Mining Version Histories to Guide Software Changes by T. Zimmermann, - PowerPoint PPT Presentation

Mining Version Histories to Guide Software Changes by T. Zimmermann, P. Weigerber, S. Diehl, A. Zeller in IEEE Transaction on Software Engineering, Vol. 31, No. 6., June 2005 The Idea Can we make similar suggestions for software changes?


  1. Mining Version Histories to Guide Software Changes by T. Zimmermann, P. Weißgerber, S. Diehl, A. Zeller in IEEE Transaction on Software Engineering, Vol. 31, No. 6., June 2005

  2. The Idea Can we make similar suggestions for software changes?

  3. Extending Eclipse Preferences  Extend Eclipse IDE with a new preference  Preferences are stored in a field fKeys[]

  4. Extending Eclipse Preferences  What else do you need to change?  Which of the 27,000 files?  Which of the 20,000 classes?  Which of the 200,000 methods?  Program analysis  fKeys[] and initDefaults() use the same variables  Usage does not induce change  Usage can be detected only within the source code  Eclipse has 12,000 non-Java files

  5. Learning from History  Programmer who changed fKeys[] also changed …

  6. From CVS to Transactions  The CVS archive for Eclipse has more than 47,000 transactions

  7. ROSE in a Nutshell

  8. Changes -> Transactions -> Rules Entity – a triple (c, i, p),   where c – syntactic category; i – identifier; p – parent entity Example: (method, initDefaults(), ( class, Comp, (file, Comp.java, …))  Operations on entities: add_to, del_from, alter  Transaction – the set of changes simultaneously submitted by a  developer to a version archive

  9. Getting Syntactic Entities

  10. Light-Weight Analysis with ROSE

  11. Light-Weight Analysis with ROSE Rose analyzes C/C++, JAVA, PYTHON, T E X and TEXINFO files We get modified methods , variables and subsections

  12. Changes -> Transactions -> Rules  ROSE retrieves changes and transactions from CVS [Berliner’90]  CVS provides only file versioning  Per-file changes are grouped into transactions  Files -> Transactions -> Sliding window approach [Fogel’02]  Two subsequent changes, the same author, 200 second apart  Branches and Merges in CVS  Rose ignores changes that affect more than 30 entities

  13. Changes -> Transactions -> Rules  Rules are mined from transactions  Rules are mined with Apriori Algorithm [Agrawal’94]  The generated rules have the form: antecedent(s) => consequent (s)   The rules have a probabilistic interpretation Evidence: support count (# of transactions) and confidence (the  strength of the correspondence)

  14. Evolutionary Coupling

  15. Evolutionary Coupling

  16. Evolutionary Coupling Support : How much evidence (= simultaneous changes)? Confidence : How much relevant is coupling for participants?

  17. Evolutionary Coupling Support : How much evidence (= simultaneous changes)? Confidence : How much relevant is coupling for participants?

  18. Applying Rules  The programmer performs a change – “a situation”:  ROSE suggests further changes by applying matching rules  Matching rule = situation = antecedent  The suggestion = union of the consequents of all the matching rules  The # of rules depends on support count and confidence

  19. Multi-Dimensional Rules  If something is added to software, there is no way to predict the change based on history  E.g., the developer adds “Foo” constant to Comp.java  ROSE can do that in “operation” dimension

  20. Examples of Rules  GCC arrays that define the cost of different assembler operations for INTEL CPUs  The arrays have been altered 9 times; 9 out of 11 times, the change is triggered by a change in the type:

  21. Examples of Rules  Python and C files – detecting evolutionary couplings in different programming languages  It would require cross-language program analysis to detect this coupling

  22. Examples of Rules  POSTGRES documentation

  23. ROSE Server and Client  The ROSE server determines coupling and rules  The ROSE client guides the programmer along related changes

  24. Evaluation  How good are rules at predicting changes?  Training period: ROSE infers rules from the past  Evaluation period: ROSE applies the mined rules  In evaluation period, every transaction T is checked:  Navigation : given one change in T, does ROSE point to further changes in T?  Error Prevention : given all but one change from T, does ROSE point to the missing change?  Closure : given all changes of T, does ROSE stay silent?

  25. Evaluating Additional Questions  Granularity  Files and functions  Maintenance  No addition or deletions  Multiple Dimensions  What is the benefit of add_to and del_from ?  History  How much history? Usefulness over time? Quality or recommendations depending of the development cycle and releases?  Recent Changes  Relevance of old changes

  26. Projects Used for Evaluation

  27. Precision vs. Recall  Recall : How many relevant entities are returned?  Precision : How many of the returned entities are relevant?

  28. Precision vs. Feedback / Support Count vs. Confidence

  29. Results: Navigation, Prevention, Closure

  30. Navigation, Prevention, Closure  The programmer has changed one single entity. Can ROSE suggest other entities that should be changed?  The programmer has changed several entities but one. Does ROSE find the missing one?  The programmer made all necessary changes. How often does ROSE still suggest a missing change?

  31. Results for Fine Granularity

  32. Results: Navigation  Given one initial item, ROSE makes predictions in 66 percent of all queries  On average, the predictions contain 33 percent of all items changed  For those queries for which ROSE makes recommendations, in 7 percent of the cases, a correct location is within ROSE’s topmost three suggestions

  33. Results: Prevention and Closure  In 3 percent of the queries where one item is missing, ROSE issues a correct warning  A warning predicts 75 percent of the items that need to be changed  ROSE’s warning about missing items should be taken seriously …  Only 2 percent of all transactions cause a false alarm (!)

  34. Results for Coarse Granularity

  35. Results for Maintenance  Rose shows the best predictive power for changes to existing entities

  36. Threads to Validity  Kinds of version histories and software projects  8 projects; 100,000 transactions  Transactions do not record the order  CVS limitation  Quality of transactions?  User studies?

  37. Summary For stable systems like GCC, ROSE gives precise suggestions  (recommendation in 63% of transactions, precision – 30%, in 90% of all recommendations – 3 topmost suggestions contain correct entity) For rapidly changing systems like KOFFICE, most useful  suggestions are at the file level (because prediction new functions – out of reach for any approach) Predictive power of ROSE is best during maintenance phases  In about 2-7% of all erroneous transactions, ROSE correctly detects  the missing change (only 2% of all transactions cause false alarm) ROSE detects coupling between non-program entities (e.g. docs,  manuals, mappings)

  38. Future Work  Taxonomies : identify patterns of changes  Sequence rules : detect rules across multiple transactions  Further data sources : log messages, bug databases  Refactoring : ROSE does not recognize renamings of methods or files  Program analysis : can improve the overall approach  Rule presentation : visualization of rules can help

  39. Downloads ROSE is publicly available as a plug-in for ECLIPSE For details and downloads visit http://www.st.cs.uni-sb.de/softevo
