SPREAD SPECTRUM PRINCIPLES ECE2526 – MOBILE COMMUNICATION Monday, March 9, 2020

CONCERNS IN COMMUNICATION SYSTEM 1. Most focus in communication system study is focused on efficient use of signal energy and bandwidth. 2. There are however circumstances where it is necessary for the communication system to: (a) resist external interference; (b) operate with low spectral density (c) provide Multiple Access without external control (d) Make it difficult for unauthorized receivers to decode the signal. 3. Spread Spectrum is one of the mostly applied technique to achieve this objective.

WHEN IS A COMMUNICATION SYSTEM CONSIDERED AS SPREAD SPECTRUM? A system is considered to be spread spectrum if is satisfies these two conditions: a) The bandwidth of the transmitted signal is much greater than the message bandwidth, and b) The transmitted bandwidth is determined by some function that is independent of the message

ADVANTAGES OF SPREAD SPECTRUM Spread spectrum systems do not combat noise unlike systems like PCM and FM, they however have the following advantages: a) Has anti-jam capability, especially narrow-band jamming b) Provides interference rejection c) Has multiple Access Capability d) Protects against multipath interference e) Has lower probability of intercept (or is use for covert operation) f) Provides secure communication

CLASSIFICATION OF SPREAD SPECTRUM SYSTEMS • Spread Spectrum system are classified according to the modulation system used as: a) Direct sequence (pseudo-noise) where data is scrambled using user specific pseudo noise code b) Frequency Hopping where the signal is spread by changing the frequency over the transmitted time. c) Time hopping where data is divided into frames with each frame being split further into time intervals. Each data burst is then hopped over frames by utilizing code sequences.

DIRECT SEQUENCE/PSEUDO NOISE TRANSMITTER • In Direct Sequence(also called a Pseudo-noise), the signal is generated by adding a binary message with the output of a pseudo-noise generator as shown below: Message Binary Balanced Adder Modulator Output Clock Pseudo-noise Carrier Generator 𝑔 𝑑

m(t) m(t)p(t) y(t) Binary Balanced Adder Modulator p(t) Clock Pseudo-noise Carrier Generator 𝜕 𝑝

DIRECT SEQUENCE/PSEUDO NOISE RECEIVER 1.The receiver of the Pseudo noise signal performs three distinct functions, i.e 1. detect the presence of signal, 2. de-spread it and 3. demodulate the message. 2.The de-spreader multiplies the incoming signal with a locally generated PN sequence. 3.When the PN sequence and the incoming signal are aligned, the output from the de-spreader is the original message which can be filtered and demodulated to produce the original.

DIRECT SEQUENCE/PSEUDO NOISE RECEIVER (2) Multiplies the incoming signal Original with a locally message generated PN sequence. De-spreader Narrowband Message Filter Demodulation 𝑡(𝑢) 𝑛(𝑢) PN Code Local Clock Generator Reconstruction

FREQUENCY HOPPING SPREAD SPECTRUM 1. Frequency-hopping spread spectrum (FHSS) is a method of transmitting radio signals by rapidly switching a carrier among many frequency channels. 2. A pseudorandom sequence known to both transmitter and receiver is used by the frequency synthesizer.

TIME HOPPING SPREAD SPECTRUM • A time hopping system is a spread spectrum system in which the period or the duty cycle of a pulsed RF carrier are varied in a pseudorandom manner under the control of a coded sequence.

HYBRID DS/FH SPREAD SPECTRUM SYSTEM Baseband DS Hybrid DS/FH Output Output Data ~ Frequency PN Code Synthesiser Generator RF Oscillator

HISTORY OF SPREAD SPECTRUM 1941: First publications. 1949: C. Shannon and R. Pierce develop basic ideas of CDMA. 1950s: First applications as military Anti-jam applications 1980s: Investigations for cellular use 80s. 1993: IS-95 standard. 1995: First commercial introduction. 1997/1998: Applied as 3G technology – WCDMA and UMTS

CDMA PRINCIPLE Rate of Change Known as bitrate Each bit of sequence 1 is replaced by the code sequence Message signal + Rate of Change Known as chiprate Output Pseudo Code

CDMA SIGNAL SPECTRUM Message Signal Bandwidth = 2KHz Output Signal Bandwidth = 16KHz The spectrum has spread from 2 Hz to 16 Hz, i.e by a factor of 8.

THE SPREADING FACTOR 1. Multiplication with the code sequence which is of a higher bit rate, results in a much wider spectrum. 2. The ratio of the code rate to the information bit rate is called the spreading factor of the spread spectrum system. 3. In CDMA (IS-95), the spreading factor is 64.

GENERSATIONS OF MOBILE DATA STANDARDS High Speed Downlink High Speed Uplink Packet Access Packet Access

SAFARICOM WCDMA

SAFARICOM HSDPA

CDMA 1. CDMA uses unique spreading codes to spread the baseband data before transmission. 2. The signal is transmitted in a channel (BTS to BSC). 3. The receiver then uses a correlator to de-spread the wanted signal 4. The output of the correlator is passed through a narrow bandpass filter. 5. Unwanted signals are not de-spread and do not pass through the filter.

BASIC CDMA COMMUNICATION SYSTEM

INTERLEAVER • Interleaving is used to facilitate error correction when a burst error affecting consecutive bits occurs. • Interleaved signals can therefore be easily recovered when fast fading of signals occurs over the air while non- interleaved are not.

EVOLUTION OF CDMA/1 1. The CDMA history can be directly linked back to the 1940s when this form of transmission was first envisaged. 2.In the 1950s, it started to be used for covert military transmissions in view of the facts that the transmissions look like noise, it is difficult to decipher without the knowledge of the right codes, and furthermore it is difficult to jam. 3.With the revolution in cellular telecommunications that occurred in the 1980s a then little know company named Qualcomm working on CDMA as a basis for a cellular telecommunications multiple access scheme - CDMA - code division multiple access..

EVOLUTION OF CDMA/2 4. Qualcomm was joined by US network operators Nynex and Ameritech to develop the first experimental CDMA system. 5. With the support of the Cellular Telecommunications Industry Association (CTIA) and the Telecommunications Industry Association (TIA) a standards group was set up. This group then published the standard for the first CDMA system in the form of IS-95 in 1995. 6. This development lead on to the CDMA2000 series of standards. 7. Later, it became necessary to evolve the GSM standard so that it could carry data and provide significant improvements in terms of spectrum use efficiency. 8. Accordingly CDMA, in the form of Wideband CDMA (WCDMA) was adopted for the GSM standard
