GAMS: A POWERFUL OPTIMIZATION TOOL AND ITS INTERFACE TO MATLAB Muhammad Ismail

Outline 2 Introduction GAMS Input File GAMS Output MATLAB Interface

Introduction 3 - GAMS = General Algebraic Modeling System - Model linear, nonlinear, and mixed integer optimization problems - GAMS can be downloaded from its home page: http://www.gams.com/ - Without a valid GAMS license, GAMS will operate as a free demo with limitations on number of constraints and variables [GAMS license is placed, when available, in the GAMS directory]

GAMS Structure and MATLAB Interface 4 MATLAB GAMS GAMS Input File GAMS Output File Compilation (name.gms) (name.lst) Optimization Solver

Outline 5 Introduction GAMS Input File GAMS Output MATLAB Interface

GAMS Input File Structure 6 Correspond to indices in you Sets problem Can be: parameters, tables, Data and scalar Can be: free (- ∞,+∞), + ve, -ve, Variables binary, integer Equations Equalities and inequalities Model & Call Solver LP , NLP , MIP , MINLP

Problem Example 7 - Consider 𝑂 networks with overlapped coverage and 𝑁 users - Out of 𝑁 users, we have: 𝑁 1 users can get service (bandwidth) using only single-network 𝑁 2 users can get service (bandwidth) using all available networks, i.e. multi-homing - Obj.: Find network assignment for single-network users and bandwidth allocation for both single-network and multi-homing users which maximizes some utility function

Mathematical Formulation 8 Assignment variable Bandwidth allocation variable Binary Positive Max {log 1 + 𝑦 𝑜𝑛 𝑐 𝑜𝑛 − 𝑞 𝑜𝑛 𝑦 𝑜𝑛 𝑐 𝑜𝑛 } 𝑜 𝑛 S.t. 𝐶 𝑛𝑗𝑜,𝑛 ≤ 𝑦 𝑜𝑛 𝑐 𝑜𝑛 ≤ 𝐶 𝑛𝑏𝑦,𝑛 ∀𝑛 𝑜 Priority parameter 𝑦 𝑜𝑛 𝑐 𝑜𝑛 ≤ 𝐷 𝑜 ∀𝑜 Matrix  Table 𝑜 𝑦 𝑜𝑛 = 1, 𝑦 𝑜𝑛 = 0,1 , ∀𝑛 ∈ 𝑁 1 Total max. and 𝑜 min. required Capacity of each network 𝑦 𝑜𝑛 = 1, ∀𝑛 ∈ 𝑁 2 BW Vector Vector Problem  MINLP

GAMS Input File 9 𝑂, 𝑁 Sets 𝑞 𝑜𝑛  Table, 𝑔  Scalar Data 𝐷 𝑜 , 𝐶 𝑛𝑏𝑦,𝑛 , 𝐶 𝑛𝑗𝑜,𝑛  parameters 𝑦 𝑜𝑛  Binary Variables 𝑐 𝑜𝑛  Positive 𝑨  free Equations Objective function and constraints (equalities and inequalities) Model & Call Solver MINLP , solver = BARON

GAMS Input File Cont. 10 1. Sets: Sets names Set declaration Sets members End Set declaration Comments 2. Data: Table name  Domains = rows and columns Table declaration Columns = same as M Rows = same as N Data End Table

GAMS Input File Cont. 11 2. Data Cont.: Parameters Declaration Scalar Scalar Name Declaration Scalar Value End Parameters Names Data 3. Variables: Declare Obj. fn. Value Variables BW & Assign. And Domain End Variables types Parameters z = free by default Declaration

GAMS Input File Cont. 12 4. Equations: Declare Equations Equations Names and End Equations Domain = ≤ Condition: ≥ Apply this only for M = 1:3, i.e. only for multi- homing users

GAMS Input File Cont. 13 4. Model & Call Solver: Problem Type Solver Name Problem Modeling Maximize obj. fn.

GAMS Input File Cont. 14 Problem type & Solver Sets Equations Data Model & Solve Variables

Outline 15 Introduction GAMS Input File GAMS Output MATLAB Interface

GAMS Outputs 16 Run your Model Name of my GAMS input file

GAMS Outputs Cont. 17 Listing file Check the results of your variables B is a Matrix 𝐶 = 0.101 … . Rows = 0.411 … . Networks Columns = Users Add bounds  Necessary for BARON to guarantee global optimality

GAMS Outputs Cont. 18 Double click on error gives you its location in your code

Outline 19 Introduction GAMS Input File GAMS Output MATLAB Interface

MATLAB Interface 20 Why? - Test how performance changes with some parameters, e.g. how does bandwidth allocation changes with number of users? - If you have a simulation on MATLAB and part of your MATLAB code needs to solve a complex optimization problem - Better view of your results  Matrix form, or a plot GDX Utilities  GAMS Data Exchange

MATLAB Interface Cont. 21 Step 1: Update MATLAB Path to Include GAMS Directory: MATLAB: File > Set path > Add folder Browse Add

MATLAB Interface Cont. 22 Step 2: Update System Variables to Include GAMS Directory: Computer: Right click > Properties > Advanced system settings Environment Variables Edit and Type GAMS Path

MATLAB Interface Cont. 23 Step 3: Modify your GAMS Input File: No members 1. Open a file tstdat.gdx: “ gdxin No Values filename”  tstdat created by MATLAB 2. Load set members and parameters values from this file Comes from MATLAB 3. Close the file: “ gdxin ” Put the variables you want to read ; on MATLAB in file tstsol.gdx

MATLAB Interface Cont. 24 Step 4: MATLAB File: A. Create MATLAB function: inputs = set members and parameters data, outputs: problem variables B. Define Sets Same as in my GAMS input file

MATLAB Interface Cont. 25 C. Define Parameters Vector Scalar Table

MATLAB Interface Cont. 26 D. Write Values in tstdat.gdx Write function E. Run the GAMS Input File Avoid crash Function: Run Name of my with loops GAMS input file GAMS input file

MATLAB Interface Cont. 27 F. Read GAMS Results on MATLAB My GAMS Variables Read function

MATLAB Interface Cont. 28 Define sets Define Parameters Write set members and Run GAMS input file parameters values Read GAMS results

MATLAB Interface Cont. 29 G. Save GAMS Input File and MATLAB function on Same Directory H. On MATLAB Command Window Input Data Run GAMS and Read Results Results

MATLAB Interface Cont. 30 Also, I can make a for loop in MATLAB on one of the parameters and fix other parameters to study some performance and plot results on MATLAB

Summary 31 Introduction GAMS Input File GAMS Output MATLAB Interface
