HILTI: An Abstract Execution Environment for Deep, Stateful Network Traffic Analysis Robin Sommer International Computer Science Institute, & Lawrence Berkeley National Laboratory robin@icsi.berkeley.edu http://www.icir.org/robin

A Tale of Three Open-Source IDS Shared functionality? Essentially none. Suricata Same for packet filters, firewalls, proxies, routers, switches, OS stack … 2 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Deep Packet Inspection Internal Tap Internet Network IDS Example: Finding downloads of known malware.
 1. Find and parse all Web traffic. 2. Find and extract binaries. 3. Compute hash and compare with database. 4. Report, and potentially kill, if found. 3 HILTI — A High-Level Intermediary Language for Traffic Inspection.

DPI Architecture Application Common primitives & idioms — but hardly Configuration, any reuse … User Interface logs, alarms … and that even Signature matching, Analysis Logic though this stuff is policy enforcement hard. Pattern matching, packet classification, Analysis Primitives event correlation, Why? multiplexing Different low-level Flow table, DFAs, State Management request/reply correlation structure & data flows. IP, TCP, HTTP, Protocol Parsing DNS No “common language”. Network Traffic 4 HILTI — A High-Level Intermediary Language for Traffic Inspection.

A High-Level Intermediary Language for Traffic Inspection Application Host Application User Interface Analysis Compiler Firewall rules, Analysis Logic IDS signatures, forwarding rules, … Analysis Primitives HILTI Abstract Machine Library of Intermediary language Reusable State Management Functionality Execution Model LLVM-based compiler Runtime library Protocol Parsing Reusable components Network Traffic 5 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Example: BPF Filters host 192.168.1.1 or src net 10.0.5.0/24 type IP::Header = overlay { hdr_len: int<8> at 0 unpack UInt8InBigEndian (0, 3), version: int<8> at 0 unpack UInt8InBigEndian (4, 7), [...] src: addr at 12 unpack IPv4InNetworkOrder, dst: addr at 16 unpack IPv4InNetworkOrder } bool filter(ref<bytes> packet) { local addr a1, a2 local bool b1, b2, b3 a1 = overlay.get IP::Header src packet b1 = equal a1 192.168.1.1 a1 = overlay.get IP::Header dst packet b2 = equal a2 192.168.1.1 b1 = or b1 b2 b2 = equal 10.0.5.0/24 a1 b3 = or b1 b2 return b3 } 6 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Instruction Set Bitsets Packet input Booleans Packet classification CIDR masks Packet dissection Callbacks Ports Closures Profiling Channels Raw data Debug support References Doubles Regular expressions Enumerations Strings Exceptions Structs File i/o Unions Flow control Time intervals Hashmaps Timer management Hashsets Timers IP addresses Times Integers Tuples Lists Vectors/arrays 7 HILTI — A High-Level Intermediary Language for Traffic Inspection.

HILTI Machine Model Focus Areas Rich Domain-specific Data Types Flexible Control Flow Concurrent Analysis Robust & Secure Execution Comprehensive Host Interface Real-time Performance Debugging & Profiling Support High-level Optimization 8 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Implementation: The HILTI Toolchain Host Application HILTI Environment LLVM Toolchain App Core C Interface Stubs HILTI Analysis Analysis HILTI LLVM Compiler/ Native Machine Specification Compiler Compiler Bitcode Linker Executable Code Runtime Library Just-in time via C++ API 9 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Hello, World! module Main import Hilti void run() { call Hilti::print("Hello, World!") } hello.hlt # hilti-build hello.hlt -o a.out && ./a.out Hello, World! # hiltic -j hello.hlt Hello, World! 10 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Can HILTI support complex applications? 11 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Application Case Studies BPF Filter Stateful Firewall Protocol Parsing Bro Script Execution 12 HILTI — A High-Level Intermediary Language for Traffic Inspection.

