Flood Fighting Structures Demonstration and Evaluation Program (FFSD) George Sills Infrastructure Conference August 2005 Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers Flood


  1. Flood Fighting Structures Demonstration and Evaluation Program (FFSD) George Sills Infrastructure Conference August 2005 Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  2. Flood Fighting Structures Demonstration and Evaluation Program (FFSD) 1. Background 2. Product Selections 3. Laboratory Testing 4. Field Testing 5. Product Summaries Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  3. Not a New Problem Lake Chicot Sand Boil (1973) Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  4. Background Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  5. Background Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  6. Flood Fighting Structures Demonstration and Evaluation Program (FFSD) Authorization 2004 Energy and Water Development Bill “The conferees therefore direct the Corps of Engineers to act immediately to devise real world testing procedures for Rapid Deployment Flood Wall (RDFW) and other promising alternative flood fighting technologies.” Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  7. FFSD Study Team Leaders Laboratory Testing Dr. Johannes Wibowo (GSL) Perry A. (Pat) Taylor (GSL) Dr. Donald Ward (CHL) Field Testing George Sills (GSL) Fred Pinkard (CHL) Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  8. Product Selections 1. Congressional Directive – Rapid Deployment Flood Wall (RDFW) 2. Standard for Comparison - Sandbags RDFW Sandbag Structure Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  9. Product Selections 1. Develop Evaluation/Selection Criteria 2. Issue Solicitation for Technical Proposal • 9 Proposals Received • Categories – Product Type Impermeable Liner (with or without frame) Granular Filled Container Water Filled Bladder 3. Evaluate Proposals and Make Selections • Based on Technical Merit Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  10. Product Selections • Competitive Technical Proposals Hesco Bastion Portadam Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  11. Evaluation Parameters 1. Product Requirements 2. Tests Static Loading Footprint and ROW requirements Overtopping Durability Wave Impact Ease of Construction and Removal Debris Impact Time / Manpower/ Equipment Adaptability to Varying Terrain 3. Performance on Seepage Various Surfaces Fill Requirements Freshly Graded Grass / Weeds Cost Finished Concrete Repair and Reusability Ability to Raise During Flood Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  12. Laboratory Testing Construction Footprint Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  13. Laboratory Testing RDFW Sandbag Structure Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  14. Laboratory Testing Debris Impact Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  15. Laboratory Results Construction Removal Effort Effort Structure (man hours) (man hours) Portadam 24.4 4.4 Hesco 20.8 13.4 Sandbags 205.1 9.0 RDFW 32.8 42.0 Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  16. Laboratory Results Seepage 2.0 1.8 1.6 1.4 Gpm/ft 1.2 1.0 0.8 0.6 0.4 0.2 0.0 Sandbags Hesco- RDFW Portadam Bastion Static 1 ft Static 2 ft Static 95% Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  17. Field Testing Site Selection Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  18. Portadam Hesco Bastion Vicksburg Harbor Test Site Sandbag Structure RDFW Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  19. Portadam Structure Testing Construction Removal Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  20. Hesco Bastion Structure Testing Removal Construction Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  21. Hesco Bastion Installation Modification Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  22. Sandbag Structure Testing Construction Removal Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  23. RDFW Structure Testing Removal Construction Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  24. RDFW Post Testing Modifications • Color Coded for Accurate Installation • Rounded Corners • Suction Trailer Available to Expedite Removal Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  25. Field Testing Construction and Removal Construction Removal Time Effort Time Effort Structure (hours) (man hours) (hours) (man hours) Portadam 5.1 26.2 2.9 12.6 Hesco Bastion 8.9 57.5 8.7 36.3 Sandbags 30.5 453.1 2.6 3.5 RDFW 7.5 48.4 17.3 113.4 Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  26. Field Testing Seepage 7000 6000 Seepage (Gallons/Hour) 5000 4000 3000 2000 1000 0 0 100 200 300 400 500 600 700 Wetted Surface Area (Square Feet) Sandbags RDFW Hesco Bastion Portadam Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  27. Field Testing - Damage Portadam None - 100% reusable Hesco Bastion Bent some panels and coils Over 95% reusable Sandbags Bags began to deteriorate All sandbags disposed RDFW Broke some unit pieces 95% of pieces reusable Coastal and Hydraulics Laboratory Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory Geotechnical and Structures Laboratory of Engineers

  28. Portadam Summary Strengths • Ease of Construction/Removal (Time, Manpower, Equipment) • Low seepage rates • No fill required • High degree of reusability • Least ROW Required Weaknesses • Punctured during debris impact test • Can’t be raised in typical application Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  29. Hesco Bastion Summary Strengths • Ease of Construction/Removal (Time, Manpower) • Low cost • High degree of reusability • Can be raised Weaknesses • Significant ROW required due to granular fill • Highest seepage rates Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  30. Sandbag Summary Strengths • Cost (volunteer / prison labor) • Conforms well to varying terrain • Low seepage rates • Can be raised Weaknesses • Very labor intensive • Not reusable Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  31. RDFW Summary Strengths • Ease of construction (Time, Manpower) • Low seepage rates • High degree of reusability • Can be raised (8 inch units) Weaknesses • Significant ROW required due to granular fill • High cost • Most difficult to remove Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  32. Remaining Work 1. Place testing data and results on publicly accessible web page. 2. Conduct pilot tests at 3 locations around the country. Philadelphia / Baltimore Districts Omaha District Sacramento District 3. Use purchased products in actual flood events. Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers

  33. Flood Fighting Structures Demonstration and Evaluation Program Coastal and Hydraulics Laboratory ERDC US Army Corps Geotechnical and Structures Laboratory of Engineers
