Simple Symmetric Venn Diagrams with 11 and 13 Curves Khalegh - PowerPoint PPT Presentation

Nov 22, 2022 •252 likes •648 views

Simple Symmetric Venn Diagrams with 11 and 13 Curves Khalegh Mamakani and Frank Ruskey Department of Computer Science, University of Victoria, Canada 1 Tuesday, 9 July, 13 WHAT IS A VENN DIAGRAM? A closed curves divides the plane into two

  1. Simple Symmetric Venn Diagrams with 11 and 13 Curves Khalegh Mamakani and Frank Ruskey Department of Computer Science, University of Victoria, Canada 1 Tuesday, 9 July, 13

  2. WHAT IS A VENN DIAGRAM? A closed curves divides the plane into two open subsets of the points.   2 Tuesday, 9 July, 13

  3. WHAT IS A VENN DIAGRAM? Regions are formed by the intersection of interior and exterior of the curves. 00 Rank of a region : 01 A binary number that indicates the curves containing the region. 11 00 11 Weight of a region : The number of curves containing the region. 10 3 Tuesday, 9 July, 13

  4. 000 100 101 110 111 011 001 010 Venn Diagram : There are exactly 2 n regions where each region is in the interior of a unique subset of the curves. 4 Tuesday, 9 July, 13

  5. SIMPLE VENN DIAGRAMS No more than two curves intersect at any given point. 5 Tuesday, 9 July, 13

  6. MONOTONE VENN DIAGRAMS Every region of weight k is adjacent to at least one region of weight k+1 and is also adjacent to at least one region of weight k-1. 6 Tuesday, 9 July, 13

  7. MONOTONE VENN DIAGRAMS Every region of weight k is adjacent to at least one region of weight k+1 and is also adjacent to at least one region of weight k-1. 6 Tuesday, 9 July, 13

  8. MONOTONE VENN DIAGRAMS Every region of weight k is adjacent to at least one region of weight k+1 and is also adjacent to at least one region of weight k-1. 6 Tuesday, 9 July, 13

  9. MONOTONE VENN DIAGRAMS Every region of weight k is adjacent to at least one region of weight k+1 and is also adjacent to at least one region of weight k-1. 6 Tuesday, 9 July, 13

  10. ROTATIONAL SYMMETRY 7 Tuesday, 9 July, 13

  11. ROTATIONAL SYMMETRY Diagram remains invariant by a rotation of 2 휋 ╱ 푛 radians about a centre point. 7 Tuesday, 9 July, 13

  12. ROTATIONAL SYMMETRY 8 Tuesday, 9 July, 13

  13. ROTATIONAL SYMMETRY For any rotationally symmetric 푛 -Venn diagram, 푛 must be prime (Henderson 1963). 8 Tuesday, 9 July, 13

  14. ROTATIONAL SYMMETRY For any rotationally symmetric 푛 -Venn diagram, 푛 must be prime (Henderson 1963). The existence of non-simple symmetric Venn diagrams has been proved for any prime number of curves (Griggs, Killian and Savage 2004). 8 Tuesday, 9 July, 13

  15. ROTATIONAL SYMMETRY For any rotationally symmetric 푛 -Venn diagram, 푛 must be prime (Henderson 1963). The existence of non-simple symmetric Venn diagrams has been proved for any prime number of curves (Griggs, Killian and Savage 2004). The largest prime number for which a simple symmetric Venn diagram was known : 7 8 Tuesday, 9 July, 13

  16. REPRESENTATION OF SIMPLE MONOTONE VENN DIAGRAMS 9 Tuesday, 9 July, 13

  17. REPRESENTATION OF SIMPLE MONOTONE VENN DIAGRAMS 9 Tuesday, 9 July, 13

  18. REPRESENTATION OF SIMPLE MONOTONE VENN DIAGRAMS 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 A binary matrix of n − 1 rows and 2 n − 2 columns. 9 Tuesday, 9 July, 13

  19. REPRESENTATION OF SIMPLE MONOTONE VENN DIAGRAMS 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 10 Tuesday, 9 July, 13

