SRRUC WATERWORKS ADVISORY COMMITTEE Open House Sheep River Library November 29, 2018 5:00 pm 6:30 pm 11/29/2018 SRRUC Corporate Structure Water License Summary Summary of Alb. Env. Approvals Sources of Raw Water Supply


  1. SRRUC WATERWORKS ADVISORY COMMITTEE Open House – Sheep River Library November 29, 2018 5:00 pm – 6:30 pm 11/29/2018

  2.  SRRUC Corporate Structure  Water License Summary  Summary of Alb. Env. Approvals  Sources of Raw Water Supply  Project Status  Capacity of Water Supply Components  Water Quality Monitoring Programs  Water Restrictions Matrix 11/29/2018

  3. SRRUC Corporate Structure Municipality Partner Shareholder Share Town of Black Diamond √ √ 45% Town of Turner Valley √ √ 45% MD of Foothills No.31 √ √ 10% Village of Longview √ - -  Three Shareholder Municipalities are each entitled to their respective share of the total SRRUC water supply and treatment capacity;  Three Shareholder Municipalities are responsible for all SRRUC financial aspects and control of assets;  Each Municipality owns and is responsible for their own water license(s); 11/29/2018

  4. Water License Summary Municipality License # Annual Amount Average Daily 00092891-00-03 Turner Valley 210,926 m 3 /yr 578 m 3 /day 00032889-00-03 145,700 m 3 /yr 399 m 3 /day Turner Valley 00076672-00-04 Turner Valley 00032890-00-04 121,835 m 3 /yr 334 m 3 /day 36,367 m 3 /yr 100 m 3 /day Turner Valley 00032892-00-03 514,828 m 3 /yr 1,411 m 3 /day Turner Valley Total: 527,790 m 3 /yr 1,446 m 3 /day Black Diamond 00368807-00-00 426,925 m 3 /yr 1,169 m 3 /day Black Diamond 00396077-00-00 954,715 m 3 /yr 2,615 m 3 /day Black Diamond Total: 1,469,543 m 3 /yr 4,026 m 3 /day Combined: MD of Foothills TBD (Millarville) TBD TBD 11/29/2018

  5. Summary of Alb. Env. Approvals • EPEA : SRRUC – Approval renewed to 2019 – Public notification for next 10 year renewal – No changes requested from current Approval • Code of Practice Registration: Black Diamond • Code of Practice Registration: Turner Valley • Code of Practice Registration: MD of Foothills – In progress for water supply to Millarville 11/29/2018

  6. Water Supply to Millarville • MD has current water license on a Coulee Tributary to Three Point Creek for Millarville • AEP is currently reviewing MD’s Water Act applications • Waterline from Turner Valley to Millarville has been completed • MD is proposing to truck untreated water from Millarville to SRRUC Raw Water Reservoir in Turner Valley on interim basis, pending AEP approval to change “point of use” • SRRUC could treat MD’s raw water, and then return potable water through the new water main to Millarville • Once Water Act Approval is complete, MD’s raw water will be diverted from the Sheep River through SRRUC’s new Direct Intake facility and pumped to Millarville 11/29/2018

  7. Sources of Raw Water Supply: Licensed Annual Licensed Max. Average Source Diversion Flow Production 527,790 m 3 /yr 2,062 m 3 /day 1,100 m 3 /day VW5 (vault on river infiltration system) 210,926 m 3 /yr 2,749 m 3 /day 650 m 3 /day TV7 (conventional water well) CW8 (culvert well) * 145,700 m 3 /yr 851 m 3 /day 300 m 3 /day 121,835 m 3 /yr 655 m 3 /day 250 m 3 /day TV5A (conventional water well) 463,292 m 3 /yr 5,788 m 3 /day Direct Intake (in progress) * TBD 1,469,543 m 3 /yr 12,105 m 3 /day Total: * Subject to limitations based on Provincial Instream Objectives (I/O) for the Sheep River 11/29/2018

  8. Raw Water Supply System Source N Aquifer Production Wells PARTIALLY RECLAIMED LANDFILL Supply lines Raw Water Water Treatment Reservoir Plant 11/29/2018

  9. Current Project Details Direct Intake on the Sheep River: • Is supplemental (Mar-Nov) to the groundwater wells • Includes a floating Riverscreen ™ intake • Pumped through trailer-mounted centrifugal irrigation pump for easy removal from flood plain if and as required • Pump is capable of 1,200 usgpm ( ± 75L/s) • Water Licenses have been assigned by transfers from Black Diamond Wells no. 2 & 3 and Turner Valley Well no. 2 & 3 11/29/2018

  10. (Project currently being completed) 11/29/2018

  11. Provisional Capacity Overview (2016 population of TV and BD combined was 5,259) Component Capacity at 410 L/c/d * Capacity at 350 L/c/d ** Water Licenses (combined) 9,819 people 11,502 people Raw Water Supply (total before Direct Intake system is 4,878 people 5,714 people implemented) Raw Water Supply (total with 12,780 people *** 14,970 people *** Direct Intake system) Water Treatment Plant 8,902 people 10,428 people *All SRRUC system design was based on average water demand (ADD) of 410 Litres/capita/day ** Actual average water use for SRRUC in 2017 was 350 L/c/d *** capacity exceeds current Water Licenses, and maximum cannot be implemented until additional Water License is secured; also dependent on Provincial IO restrictions 11/29/2018

  12. Water Quality Monitoring Programs  Water stored in raw water reservoir: monthly testing  Groundwater near raw water reservoir site: 3 x per year  Raw water sources: 2 x per year  Source water aquifer: 2 x per year  Treated water distribution system overall sampling: 2 x per year  Treated water distribution system BacT.sampling: weekly 11/29/2018

  13. Water Conservation Matrix (before implementation of Direct Intake) 11/29/2018

  14. Water Conservation Matrix ( after implementation of Direct Intake) 11/29/2018

  15. Questions? Feel free to ask! 11/29/2018
