Introduction in ML with scikit- learn

Professor Patrick McDaniel Jonathan Price Fall 2015

Page

Features

• Attributes in a data set
• “Individual measurable property of phenomenon

being observed”

• Choosing/discovering features is a crucial part of

ML

• Ex:
• Character Recognition: histograms of pixels
• Speech Recognition: Sound length, power, frequency
• Malware Detection: Function use count, byte counts

Page

Supervised Learning

• Inferring a function from labeled training data
• The features are selected by the developer
• As such, it requires the developer to know

something about the dataset to infer good features

• Based on pairs of input objects and output values
• Ex:
• Regression – Predict values
• Classification – Predict groupings

Page

Unsupervised Learning

• Find hidden structure or patterns in unlabled data
• Requires no prior knowledge of the nature of data
• Not limited by biases inherent in feature selection
• Ex:
• K-means
• Clustering
• Neural networks

Page

Scikit-learn

• The easy way to do data mining and data analysis
• Its all Python scripts (yay)
• Built on NumPy, SciPy, and matplotlib
• Okay, lets get it:
• pip install numpy scipy scikit-learn

Page

Lets do one

• Classification of digits problem
• Classify images of drawn numbers

Page

Before We Start

• What can we use about the image of a character

to solve this problem?

Page

Dataset

• Dataset object in scikit-learn is a dictionary-like
• bject that holds all data (and some metadata).
• Actual data is stored as a N_sampes, N_features

array

• Lets get the digit dataset:

>>> from sklearn import datasets >>> digits = datasets.load_digits()

Page

Dataset

Page

Dataset

• “digit database by collecting 250 samples from 44
• writers. The samples written by 30 writers are

used for training, cross-validation and writer dependent testing, and the digits written by the

• ther 14 are used for writer independent testing”
• 500 x 500 pixel characters, compressed to form

this (and then a feature vector of length=64):

Page

Lets Do Some Estimating

• We’re going to use support vector classification

(SVC). We’ll explain later.

• This code sets up the classifier clf:

>>> from sklearn import svm >>> clf = svm.SVC(gamma=0.001, C=100.)

• We will also treat this as a black box and come

back to the gamma/C values later

Page

Fit And Predict

• To fit the classifier:

>>> clf.fit(digits.data[:-1], digits.target[:-1])

• Now, we predict!

>>> clf.predict(digits.data[-1]) array([8])

• Which is apparently this from before:

Page

Its (Sort of) That Easy!

• We glossed over a couple details, but this shows

how easy scikit learn makes the actual implementation

• Lets talk about some of the concepts we skipped
• ver earlier

Page

SVC’s

• We are NOT going into implementation details.
• Used for classification, regression, and detecting
• utliers
• Advantages:
• Works in high-dimensional spaces
• Memory efficient
• Versatile
• Disadvantages
• Bad when # of features > # of samples
• Don’t directly provide probability

Page

SVC: Graphically

Page

Next Week

• Next, we will go over a security usage of data

analysis: a malware classification Kaggle challenge from Microsoft

• See the course site for supplemental readings and

setup instructions
