Same Sofware Different Hardware configuration
THT CC � 2 x BLUE light emitter angled by 45 ° � 2 x UV led emitter angled by 90 ° � 2 x RED light emitter angled by 35 ° � 2 x RED light emitter angled by 45 ° � 2 x WHITE light diffused emitter (90 ° ) � 2 x WHITE light diffused emitter angled by 35 ° � Parallax-Free optical lens pack with 300x400mm or 420x540mm area � 1.200 dpi full RGB 24 bit sensor � Single FoV 14.040x20.400 pixel (about 860 Mpixel) � 19.656x27.540 pixel (about 1.630 Mpixel) � Optical inspection time between 6 to 25 secs (25mm/sec) �
� The Scanner is fixed (no external movable parts) � Scanning max time 25 secs � Each pixel is full RGB; it means each pixel has 24 real bits (debayering is not needed) � Easly mountable top or bottom FILTER GLASS SENSORS
Specific Optical path: � Without parallax error � Orthoscopic having high sharpness/resolution capacity and low distortions, perfect for measurement applications
� Presence � Position � Polarity
THT Pin THT Pin THT Pin THT Pin THT Pin not soldered not lean soldered soldered with hole soldered soldered with hole
Short and bead Solderball Splash (beads)
Keep out zone violation Coating drops visible Areas on board coated and uncoated , finding at non coated area area automatically, by wizard
Coated area visible at 3D image or as landscape thickness indicator
Optional feature Coating landscape thickness measurement: Calibrated by Sensor
Bare or Data Matrix Code reading
� In-line � Top � Bottom � Camera � Dual
� In-Line system � Single TOP (presence-position inspection) � Single BOTTOM (wave soldering quality inspection) � Double side
� Very small footprint � Easy to integrate � Ideal solution for dedicated lines working on small items
• Effegi (EMS automotive) (IT) • ABB (OEM Inverters & Car Charger) (IT) • SSI (automotive) (Czech Rep) • Magna (automotive) (IT) • Continental (automotive) (Mexico)
� In-line system � Scanner technology � Standard belt or chain (CC) conveyor
Inline ICT Unload MiniWave Dragon Manual Assembly multipot Selective Fly Wave Soldering Repair Station Automatic recipe change barcode controlled
THT inspection Single side (Bottom) Standard scanner
� 1X THT inspection � Singe side (Top) � Large scanner � 2X CC inspection � Double side � Large scanner
Manual Assembly Dragon Wave Soldering Tilt Unit Load/Unload Fly Repair Station Pallets return on a bottom line Pallet dispatch by RFID control
DragonFly inspects: - first side after coating top side - both sides after coating bottom side Manual Glue Coating Coating Dragon Oven Load/Unload Station machine 1 machine 2 Fly Repair Tilt Unit Station Pallet dispatch by RFID control
Top Bottom Side Side
� Dedicated line � In-line system � Scanner technology � Bosch conveyor
Previous line RFID part identification and tracking Pin Repair Firefly1 Firefly2 Dragonfly centering Station Completion Unload
Esempio prodotto
� Single-product line � In-line system � Camera technology � Same inspection sw features
� Product: automotive pump � 3 solder joints
� 2 Systems in 1 � Soldering + AOI
XY robot for pallet/part dispatch: � Good part � back to the operator within the pallet Laser AOI � Bad part � part scraped, empty pallet back to the operator Other process steps: � PCB + electrode assembly � Crimping � Programming � Test � EOL � Packaging
Automotive Sensor
SOLDERING AOI
• MANAGE: PLC, VIVA, MODUS SW • COMUNICATE WITH MES
��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ������������� �������� ��������� ����� �������� �������� ��� ��� ��� ��� ������� ��� ����� ��� ����� ��� �������� ���� ������� ��� ����� ��� ���� ��� ��� ���� ���� �� ����� ������������� ������� ����� ������ ��������� �� ��!����"�! ����� ����� ����� ����� ��� ��� ��� ��� # �������� ��������� ��������� ��������� ��������� ��������� ��������� ��������� ��������� ����� ��� �������� ���$�� ������ ����������� ��!%"�!����� ��������&����� ��������� ��������� ��������� ��������� ������� ������� ������� �������
