Semantics and Verification of Software Summer Semester 2019 Lecture - PowerPoint PPT Presentation

Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness) Thomas Noll Software Modeling and Verification Group RWTH Aachen University


  1. Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness) Thomas Noll Software Modeling and Verification Group RWTH Aachen University https://moves.rwth-aachen.de/teaching/ss-19/sv-sw/

  2. Recap: Hoare Logic Outline of Lecture 11 Recap: Hoare Logic Incompleteness of Hoare Logic Relative Completeness of Hoare Logic Total Correctness 2 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  3. Recap: Hoare Logic Hoare Logic Goal: syntactic derivation of valid partial correctness properties. Here A [ x �→ a ] denotes the syntactic replacement of every occurrence of x by a in A . Tony Hoare (* 1934) Definition (Hoare Logic) The Hoare rules are given by (skip) { A } skip { A } (asgn) { A [ x �→ a ] } x := a { A } (seq) { A } c 1 { C } { C } c 2 { B } (if) { A ∧ b } c 1 { B } { A ∧ ¬ b } c 2 { B } { A } c 1 ; c 2 { B } { A } if b then c 1 else c 2 end { B } = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } { A ∧ b } c { A } (cons) | | (while) { A } while b do c end { A ∧ ¬ b } { A } c { B } A partial correctness property is provable (notation: ⊢ { A } c { B } ) if it is derivable by the Hoare rules. In (while), A is called a (loop) invariant. 3 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  4. Recap: Hoare Logic Soundness of Hoare Logic Theorem (Soundness of Hoare Logic) For every partial correctness property { A } c { B } , ⊢ { A } c { B } ⇒ | = { A } c { B } . Proof. Let ⊢ { A } c { B } . By induction over the structure of the corresponding proof tree we = I A , C � c � σ = ⊥ or C � c � σ | = I B show that, for every σ ∈ Σ and I ∈ Int such that σ | (on the board). 4 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  5. Incompleteness of Hoare Logic Outline of Lecture 11 Recap: Hoare Logic Incompleteness of Hoare Logic Relative Completeness of Hoare Logic Total Correctness 5 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  6. Incompleteness of Hoare Logic Incompleteness of Hoare Logic I Soundness: only valid partial correctness properties are provable � Completeness: all valid partial correctness properties are systematically derivable � 6 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  7. Incompleteness of Hoare Logic Incompleteness of Hoare Logic I Soundness: only valid partial correctness properties are provable � Completeness: all valid partial correctness properties are systematically derivable � Theorem 11.1 (G¨ odel’s Incompleteness Theorem) The set of all valid assertions { A ∈ Assn | | = A } is not recursively enumerable, i.e., there exists no proof system for Assn in which all valid assertions are systematically derivable. Proof. Kurt G¨ odel see [Winskel 1996, p. 110 ff] (1906–1978) 6 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  8. Incompleteness of Hoare Logic Incompleteness of Hoare Logic II Corollary 11.2 There is no proof system in which all valid partial correctness properties can be enumerated. 7 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  9. Incompleteness of Hoare Logic Incompleteness of Hoare Logic II Corollary 11.2 There is no proof system in which all valid partial correctness properties can be enumerated. Proof. Given A ∈ Assn , | = A is obviously equivalent to { true } skip { A } . Thus the enumerability of all valid partial correctness properties would imply the enumerability of all valid assertions. 7 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  10. Incompleteness of Hoare Logic Incompleteness of Hoare Logic II Corollary 11.2 There is no proof system in which all valid partial correctness properties can be enumerated. Proof. Given A ∈ Assn , | = A is obviously equivalent to { true } skip { A } . Thus the enumerability of all valid partial correctness properties would imply the enumerability of all valid assertions. Remark: alternative proof (using computability theory): { true } c { false } is valid iff c does not terminate on any input state. But the set of all non-terminating WHILE statements is not enumerable. 7 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  11. Relative Completeness of Hoare Logic Outline of Lecture 11 Recap: Hoare Logic Incompleteness of Hoare Logic Relative Completeness of Hoare Logic Total Correctness 8 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  12. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic I • We will see: actual reason of incompleteness is rule = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } (cons) | | { A } c { B } since it is based on the validity of implications within Assn 9 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  13. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic I • We will see: actual reason of incompleteness is rule = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } (cons) | | { A } c { B } since it is based on the validity of implications within Assn • The other language constructs are “enumerable” 9 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  14. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic I • We will see: actual reason of incompleteness is rule = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } (cons) | | { A } c { B } since it is based on the validity of implications within Assn • The other language constructs are “enumerable” • Therefore: separation of proof system (Hoare Logic) and assertion language ( Assn ) 9 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  15. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic I • We will see: actual reason of incompleteness is rule = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } (cons) | | { A } c { B } since it is based on the validity of implications within Assn • The other language constructs are “enumerable” • Therefore: separation of proof system (Hoare Logic) and assertion language ( Assn ) • One can show: if an “oracle” is available which decides whether a given assertion is valid, then all valid partial correctness properties can be systematically derived 9 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  16. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic I • We will see: actual reason of incompleteness is rule = ( B ′ ⇒ B ) = ( A ⇒ A ′ ) { A ′ } c { B ′ } (cons) | | { A } c { B } since it is based on the validity of implications within Assn • The other language constructs are “enumerable” • Therefore: separation of proof system (Hoare Logic) and assertion language ( Assn ) • One can show: if an “oracle” is available which decides whether a given assertion is valid, then all valid partial correctness properties can be systematically derived ⇒ “Relative completeness” 9 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)

  17. Relative Completeness of Hoare Logic Relative Completeness of Hoare Logic II Theorem 11.3 (Cook’s Completeness Theorem) Hoare Logic is relatively complete, i.e., for every partial correctness property { A } c { B } : | = { A } c { B } ⇒ ⊢ { A } c { B } . Stephen A. Cook (* 1939) Thus: if we know that a partial correctness property is valid, then we know that there is a corresponding proof. 10 of 22 Semantics and Verification of Software Summer Semester 2019 Lecture 11: Axiomatic Semantics of WHILE III (Completeness & Total Correctness)
