인류가 만든 문제에 대한 자연적인 해법 Natural Solutions for man-made problems

오일이 토양에 유출됨 Oil spill in soil

I 시간 후

3 개월 후

PROJECT: COKE OVEN TAR - 40 YEAR OLD PROBLEM 제철소 현장 (STEEL PRODUCTION SITE) 코크스오븐의 유출물의 PAH 오염물이 6 개월간의 처리 후 95% 사라짐 Six months treatment cut 95% of priority PAH pollutants from coke oven effluent . 씨타델 바이오켓 플러스는 코크스오븐의 유출물로 인해 오염된 토양 150,000 톤을 생물학적 복원을 이뤄냈습니다 . Citadel BioCat+ TM provided the bioremediation in situ of 150,000 cubic meters of contaminated soil at a decommissioned coke oven effluent lagoon 0.05% 의 계면활성제와 Citadel BioCat+ TM 8% 용액을 혼합한 25 리터를 토양 1 톤당 산포하였습니다 . 25 litres of Citadel BioCat+ TM 8% solution with 0.05% surfactant was sprayed per cubic meter of soil.

제철소 코크스 오븐 타르 Steel works coke oven tar 처리 전 처리 후

토양 농작법 LAND FARMING 생물학적 복원 / 분해 Bio-Remediation/Degradation  토양 (Soil)  단백질 Enzymes ( Microbes / BioCat+  산소 ( 대기 중 ) Oxygen (air)  물 / 열 Water / Heat  질소 ( 우레아 / 비료 ) Nitrogen (Urea / Fertilizer)  네이쳐솝 Naturesorb (The Host)  폭기 / 회전경운기 Aeration / Rotovation

토양 농작법 LAND FARMING Naturesorb BioCat+ Nutrients Bacteria 현장에서 바로 가능하고 , 다른 곳에서 할 수도 있다 Can be done in situ or at a different site.

생물학적 복원 차트 BIO-REMEDIATION CHART 6000 5000 차트는 110 일이상 기간에 생물학적 복원상태를 Kg 당 탄화수소 (HC) 의 평균 밀리그램값으로 보여준다 Chart showing average Bio-remediation of 4000 Hydrocarbons milligrams per Kg over a 110 day period 3000 2000 1000 0 Day 1 Day 31 Day 110 Day 60 9

치즈공장 라군의 모래가 씨타델 바이오켓플러스로 정화되었다 Cheese factory lagoon Sand has been cleaned by Citadel BioCat+ 바이오켓이 라군의 모래톱의 그리스를 분해 높은 생물학적 반응 시킨다 BioCat+ breaks down the grease from the High biological reaction sand banks of the lagoon

바이오켓 공정을 이용하여 생물학적으로 처리할 수 있는 폐기물의 종류 TYPES OF WASTE THAT CAN BE BIOLOGICALLY TREATED USING BIOCAT+ PROCESS 라군 복원 Lagoon restoration CPU 유제품 생산 폐기물 아스팔트 탱크의 잔류물 Dairy produce waste CPU Bitumen tank residue

Isipingo River decontamination Citadel Biocat + provided an effective tool for restoring the “Isipingo River”, which also was practical and affordable for the South African government. The amount of oxygen in the river had dropped to less than 3 mg/l, which is 50% less oxygen than is needed to keep fish and other wildlife alive. Citadel BioCat+ was introduced upstream from  Increased DO from <0.5 to >7.0 the industrial/residential area at a rate of eight gallons per day. The (DO level) increased 93% in  Eliminated mal-odours and septic appearance. four months.  Lowered total coli forms from 51,000 to <50.

CASE STUDY TOXIC OIL SPILL

공장 벽에 구멍 Hole in factory wall 우유 탱크 Milk tanker

네이처솝으로 디젤과 황산을 딖아내고 있다 Sweeping up Diesel & sulfuric acid with Naturesorb

태양과 물 , 그리고 네이처솝과 바이오켓 플러스로 3 개월 후에 새로운 식물이 생장 New plant growth after only 3 months of sun water, Naturesorb & BioCat+

사례연구 CASE STUDY 캐스트롤 화재 CASTROL FIRE

사례연구 캐스트롤 화재 CASTROL FIRE CASE STUDY 전소 후 Aftermath

CASTROL FIRE CASE STUDY Sweeping up absorbed oil notice no trace of oil residue 사무실엔 13 센티미터의 오일 Office under 5’’ of Oil 1 . Office area now covered with product, Note the Note light areas where absorption oil “high is complete tide” mark. 4 . 5. OIL Free Carpet the next day 3 . 2.

CASE STUDY CASTROL FIRE SWD Containment  Delivery Motor Cycle Oil level in the Store

CASE STUDY CASTROL FIRE Drum encapsulation of hazardous chemicals ready for disposal

CASE STUDY CASTROL FIRE 13 WORKING DAYS

Red fish oil leaked into the fiord in Sotra, Bergen. Ragnar Hatlem of ABSOR positioning skimmer to pump the oil to storage tanks on work boat Skimmer inlet 노르웨이에서 생선기름 유출 사고 FISH OIL SPILL IN SOTRA, NORWAY

노르웨이 생선기름 유출 사고 FISH OIL SPILL IN SOTRA, NORWAY 정화 전 Before cleaning

 NATURESORB AGGLOMERATES THE OIL  RECOVERY OF OIL MADE EASY, NO SPECIAL EQUIPMENT 25

FISH OIL SPILL IN SOTRA, NORWAY Fish Oil on the shore Line before cleaning

FISH OIL SPILL IN SOTRA, NORWAY Applying naturesorb

FISH OIL SPILL IN SOTRA, NORWAY Applying naturesorb Skimming used naturesorb

Appling Naturesorb FISH OIL SPILL IN SOTRA, NORWAY Pressure washing rocks

FISH OIL SPILL IN SOTRA NORWAY Naturesorb applied to the shoreline

FISH OIL SPILL IN SOTRA, NORWAY Clean shoreline after naturesorb process

FISH OIL SPILL IN SOTRA, NORWAY Totally restored environment

SPILL MANAGEMENT ON RIVERS & CREEKS  Naturesorb can be easily applied to oil spills in marshlands Oil contamination in the marshlands of Louisiana from Horizon Deep spill, Gulf of Mexico 33

SPILL MANAGEMENT ON RIVERS & CREEKS  Spray application simple and effective  Removes oil from water and vegetation on contact Naturesorb being applied at the Louisiana Marshlands 34
