SIGNET: NETWORK-ON-CHIP FILTERING FOR COARSE VECTOR DIRECTORIES - PowerPoint PPT Presentation

Jan 04, 2024 •425 likes •1.19k views

SIGNET: NETWORK-ON-CHIP FILTERING FOR COARSE VECTOR DIRECTORIES Natalie Enright Jerger University of Toronto Interaction of Coherence and Network 2 Cache coherence protocol drives network-on-chip traffic Scalable coherence protocols

  1. SIGNET: NETWORK-ON-CHIP FILTERING FOR COARSE VECTOR DIRECTORIES Natalie Enright Jerger University of Toronto

  2. Interaction of Coherence and Network 2  Cache coherence protocol drives network-on-chip traffic  Scalable coherence protocols needed for many-core architectures  Consider interconnection network optimizations to help facilitate scalable coherence DATE 2010 Natalie Enright Jerger

  3. Talk Outline 3  Introduction  Network-on-Chip Challenges with Scalable Coherence Protocol  SigNet Architecture: Network filtering solution  Evaluation  Conclusion DATE 2010 Natalie Enright Jerger

  4. Many-Core Cache Coherence Challenges 4 DATE 2010 Natalie Enright Jerger

  5. Many-Core Cache Coherence Challenges 4  Broadcast  Good latency  Poor scaling due to bandwidth requirements DATE 2010 Natalie Enright Jerger

  6. Many-Core Cache Coherence Challenges 4  Broadcast  Good latency  Poor scaling due to bandwidth requirements DATE 2010 Natalie Enright Jerger

  7. Many-Core Cache Coherence Challenges 4  Broadcast  Directory  Good latency  Good scalability due to point to point communication  Poor scaling due to  Storage overheads bandwidth requirements DATE 2010 Natalie Enright Jerger

  8. Many-Core Cache Coherence Challenges 4 Store Miss  Broadcast  Directory  Good latency  Good scalability due to point to point communication  Poor scaling due to  Storage overheads bandwidth requirements DATE 2010 Natalie Enright Jerger

  9. Many-Core Cache Coherence Challenges 4 Store Miss ForwardX  Broadcast  Directory  Good latency  Good scalability due to point to point communication  Poor scaling due to  Storage overheads bandwidth requirements DATE 2010 Natalie Enright Jerger

  10. Many-Core Cache Coherence Challenges 4 Response Store Miss ForwardX  Broadcast  Directory  Good latency  Good scalability due to point to point communication  Poor scaling due to  Storage overheads bandwidth requirements DATE 2010 Natalie Enright Jerger

  11. Scalable Cache Coherence 5 DATE 2010 Natalie Enright Jerger

  12. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  13. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  14. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  15. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  16. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  17. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line! DATE 2010 Natalie Enright Jerger

  18. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of overhead per cache line!  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  19. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line!  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  20. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line!  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  21. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  22. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  23. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  24. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  25. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  26. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  27. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  28. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2  Requires 1/2 as much storage DATE 2010 Natalie Enright Jerger

  29. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Only 2 sharers: 1 & 15  Coarse Vector Directories  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2 3 sharers but 6  Requires 1/2 as much storage invalidations DATE 2010 Natalie Enright Jerger

  30. Scalable Cache Coherence 5  Directory protocol storage overheads  Single bit per core in sharing Cores 1, 2, 5 & 15 share cache line vector (full map)  256 cores ➔ 32 Bytes of 2 pointers overhead per cache line! Represents Only 2 sharers: 1 & 15  Coarse Vector Directories cores 0 & 1  Dir i CV r  i: # of pointers  r: # of cores in region 3 rd sharer: overflow  Example: Dir 2 CV 2 3 sharers but 6  Requires 1/2 as much storage invalidations DATE 2010 Natalie Enright Jerger