  20. REPRESENTATION OF SIMPLE MONOTONE VENN DIAGRAMS 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 1 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 0 0 0 1 0 0 Crossing Sequence (Wendy Myrvold) : 1, 3, 2, 4, 3, 2, 1, 3, 2, 4, 3, 2, 1, 3, 2, 4, 3, 2, 1, 3, 2, 4, 3, 2, 1, 3, 2, 4, 3, 2 10 Tuesday, 9 July, 13

  21. CROSSCUT SYMMETRY Crosscut : A curve segment that sequentially crosses all other curves once. 11 Tuesday, 9 July, 13

  22. CROSSCUT SYMMETRY M4 (Ruskey) Hamilton (Edwards) 12 Tuesday, 9 July, 13

  23. CROSSCUT SYMMETRY 13 Tuesday, 9 July, 13

  24. CROSSCUT SYMMETRY 13 Tuesday, 9 July, 13

  25. CROSSCUT SYMMETRY Crosscut Symmetry : Reflective symmetry across the crosscut (ignoring the two regions at top and bottom). 13 Tuesday, 9 July, 13

  26. CROSSCUT SYMMETRY Crosscut Symmetry : Reflective symmetry across the crosscut (ignoring the two regions at top and bottom). Curve intersections are palindromic (except for the crosscut). C 5 intersections : [ C 4 , C 6 , C 3 , C 6 , C 4 , C 1 , C 4 , C 6 , C 3 , C 6 , C 4 ] 13 Tuesday, 9 July, 13

  27. CROSSCUT SYMMETRY THEOREM Crossing sequence of the 7-V ossing sequence of the 7-V ossing sequence of the 7-Venn ossing sequence of the 7-Venn ρ α δ α r+ 1, 3, 2, 5, 4, 3, 2, 3, 4, 6, 5, 4, 3, 2, 5, 4, 3, 4 14 Tuesday, 9 July, 13

  28. CROSSCUT SYMMETRY THEOREM Crossing sequence of the 7-V ossing sequence of the 7-Venn ossing sequence of the 7-Venn ossing sequence of the 7-V ρ α δ α r+ 1, 3, 2, 5, 4, 3, 2, 3, 4, 6, 5, 4, 3, 2, 5, 4, 3, 4 A simple monotone rotationally symmetric n -Venn diagram is crosscut-symmetric if and only if it can be represented by a crossing sequence of the form ρ , α , δ , α r + where • ρ is 1 , 3 , 2 , 5 , 4 , . . . , n − 2 , n − 3 and δ is n − 1 , n − 2 , . . . , 3 , 2 . • | α | = | α r + | = (2 n − 1 − ( n − 1) 2 ) /n and α [ i ] ∈ { 2 , . . . , n − 3 } . • α r + is obtained by reversing α and incrementing each element by 1. 14 Tuesday, 9 July, 13

  29. The First Simple Symmetric 11-Venn Diagram 15 Tuesday, 9 July, 13

  30. The First Simple Symmetric 11-Venn Diagram 15 Tuesday, 9 July, 13

  31. THE FIRST SIMPLE SYMMETRIC 11-VENN DIAGRAM α sequence : 3, 2, 3, 4, 3, 4, 5, 4, 3, 2, 3, 4, 3, 4, 5, 4, 3, 4, 5, 4, 5, 6, 5, 4, 5, 6, 5, 6, 7, 6, 5, 4, 3, 2, 5, 4, 3, 4, 6, 5, 4, 5, 6, 7, 6, 7, 8, 7, 6, 5, 6, 5, 4, 3, 4, 5, 7, 6, 5, 4, 6, 5, 8, 7, 6, 5, 4, 5, 7, 6, 5, 6, 8, 7, 6, 5, 4, 6, 5, 7, 6, 5, 6, 7. 16 Tuesday, 9 July, 13

