Future Urban networks including Penlink January 2017

2 • Networks supported by Auckland Transport, Auckland Council and NZTA in late 2016

3 Insert updated growth movie

4 Unitary Plan Zoning

5 Penlink - Key Objectives Penlink is effective in reducing traffic through the Silverdale Interchange – thereby freeing up transport capacity for housing development in Wainui, Silverdale West and approved development on the Whangaparoa peninsula. GOLF COURSE REDEVELOPMENT WAINUI SILVERDALE INTERCHANGE TOP HARBOUR DEVELOPMENT SILVERDALE WEST LESS TRAFFIC MORE TRAFFIC

6 Penlink movie • https://www.youtube.com/watch?v=6emPmT9V2Lg

7 Penlink Project Cost The November 2013 business case for implementation of Penlink concluded the project: • Achieved the strategic objectives of improved travel times, improved network performance and the promotion of economic activity. • Had a sound economic case with a benefit cost ratio (BCR) of 2.9, giving it a Medium efficiency funding rating in terms of the NZTA funding profile at the time. • The project was given an HMM profile in the LTP. Total design and construction costs were estimated to be $282m plus contingency of $72m. Funding of the project through a tolling regime and private financing was considered. However funding constraints consigned the project to the second decade in the LTP.

8 Penlink - ATAP Strategic response

9

10

11 Proposed Proposed

12

13 Current progress • Penlink – business case completed / designation secured / early works undertaken as part of Weiti development • Wainui Live zones – identification of arterial roads with land owners • Route protection of future urban strategic corridors by 2022