BinPAC - A Yacc for Network Protocols Grammar example: Parsing SSH banners. SSH-2.0-OpenSSH_3.8.1p1 type SSH::Banner = unit { magic : /SSH-/; version : /[^-]*/; dash : /-/; software: /[^\r\n]*/; } BinPAC compiles grammar into HILTI parser. HILTI compiles parser into executable code just-in-time. Bro plugin integrates parsers at startup. 13 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Hello, World! type SSH::Banner = unit { magic : /SSH-/; version : /[^-]*/; dash : /-/; software: /[^\r\n]*/; } ssh.pac2 grammar ssh.pac2; protocol analyzer SSH over TCP:
 parse with SSH::Banner, port 22/tcp; on SSH::Banner ssh.evt -> event ssh_banner(self.version, self.software); event ssh_banner(version: string, software: string) { { print software, version; } ssh.bro # bro -r ssh.trace ssh.evt ssh.bro OpenSSH_3.9p1, 1.99 OpenSSH_3.8.1p1, 2.0 14 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Application Case Studies BPF Filter Stateful Firewall Protocol Parsing Bro Script Execution 15 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Bro Scripts Script example: A simple scan detector. global attempts: table[addr] of count &default=0; event connection_rejected(c: connection) { local orig = c$id$orig_h; # Get originator address. local n = ++attempts[orig]; # Increase counter. if ( n == SOME_THRESHOLD ) # Check for threshold. NOTICE(...); # Alarm. } Bro plugin compiles scripts into HILTI code. HILTI compiles that into executable code just-in-time. 16 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Evaluation Use HILTI plugin for Bro to compare parsing & script execution with a native Bro. Traces: HTTP: 1/25 of Berkeley port 80 traffic. 30GB trace, 52min, 340k messages. DNS: Full Berkeley port 53 traffic. 1GB trace, 10min, 65M messages. Correctness Performance HILTI captures Let’s see. semantics correctly. 17 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Protocol Parsing HTTP 6tanGaUG 683G 643G 241G 1567G HIL7I 852G 450G 21G 258G 1580G 1.25x Protocol PDrsing DNS 6cULSt ExHcutLon HIL7I-to-BUo GOuH 6tanGaUG 177G 356G 180G 712G 2thHU HIL7I 469G 405G 81G 217G 1173G 2.65x 0.0B 0.2B 0.4B 0.6B 0.8B 1.0B 1.2B 1.4B 1.6B 1.8B C38 cycOHs 18 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Bro Scripts HTTP 6tanGaUG 683G 635G 244G 1562G HIL7I 698G 781G 76G 254G 1810G 1.23x DNS 3UotocoO 3aUsLng ScriSt ExHcution 6tanGaUG 175G 358G 176G 709G HIL7I-to-BUo GOuH 2thHU HIL7I 175G 243G 139G136G 694G 0.68x 0.0B 0.5B 1.0B 1.5B 2.0B C38 cycOHs 19 HILTI — A High-Level Intermediary Language for Traffic Inspection.

Summary HILTI: A new platform for network traffic analysis. A compiler-target for host applications to leverage. Provides common data structures and control flow primitives. Case studies demonstrate aptness of design. Packet filter, stateful firewall, protocol parsing, Bro scripts. Initial performance experiments encouraging. Not too different from native applications. It’s still a prototype, with lots of potential. Sommer/Vallentin/De Carli/Paxson: “HILTI: An Abstract Execution Environment for Deep, Stateful Network Traffic Analysis”. ACM IMC 2014. 20 HILTI — A High-Level Intermediary Language for Traffic Inspection.

The HILTI Vision Transparent improvement under the hood. Performance Integration of non-standard hardware. via Abstraction High-level compiler optimizations. Automatic parallelization. ❊ Means and glue to share functionality. Facilitate Reuse HILTI library of common high-level components. HILTI is available under BSD license at http://www.icir.org/hilti ❊ De Carli/Sommer/Jha: “Beyond Pattern Matching: A Concurrency Model for Stateful Deep Packet Inspection”. ACM CCS 2014.