  32. ITERATED CROSSCUT SYMMETRY Simple Symmetric 7-Venn Diagram Hamilton (Edwards) 17 Tuesday, 9 July, 13

  33. ITERATED CROSSCUT SYMMETRY 17 Tuesday, 9 July, 13

  34. A simple symmetric 13-Venn diagram with iterated crosscut symmetry 18 Tuesday, 9 July, 13

  35. 18 Tuesday, 9 July, 13

  36. α sequence of the simple symmetric 13-Venn : 3 2 4 3 5 4 3 2 4 3 5 4 6 5 4 3 5 4 6 5 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 6 5 6 5 4 5 4 7 6 5 4 6 5 7 6 8 7 6 5 4 3 7 8 6 7 5 6 7 8 5 6 5 6 7 6 7 4 5 6 7 6 5 6 5 4 5 4 9 8 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 5 4 6 5 4 5 6 7 6 5 4 5 6 5 6 7 6 5 6 7 6 7 8 7 6 5 4 3 5 4 6 5 7 6 5 4 6 5 7 6 8 7 8 7 6 5 4 5 6 7 6 5 4 7 6 8 7 6 5 7 6 5 8 7 6 9 8 7 6 5 4 8 7 8 7 6 7 6 5 9 8 7 6 8 7 6 5 9 8 7 6 10 9 8 7 6 5 4 3 7 8 9 10 6 7 8 9 7 8 9 10 6 7 8 7 8 9 8 9 5 6 7 8 9 10 7 8 9 6 7 8 6 7 8 9 7 8 5 6 7 8 7 6 5 6 7 8 9 8 9 7 8 6 7 5 6 7 8 6 7 5 6 4 5 6 7 8 9 8 7 8 7 6 7 8 7 6 7 6 5 6 7 8 7 6 5 6 7 5 6 4 5 6 7 6 5 6 5 4 5 4 19 Tuesday, 9 July, 13

  37. α sequence of the simple symmetric 13-Venn : 3 2 4 3 5 4 3 2 4 3 5 4 6 5 4 3 5 4 6 5 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 6 5 6 5 4 5 4 7 6 5 4 6 5 7 6 8 7 6 5 4 3 7 8 6 7 5 6 7 8 5 6 5 6 7 6 7 4 5 6 7 6 5 6 5 4 5 4 9 8 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 5 4 6 5 4 5 6 7 6 5 4 5 6 5 6 7 6 5 6 7 6 7 8 7 6 5 4 3 5 4 6 5 7 6 5 4 6 5 7 6 8 7 8 7 6 5 4 5 6 7 6 5 4 7 6 8 7 6 5 7 6 5 8 7 6 9 8 7 6 5 4 8 7 8 7 6 7 6 5 9 8 7 6 8 7 6 5 9 8 7 6 10 9 8 7 6 5 4 3 7 8 9 10 6 7 8 9 7 8 9 10 6 7 8 7 8 9 8 9 5 6 7 8 9 10 7 8 9 6 7 8 6 7 8 9 7 8 5 6 7 8 7 6 5 6 7 8 9 8 9 7 8 6 7 5 6 7 8 6 7 5 6 4 5 6 7 8 9 8 7 8 7 6 7 8 7 6 7 6 5 6 7 8 7 6 5 6 7 5 6 4 5 6 7 6 5 6 5 4 5 4 19 Tuesday, 9 July, 13

  38. α sequence of the simple symmetric 13-Venn : 3 2 4 3 5 4 3 2 4 3 5 4 6 5 4 3 5 4 6 5 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 6 5 6 5 4 5 4 7 6 5 4 6 5 7 6 8 7 6 5 4 3 7 8 6 7 5 6 7 8 5 6 5 6 7 6 7 4 5 6 7 6 5 6 5 4 5 4 9 8 7 6 5 4 3 2 3 4 3 4 5 4 5 6 5 4 3 5 4 6 5 4 5 6 7 6 5 4 5 6 5 6 7 6 5 6 7 6 7 8 7 6 5 4 3 5 4 6 5 7 6 5 4 6 5 7 6 8 7 8 7 6 5 4 5 6 7 6 5 4 7 6 8 7 6 5 7 6 5 8 7 6 9 8 7 6 5 4 8 7 8 7 6 7 6 5 9 8 7 6 8 7 6 5 9 8 7 6 10 9 8 7 6 5 4 3 7 8 9 10 6 7 8 9 7 8 9 10 6 7 8 7 8 9 8 9 5 6 7 8 9 10 7 8 9 6 7 8 6 7 8 9 7 8 5 6 7 8 7 6 5 6 7 8 9 8 9 7 8 6 7 5 6 7 8 6 7 5 6 4 5 6 7 8 9 8 7 8 7 6 7 8 7 6 7 6 5 6 7 8 7 6 5 6 7 5 6 4 5 6 7 6 5 6 5 4 5 4 19 Tuesday, 9 July, 13

  39. Thank you! 20 Tuesday, 9 July, 13
