Why model abundance spatially? Why model abundance spatially? 2 / 52 2 / 52
Maps Maps 3 / 52 3 / 52
Black bears in Alaska Heterogeneous spatial distribution 4 / 52
Spatial decision making Spatial decision making 5 / 52 5 / 52
Block Island, Rhode Island First offshore wind in the USA Spatial impact assessment 6 / 52
Back to regular distance sampling Back to regular distance sampling 7 / 52 7 / 52
How many animals are there? (500!) 8 / 52
Plot sampling 9 / 52
Strip transect 10 / 52
Detectability matters! We've assumed certain detection so far This rarely happens in the field Distance to the object is important Detectability should decrease with increasing distance 11 / 52
Distance and detectability Credit Scott and Mary Flanders 12 / 52
Line transect 13 / 52
Line transects - distances 14 / 52
Distance sampling animation 15 / 52
Detection function 16 / 52
Distance sampling estimate Surveyed 5 lines (each area 1 2 0.025) ∗ ∗ Total covered area 5 1 (2 0.025) = 0.25 𝑏 = ∗ ∗ ∗ Probability of detection 0.546 𝑞 ̂ = Saw 76 animals 𝑜 = Inflate to 139.198 𝑜 / = 𝑞 ̂ Estimated density 556.8 𝑜 / 𝑞 ̂ ̂ 𝐸 = = 𝑏 Total area 𝐵 = 1 Estimated abundance 556.8 𝑂 ̂ ̂ = 𝐸 𝐵 = 17 / 52
Reminder of assumptions 1. Animals are distributed independent of lines 2. On the line, detection is certain 3. Distances are recorded correctly 4. Animals don't move before detection 18 / 52
What are detection functions? ℙ (detection | animal at distance 𝑦 ) "Integrate out distance" == "area under curve" == 𝑞 ̂ Many different forms, depending on the data All share some characteristics 19 / 52
Fitting detection functions (in R!) Using the package Distance Function ds() does most of the work More on this in the practical! library (Distance) df_hn <- ds(distdata, truncation=6000) 20 / 52
Horvitz-Thompson-like estimators Once we have how do we get ? 𝑂 ̂ 𝑞 ̂ Rescale the (flat) density and extrapolate 𝑜 study area 𝑡 𝑗 𝑂 ̂ = covered area ∑ 𝑞 ̂ 𝑗 𝑗 =1 are group/cluster sizes 𝑡 𝑗 is the detection probability (from detection function) 𝑞 ̂ 𝑗 21 / 52
Hidden in this formula is a simple assumption Probability of sampling every point in the study area is equal Is this true? Sometimes. If (and only if) the design is randomised 22 / 52
Many faces of randomisation 23 / 52
Randomisation & coverage probability H-T equation above assumes even coverage (or you can estimate) 24 / 52
Extra information 25 / 52
Extra information - depth 26 / 52
Extra information - SST 27 / 52
We should model that! We should model that! 28 / 52 28 / 52
DSM �ow diagram 29 / 52
Modelling requirements Account for effort Flexible/interpretable effects Predictions over an arbitrary area Include detectability 30 / 52
Accounting for e�ort Accounting for e�ort 31 / 52 31 / 52
E�ort Have transects Variation in counts and covars along them Want a sample unit w/ minimal variation "Segments": chunks of effort 32 / 52
Chopping up transects Physeter catodon by Noah Schlottman 33 / 52
Flexible, interpretable e�ects Flexible, interpretable e�ects 34 / 52 34 / 52
Smooth response 35 / 52
Explicit spatial e�ects 36 / 52
Predictions Predictions 37 / 52 37 / 52
Predictions over an arbitrary area Don't want to be restricted to predict on segments Predict within survey area Extrapolate outside (with caution) Working on a grid of cells 38 / 52
Detection information Detection information 39 / 52 39 / 52
