Domain-Contextualized Intelligent Traceability Presented by: Auguste Lalande What are trace links? Software development generates artifacts, such as regulatory documents , and system level requirement documents Trace links connect the


  1. Domain-Contextualized Intelligent Traceability Presented by: Auguste Lalande

  2. What are trace links?  Software development generates artifacts, such as regulatory documents , and system level requirement documents  Trace links connect the sections of these documents that correspond to the same idea

  3. Action Units  Break down natural language requirement into its key parts The Wayside Segment shall transmit Wayside Status Messages (WSMs) to the Automobile Segment. Action Semantic Group Properties transmit Transmissive Agent: wayside segment Theme: WSM Recipient: automobile segment

  4. Action Units: How?  POS parse tree (Stanford Parser)  Dependency set (Stanford Parser)  Syntactic group  Group of verbs with similar syntactic properties  Mapping rules  Given the verb transmit, t he subject corresponds to the agent property. Dependency set  agent = nsubj = Wayside Segment dobj(transmit-5, Messages-8) nsubj(transmit-5, Segment-3) ⋮

  5. Link Heuristics  Given two action units, should a link be made?  Match the properties of two action units based on their semantic group  Different strictness levels of matching : 0 (least strict) to 3 (most strict) Affirmative-Inclusive Agent match level 0 Theme match level 2  A domain specific ontology is used to allow for hierarchical matching and to relate equivalent terms.

  6. Overall System Vector Space Model  Similar to Latent Semantic Indexing   Rank generated links

  7. Mean Average Precision  Do relevant links appear at the top of the ranked list?  On average what percentage of irrelevant links are seen before seeing a relevant one? 𝑠 = 𝑆𝑏𝑜𝑙 𝑝𝑔 𝑢𝑏𝑠𝑕𝑓𝑢 𝑂 σ 𝑠=1 (𝑄𝑠𝑓𝑑𝑗𝑡𝑗𝑝𝑜 𝑠 × 𝑗𝑡𝑆𝑓𝑚𝑓𝑤𝑏𝑜𝑢 𝑠 ) 𝑄𝑠𝑓𝑑𝑗𝑡𝑗𝑝𝑜 𝑠 = 𝑄𝑠𝑓𝑑𝑗𝑡𝑗𝑝𝑜 𝑝𝑔 𝑚𝑗𝑡𝑢 𝑣𝑞𝑢𝑝 𝑠 𝐵𝑄 = 𝑆𝑓𝑚𝑓𝑤𝑏𝑜𝑢𝐸𝑝𝑑𝑣𝑛𝑓𝑜𝑢𝑡 𝑗𝑡𝑆𝑓𝑚𝑓𝑤𝑏𝑜𝑢 𝑠 = ቊ1 𝑗𝑔 𝑠 𝑠𝑓𝑚𝑓𝑤𝑏𝑜𝑢 0 𝑝𝑢ℎ𝑓𝑠𝑥𝑗𝑡𝑓
