L2VPN OAM Requirements & Framework - PowerPoint PPT Presentation

L2VPN OAM Requirements & Framework draft-ietf-l2vpn-oam-req-frmk-04.txt Dinesh Mohan (Nortel) mohand@nortel.com Ali Sajassi (Cisco) sajassi@cisco.com IETF-64, Vancouver November 07, 2005 draft-ietf-l2vpn-oam-req-frmk-04.txt 1 Overview


  1. L2VPN OAM Requirements & Framework draft-ietf-l2vpn-oam-req-frmk-04.txt Dinesh Mohan (Nortel) mohand@nortel.com Ali Sajassi (Cisco) sajassi@cisco.com IETF-64, Vancouver November 07, 2005 draft-ietf-l2vpn-oam-req-frmk-04.txt 1

  2. Overview Customer Service Provider Customer MPLS Access Eth Access MPLS Core Customer Domain Service Provider Domain OAM Operator Operator Domain Operator Domain Domain Network PW/ MPLS Domain OAM MPLS MEP MPLS Domain MIP OAM > OAM Framework constructs and OAM Requirements > Service Layer make use of native technology OAM > Underlying MPLS/IP PSN layers make use of PW/LSP OAM draft-ietf-l2vpn-oam-req-frmk-04.txt 2

  3. Draft -04 Editorial Updates > Authors and Contributors information updated • Additional authors added • Simon Delord (Uecomm) • Philippe Niger (France Telecom) • Additional contributors added • Deborah Brungard (AT&T) • Lei Zhu (Sprint) • Yuichi Ikejiri, Yuichiro Wada (NTT) • Kenji Kumaki (KDDI) > Section 1.1 (Terminology) added > Section 4 reorganized and other sections added for better readability draft-ietf-l2vpn-oam-req-frmk-04.txt 3

  4. Draft -04 Technical Updates - I > Section 3.2 (OAM Domains) updated • Hierarchical and Adjacent OAM domains distinction added > Section 5 (OAM Framework for VPWS) added • Based on VPWS framework in draft-delord-pwe3-oam-applications-01.txt > Section 9 (OAM Operational Scenarios) added • Indicate what kind of solutions can be used for different OAM layers without being presciptive draft-ietf-l2vpn-oam-req-frmk-04.txt 4

  5. VPWS Management Model 1 Customer Service Provider Customer PW AC 1 AC 2 LSP CE1 PE1 PE2 CE2 Access 2 Access 1 PSN Core Customer Domain (A) Service OAM Provider Domain PW/ (B) Network MPLS Operator Domain OAM OAM (C) > CEs are owned and managed by Customer • Customer runs end-to-end OAM using native technology OAM > If CE to PE connection is phy interface, AC ME monitoring req is minimal > Provider is responsible for monitoring the PW ME > AC monitoring is joint responsibility of Customer and Provider draft-ietf-l2vpn-oam-req-frmk-04.txt 5

  6. VPWS Management Model 2 Customer Service Provider Customer PW AC 1 AC 2 LSP CE1 PE1 PE2 CE2 Access 2 Access 1 PSN Core Customer Domain (A) Provider Domain Service (B1) OAM (B2) Provider Domain Provider Domain Provider Domain (C) Network OAM Operator Domain Operator Domain Operator Domain (D) > Provider manages CEs and runs end-to-end OAM (B1 or B2) (B1) when PEs are client service unaware, (B2) when PEs are client service aware • > Provider may additionally monitor AC and PW MEs (C) > Operator may monitor Access Tunnels and PSN Tunnels (D) > This model is assumed to be more common for carrier services > Not all MEs may be monitored as Provider & Operator may be same groups draft-ietf-l2vpn-oam-req-frmk-04.txt 6

  7. Draft -04 Technical Updates - II > Appendix 1 (Alternate Management Models) added • To allow a view of interim solutions when CEs or PEs are not functional to implement recommended Management Model 2 > IPLS OAM Section removed • No interest or contributions identified draft-ietf-l2vpn-oam-req-frmk-04.txt 7

  8. Alternate Mgmt Model – Minimal OAM Customer Service Provider Customer PW AC 1 AC 2 LSP CE1 PE1 PE2 CE2 Access 2 Access 1 PSN Core Provider Domain Service (B1) OAM Network OAM Operator Domain Operator Domain Operator Domain (D) > Provider does end-to-end OAM (B1) > Network Operators monitor segments e.g. Access Tunnels and PSN Tunnels (D) > Advantage VPWS monitoring is limited to CEs • > Limitation • No Fault localization capabilities are available at the VPWS service layer draft-ietf-l2vpn-oam-req-frmk-04.txt 8

  9. Alternate Mgmt Model – Segment OAM I/W Customer Service Provider Customer PW AC 1 AC 2 LSP CE1 PE1 PE2 CE2 Access 2 Access 1 PSN Core Service OAM Provider Domain Provider Domain Provider Domain (C) Network OAM Operator Domain Operator Domain Operator Domain (D) > End-to-end OAM is provided by interworking OAM across segments (C) > Interworking functions can be simple or complex depending on homogeneous VPWS or heterogeneous VPWS respectively > Limitation • End to end service is tied to network technology • Interworking function is needed which depends on the AC and PW technology types • End to end service path is not exercised draft-ietf-l2vpn-oam-req-frmk-04.txt 9

  10. Next Steps > Add VPWS OAM Requirements • Based on draft-delord-pwe3-oam-applications-02.txt > Update References > Target last call by IETF-65 > Initiate solution drafts addressing specific OAM requirements > Initiate other draft identifying interim requirements (minimal set of OAM requirements) for interim solutions??? • Volunteers???? draft-ietf-l2vpn-oam-req-frmk-04.txt 10

  11. draft-ietf-l2vpn-oam-req-frmk-04.txt Backup Slides 11

  12. L2VPN OAM – How diff. layers come together? Services Service OAM L2VPN Network Network OAM PWE3 Transport Ethernet link PW/MPLS EoSONET Other Links OAM OAM OAM OAM > OAM Interworking possible to utilize OAM across Layers > However, each layer must support OAM capabilities independently draft-ietf-l2vpn-oam-req-frmk-04.txt 12

  13. History > IETF-63 (Paris) • draft-ietf-l2vpn-oam-req-frmk-03.txt updated submitted • Agreement to include VPWS framework and requirements from draft-delord • Discussion to reflect how the framework can accommodate interim solutions > IETF-62 (Minneapolis) • draft-ietf-l2vpn-oam-req-frmk-02.txt update submitted • Editorial updates based on discussion during IETF-61 meeting > IETF-61 (Washington D.C.) • draft-ietf-l2vpn-oam-req-frmk-01.txt discussed • Agreement to continue work for L2VPN Service OAM • Agreement to specifically identify requirements on underlying technologies supporting L2VPN e.g. PWs and/or LSPs > IETF-60 (San Diego) • Draft-ietf-l2vpn-oam-req-frmk-00.txt submitted • Overwhelming support for draft-mohan-sajassi-oam-req-frmk-00.txt to progress as a WG draft (during IETF-59 Seoul meeting and mailing list) draft-ietf-l2vpn-oam-req-frmk-04.txt 13
