Plugging external provers into the Rodin platform Laurent Voisin (Systerel) Rodin and Event-B An open platform for Event-B modelling and proving Designed to model reactive discrete systems by engineers (no PhD required) Based on the


  1. Plugging external provers into the Rodin platform Laurent Voisin (Systerel)

  2. Rodin and Event-B • An open platform for Event-B modelling and proving • Designed to model reactive discrete systems by engineers (no PhD required) • Based on the Eclipse IDE • Contains an open proving framework for both automated and interactive proof • see http://www.event-b.org

  3. The Event-B mathematical language • Formally defined • Based on classical first-order predicate calculus with equality, typed set- theory and integer arithmetic • Extensible: • inductive datatypes (e.g., List) • (recursively) defined operators (e.g., sequence, append) • axiomatic types (e.g., Real numbers) • axiomatic operators (e.g., Real addition) • Proof system defined using sequent calculus

  4. Proving framework • From the model, the platform generates proof obligations (aka VC) • Each PO must be discharged • A proof is a tree where each node carries a sequent • The root carries the sequent corresponding to the PO • The platform maintains the proof tree

  5. Reasoners • Inference rules are produced by reasoners • Inference rules can be forward or backward • A terminating rule has no antecedent
 (e.g., H, P |- P) • Some reasoners are integrated into the platform (e.g., normalizers and specialized reasoners) • Some reasoners are provided by external provers

  6. A word about safety • The platform trusts the external reasoners • It is not skeptical • Practical trade-off • There is more chance that the model is wrong • Rather than the reasoner you use produces an invalid rule • You can check each rule with another reasoner to increase confidence

  7. External provers • Need to translate from Event-B to the language/ logic of the external prover • Would need to translate back from the external prover • This is easy for terminating rules • Not attempted for other kinds of rules • Important note: want minimal rules to facilitate reuse

  8. Examples • Atelier B provers (translates to classical B) • SMT solvers (translates to SMT-LIB, uses unsat core) • TPTP provers (translates to TPTP) • Isabelle (experimental, translates to a shallow embedding in HOL).
