluster of VCAs [..] [..] * image compositing 24

  25. DISTRIBUTED DATATYPES Various Application Domains Volume datatypes Regular ▪ Sparse ▪ ▪ Unstructured/Irregular Surface-geometry datatypes ▪ Height field Triangle mesh ▪ 25

  26. IN-TRANS AND IN-SITU VISUALIZATION 26

  27. TRADITIONAL VISUALIZATION PIPELINE Simulation Cluster NVIDIA IndeX Visualization Data Storage Cluster e.g. Unstructured Data 5/15/2 27 017

  28. TIME-SERIES DATA VISUALIZATION Visualize Pre-calculated ALYA Simulation Results Visualize and Animate Stream Interact and Explore Terabyte time-varying simulation data of nasal system 28

  29. IN-SITU (IN-TRANS) VISUALIZATION PIPELINE Unstructured Data Unstructured Data Unstructured Data Simulation Cluster NVIDIA IndeX Visualization Network Cluster 29

  30. IN-SITU VISUALIZATION PIPELINE Combined Simulation and Visualization Cluster 5/15/2 30 017

  31. IN-SITU/IN-TRANS SUPPORT Compute Result Integration Parallel jobs executed locally or remotely Direct access to local host and device data Fast RDMA memory transfers User-defined affinity and spatial subdivision Application-driven updates Push updated data when ready ▪ Rendering-driven updates ▪ Request computation updates for active data 31 Clustered neuron activity

  32. IN-TRANS RESULT TRANSFERS Fast Data Transfers to Rendering Nodes/GPUs Page-Locked System Page-Locked System Memory Memory RDMA (over InfiniBand) CUDA GPU CUDA GPU Memory Memory GPUDirect RDMA NVLink high-speed interconnect between system memory and GPU (IBM and NVIDIA) 32

  33. COMPUTATIONAL HEART In-Situ Simulation and Visualization Simulate/Compute Visualize (ALYA) Interact and Parameterize and Explore Steer 33

  34. NVIDIA INDEX AVAILABILITY 34

  35. NVIDIA INDEX 1.4 In-Situ/In-Trans Visualization Support Support of 32bit, 16bit, 8bit fixed point, 32bit floating point and RGBA (8bit) regular volumes Dynamic streaming and GPU caching of time-varying volume data Irregular volumes and sparse volumes Built-in volume shading capabilities Multi-view capabilities NVIDIA IndeX 1.4 Zero-copy RDMA/GPUDirect compute integration infrastructure (released 07/2016) User-defined affinity and spatial subdivision support Architecture and API for in-situ/in-trans visualization (compute integration) Dynamic workload balancing Advanced CUDA memory management, error handling and logging MPI/NVIDIA IndeX interprocess coupling (CUDA IPC and shared memory) 35

  36. NVIDIA INDEX 1.5 OUTLOOK User-defined Rendering Kernel Components 36

  37. NVIDIA INDEX 1.5 OUTLOOK User-defined Rendering Kernel Components 37

  38. IN-SITU VISUALIZATIONS 38

  39. Challenges Simulation Index Rendering MPI MPI • Parallel Operations • Maintain frame rates • Steering Simulation MPI MPI • Data Affinity . . • Render @compute Cubical Scene region . . Unstructured Mesh • In-trans approach Even spatial partitions Uneven Spatial partitions Balanced rendering load Balanced computations MPI MPI 39

  40. Multi-code Coupling in ALYA • All spatial interpolation on spatial domain in structured and unstructured meshes • Allows setting send and receive frequencies to synchronize simulation times. • Allows coupling with third party codes • Parallel and Asynchronous MPI coupling 40

  41. Ingredients of Coupling in ALYA mpirun -np 8 Alya.x fluid : -np 4 Test.x : -np 4 Alya.x solidz • WHAT  The underlying variables • WHERE  Surface, Volume, etc. • WHEN  Time step, iteration step • HOW  Algorithmic interpolation 41

  42. Coupling for IN-SITU Visualizations • Allows optimizing resources for compute Simulation Index Rendering and render MPI MPI • Application Driven Updates, push simulation data. • Allows inter-operability between coarser MPI MPI and finer meshes, adjusting data updates. . . . . • Maintains high frame rates and allows interaction with the volume. MPI MPI • Can couple multiple physics apps to a single rendering app. 42

  43. Steering Simulations Coupling • Steering is Application Specific Simulation Rendering • Steering simulations requires handling interrupts. Time Interrupt handler Time S1 S1 • Interrupt communicated through backward coupling. Time Time • A general approach by S2 S2 Function scalar/vector interrupts, and user applied to defined function to handle the fields variables of simulation. Time Time S3 S3 . . . . 43

  44. Summary: In-situ Visualization • Index enables better insights into simulation data through professional visualization techniques • Scalability is the enabler for HPC in-situ visualization. • Multiphysics coupling is the key to scalability, and resource management for in-situ. 44

  45. SELF-PACED LABS Interactive HPC Volume Visualization in ParaView NVIDIA IndeX for ParaView plugin hands-on Location: Self-paced lab area on lower level ▪ Dates: Monday 1:00 – 5:00pm ▪ Tuesday 9:30 – 11.30am ▪ ▪ Wednesday 1:00 – 5:00pm 45

  46. INTERACTIVE DEMO Interactiver HPC: Large Scale In-Situ Visualization using NVIDIA IndeX in ALYA MultiPhysics Live demonstration of in-situ visualization Interactive steering of simulation parameters Location: NVIDIA demo-booth in exhibit hall 1 ▪ 46

  47. Christopher Lux, NVIDIA Vishal Mehta, BSC Marc Nienhaus, NVIDA
