GTC EUROPE 2017 Mehmet TUN (Mech. Eng. M.Sc.) 10-12 Oct, Munich - PDF document

1 FNSS Savunma Sistemleri A.S. Proprietary Information. The information contained in this document is FNSS Savunma Sistemleri A.S. proprietary information and is disclosed in confidence. It is the property of FNSS Savunma Sistemleri A.S: and shall not be used, disclosed to others or reproduced without the express written consent of FNSS Savunma Sistemleri A.S. PLM, Configuration Management and TDP Development Department Manager GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE GTC EUROPE 2017 Mehmet TUNÇ (Mech. Eng. M.Sc.) 10-12 Oct, Munich

SUMMARY 2 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

My Last Holiday Days Before Conference The 30th Integrated Process Excellence Symposium, 18-20 Sep 2017, Orlando - 3 COMMERCIAL IN CONFIDENCE

My Last Holiday Days

My Last Holiday Days

AGENDA  FNSS Company Profile  FNSS CAD Environment  FNSS 3D CAD Virtualization Project  Current Status  Summary & Benefits  Next Steps & Lessons Learned 69 Slides 40 Minutes 6 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Company Profile 7 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS Profile  Established in 1989, Gölbaşı / Ankara  Leading manufacturer and supplier of tracked and wheeled armored vehicles and weapon systems. Vision Globally trusted and respected Turkish partner in defense Mission We protect and add value to our users and stakeholders by creating innovative solutions 8 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS Product Evolution TEBER-30 RCT ACV-15 CLAW SSM AAV (ZAHA) Development Contract Remote Controlled AV-8 8x8 WAV Contract Contract Turret Development KAPLAN-20 NGAFV SSM ACV-15 Development Contract SSM ACV-15 AAPC PARS 6x6 PARS 8x8 KAPLAN Contract Armoured Wheeled Modern Medium WAV Development LAWC-T TEBER-30 Vehicle Development Weight Tank Development 2-Man Turret Development Development Contract 1990-94 1996-2000 2002 2004 2006 2008 2010 2012 2013 2015 2016 2017 PARS III M113 6x6 – 8x8 WAV Modernization SSM AAAB Contract Studies ACV-19 Contract Development ACV-SW SSM PARS Air Defense 4X4 WCV Contract Platform Contract SSM M113 Modernisation SSM AACE ATGM Turret ACV-15 SABER 25 Contract SSM KAPLAN-15 Contract Contract Turret Development WCV Contract Licensed Manufacturer Indigenous Product Manufacturer 9 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Products 1/3 10 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Products 2/3 11 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Products 3/3 12 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS VIDEO 13 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

AGENDA  FNSS Company Profile  FNSS CAD Environment  FNSS 3D CAD Virtualization Project  Current Status  Summary & Benefits  Next Steps & Lessons Learned 14 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Department Profile IT Engineering and R&D PLM, CM and TDP Development Department Configuration Technical Data CAD PLM Management Package Prep. Management Systems  Managing PLM environment and CAD processes  Technical data package preparation and knowledge management  Managing configuration related operational activities 15 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

CAx INFRASTRUCTURE CAx Domain CAE CAD  Isolated Network (10 Gb/s) • CATIA V6 • ANSYS Operation Backup WS GPU Server • 3DVIA • LSDYNA System • SOLIDWORKS • ADAMS Thin Client Virtualisation • Q-CHECKER • MATLAB • AUTOCAD • HYPERMESH • CADDS5 • EAGLE PLM • JACK • ENOVIA • RHINO CAM • VESYS • DELMIA • CATIA • GRANTA • 3DVIA • FRACAS • NX • AUTO.STUDIO • SIGMANEST • MATHCAD DB  ORACLE  MS SQL 16 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS CAD & HW HISTORY 1989 2013 May 2004 17 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

AGENDA  FNSS Company Profile  FNSS CAD Environment  FNSS 3D CAD Virtualization Project  Current Status  Summary & Benefits  Next Steps & Lessons Learned 18 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

