Specifying Timber in Projects Seminar 8 th April 2019 Barry Brunton Sth. Aust Tech Team Barry.Brunton@woodsolutions.com.au 0426 56 7771

Welcome! Thanks to all for attending! In case of Emergency • Planned Fire Alarms? • Gents & Ladies facilities • Thanks to Speakers – investing time & effort • Thanks to Engineers Australia •

Programme 09:20 to 09:30 Introduction 09:30 to 10:20 (incl. questions) Timber in Architecture Presented by Cary Duffield – Troppo Architects 10:20 to 11:10 (incl. questions) Various applications of Timber Species Presented by Ken Otto – Otto Timber and Hardware Morning Tea (20 minutes) 11:30 to 12:20 (incl. questions) CLT in Sth. Aust – Verde Apartments Presented By Barry Brunton (on behalf of Morgan & Hansen) 12:20 to 12:30 Close

WoodSolutions ™ : Who we are An Australian industry initiative, resourced by Forest and Wood Products Australia (FWPA) – For architects, engineers, designers and other building professionals • inspiration • information & resources • CPD.

Text frame One Line Style Text headings in Calibri bold Body text in Calibri regular, body text in Calibri regular, Body text in Calibri regular, Body text in Calibri regular. Text headings in Calibri bold Body text in Calibri regular, body text in Calibri regular, Body text in Calibri regular, Body text in Calibri regular.

Exciting Times! Exciting times for the timber industry Wider scopes within the NCC • Development of engineering tools to support projects • Greater awareness of the ‘Green credentials’ • Desire to consider Engineered Timber products •

NCC Code Change 2019 The National Construction Code (NCC) is the regulatory framework for determining the minimum design and construction requirements for buildings in Australia. NCC Volume One Building Code of Australia 2019 for Class 2 to Class 9 Buildings is the document relevant to mid-rise timber buildings Previously restricted to Class 2,3 & 5

New Timber Construction Provisions The 2019 NCC, has been amended to permit, under the Deemed-to-Satisfy (DTS) provisions, the use of fire- protected timber construction systems in all classes of buildings up to 25 metres in effective height (herein termed ‘ mid-rise construction ’).

NCC 2019 changes for Timber Construction

Fire Protected Timber Lightweight Timber General Timber (High level of protection to timber) • FRL lightweight timber-framed construction e.g. 90, 120, 140 x 45mm • Fire-grade plasterboard linings required (typical solution): • 2 x 13mm fire-grade plasterboard for walls, and • 2 x 16mm fire-grade plasterboard for ceilings

Fire Protected Timber Massive Timber Massive Timber (Lower level of protection to timber) • Minimum 75mm thickness of massive timber element, with required FRL, with no concealed spaces between plasterboard coverings and timber e.g. CLT, Glulam, LVL • Fire protective covering required: Fire -grade plasterboard Element with appropriate layers • of fire protective covering, Massive timber generally 1 layer of 16mm fire- grade plasterboard for walls and ceilings

Mixed Class Buildings Hybrid Construction Fire-protected timber solutions apply to all classes of buildings that include sprinkler protection . Mixed Class Buildings - concrete structure on lower levels provides termite barrier and resistance to moisture penetration. Lightweight additions to existing buildings.

Structural Design Guide & Software FREE ASSISTANCE TO ENGINEERS FOR MID-RISE PROJECTS Video tutorial Midrise Structural Engineers Design Guide – In development ACRO-TIM Automated Calculation ROutines of mid-rise TIMber structures under combined wind and quake actions (VNA440-1718)

Specifying Timber in Projects We want to use timber….. What species to use? What Engineered Product to use? Multiple Options available • Learn from existing projects • Learn from experienced • professionals Utilise WoodSolutions website •

Shared Learning How do we benefit from the learning of those in the industry? - Our speakers / projects today have gained years of experience and learning in the industry

Allure of wood Affects all our senses Texture • Colour • Depth • Life • Promotes Wellness & Productivity • Pollinate Study – (Link below) • Handling – lightweight Strength - (weight to strength ratio) We have a sense of pride when it comes to timber projects https://www.woodsolutions.c om.au/wood-at-work

Engineers Australia Tall Timber presentation - 17 th April - At this venue - 5:30pm

Speakers Thank you and on to our first speaker……..