AGENDA  FNSS Company Profile  FNSS CAD Environment  Requirement / Purpose  FNSS 3D CAD Virtualization Project  Current Status  Summary & Benefits  Next Steps & Lessons Learned 19 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

vGPU NEED ? • Classically, a CAD or a CAE user needs a Workstation Computer for doing his/her tasks 20 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

vGPU NEED ? • High capacity (and Costly !) WS’s purchased for full time CAD users & Drafters  WS’s renewed periodically for same group of people 21 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Heavy User Vs Light User • (*) British Short Hair 22 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

vGPU NEED ? • Lower Cost or Older WS’s are provided to partial CAD users and light users. • They have problems when they work with extra-large assemblies ! 23 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

vGPU NEED ? • My Dream / Requirement: • Centrally located powerful WS’s or Servers • Allocate it to the partial/light CAD users via remote desktop, whenever they need additional power for large assemblies • Cut the expenses for buying high capacity expensive WS to each & every CAD user. 24 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

vGPU NEED ? • Requirement was absolutely a dream previous years… • GPU HW and the technology was not adequate • Remote access SW capabilities were not good enough • My different attempts failed 25 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

AGENDA  FNSS Company Profile  FNSS CAD Environment  Initiation and First Part  FNSS 3D CAD Virtualization Project  Current Status  Summary & Benefits  Next Steps & Lessons Learned 26 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

START UP of the PROJECT • A software solution provider come to us (2014, March) and say the magical words... • ‘’ Nvidia Grid Technology is a game changer’’ • ‘’ vGPU user community is increasing, there are many companies investing and using it.’’ • ‘’We have applied it in several universities, institutions, etc..’’ • ‘’Our software is the best; it is %10 faster to competitor and more reliable’’ • We initiated a market search & feasibility study 27 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS CAD & HW HISTORY vGPU Feasibility Study ??? 1989 2014 March 2013 2004 28 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

VDI Technology 29 DELL EMC FORUM, 3 Oct 2017, İstanbul - COMMERCIAL IN CONFIDENCE

NVDIA GRID TECHNOLOGY 30 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

START UP of the POC • We asked for a POC study • SW company proposed another solution partner (?!) • Studies initiated (2014, September) • POC Lasted 3 months, • Vendor’s demo & testing server (Fujitsu R920) & 2 thin clients installed • IT and PLM groups were busy with other operational tasks (as most of the times !), • There were problems, but it is said to be solved with real server deployment and real effort & concentration... • Studies were found to be successful • GO decision given 31 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS CAD, HW & vGPU HISTORY vGPU Feasibility Sudy 1989 2014 March 2013 May 2004 2014 Sep-Nov 32 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

FNSS CAD, HW & vGPU HISTORY vGPU Feasibility Purchase Study 1989 2014 March 2013 May 2004 2014 Sep-Nov 2015 Feb 33 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

Purchase of the Initial HW & SW • First Group HW and SW are purchased (2015, Feb.) • 5 Servers (Dell PowerEdge R720, Intel Xeon E-26XX v2 Processors, Intel Xeon E5-2670 2.5 GHGz 25M Cache, 8.0GT/s QPI Turbo, HT, 10 C 1866 MHz, 24 X 16GB RDIMM 1600 MHz, 2 X NVIDIA GRID K2 GPU) • 35 Dell thin clients, (DELL WYSE Z90Q8 - 16GF/4GR - QUAD CORE) • 35 XenDesktop (Platinium) • Service Agreement is signed 34 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

DEPLOYMENT OF HW & SW • HW and SW are installed (Feb 2015) 35 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE

First Part 1/6 • Server deployments are completed. • 5 clients are provided to some key users. • WS’s are kept below the ir desk as a failsafe mechanism. • After some period, performance issues and compatibility problems with Catia V6 is observed. • WS are taken back to service ! 36 GTC EUROPE 2017, 10-12 Oct, Munich - COMMERCIAL IN CONFIDENCE
