Autogenerating Algorithms and Data Structures Exams

Gerth Stølting Brodal

Algorithms and Data Structures Retreat, Sandbjerg, Denmark, March 3, 2020

Algorithms and Data Structures Cource

ADS 10 ECTS, 2nd semester

1991 - 2003 Written exam

ADS 1 5 ECTS, 2nd semester

2004 - 2014 Multiple choice + short answers 2015 - 2017 Multiple choice

ADS 2 5 ECTS 2nd semester

2004 - 2017 Written

ADS 10 ECTS, 1st semester

2017 Multiple choice + written question 2018 - Multiple choice

𝑥 = question weight 𝑟 = # subquestions 𝑙 = # answer options score = ቐ no answer 𝑥/𝑟 correct −𝑥/(𝑟 𝑙 − 1 ) wrong

Previously exercises made manually with LaTeX + xfig

xfig

• Vector based drawing program
• First version 1985
• Early version for Unix, later Linux
• Runs on Windows 10 using

Cygwin X-server

• Allows LaTeX in text fields

PostScript / pdf

• Transfig: fig +

latex (same font in figures + text)

• Due to lack of support, for a period numbers should be type in

right-to-left, e.g. “125” as “5” “2” “1”

Compiling LaTeX document – perl script

main.tex A.fig B.fig list of figures perl script A.ps A.tex B.ps B.tex ∙∙∙ transfig main.dvi latex dvips main.ps pstopdf main.pdf .pdf .pdf pdflatex

Fall 2019 Is Is it it possible to autogenerate ADS exams ?

• Essentially all questions are standard question, many of the form

“What does algorithm X output on input Y ?”

• Must come up with two exams every year (ordinary + reexam)
• Provide students with (extremely) representative test exam to train on
• Special in Fall 2019, could not make exam due to COI (thanks Kasper)
• Excuse for doing some Python programming

Status

• Can currently autogenerate ≈ 2/3 of an ADS exam
• Missing topics:
• dynamic programming
• loop invariants
• amortized analysis
• augmented search trees
• 3.000+ lines of Python code

main.py ads-exam.tex ads-pdf-form.tex ads-solutions.tex ads-selftest.tex (embeded JavaScript) ads-exam.pdf ads-pdf-form.pdf ads-solutions.pdf ads-selftest.pdf pdflatex

The autogeneration of a question

• Generate random input
• Run correct algorithm
• Run “obvious wrong” algorithms

Retries: Q32:1 Q34:1 Q35:1 Q36:1 Q38:1 Q40:1 Q41:1 Q42:4 Q47:1 Q50:1 Q52:5 Q53:7 Q54:6 Q55:6 Q56:3 Q57:2 Q58:15 Q59:3 Q60:5 Q68:1 Q71:1115 Q72:4129 Q73:3772 Q74:240 Q75:589 Q76:1696 Q77:719 Q78:388 Q79:1030 Q80:407 Q81:40 Q82:19 Q83:34 Q84:69 Q85:7 Q86:24 Q87:38 Q88:16 Q89:11 Q90:5 Q91:4 Q92:10 Q93:15 Q94:4 Q95:15 Q96:6 Q97:2 Q98:9 Q99:6 Q100:6 Q101:5 Q102:13 Q103:5 Q104:22 Q105:22 Q106:16 Q107:5 Q108:15 Q109:18 Q110:17 Q111:17 Q112:3 Q113:43 Q114:20 Q115:4 Q116:25 Q118:8 Q119:13 Q120:28 Q121:34 Q122:29 Q123:29 Q124:12 Q125:35 Q126:20 Q127:6 Q128:13 Q129:24 Q130:3 Q131:2 Q132:22 Q133:151 Q134:33 Q135:13 Q136:38 Q137:9 Q138:39 Q139:80 Q140:6 Q143:1 Q144:1 Q148:1 Q150:1 Q151:22 Q152:12 Q154:12 Q155:2 Q156:5 Q159:9 Q160:7 Q161:1406 Q162:22 Q163:777 Q164:2807 Q165:2739 Q166:52 Q167:221 Q168:831 Q169:20 Q170:1921 Q171:3 Q172:4 Q174:2 Q175:2 Q176:3 Q177:1 Q180:2 Q181:25 Q182:36 Q183:165 Q184:42 Q185:3 Q186:15 Q187:104 Q188:9 Q189:3 Q190:30 Q191:380 Q192:92 Q193:172 Q194:21 Q195:82 Q196:16 Q197:58 Q198:19 Q199:55 Q200:127 Q201:2 Q203:7 Q204:1 Q205:2 Q206:4 Q208:1 Q209:3 Q210:1 Q219:1

radix-sort

repeat if input “non-interesting”

• r two identical answer options
• r two identical subquestions
• r ...

raise question.Retry('no valid coloring')

Figures – LaTeX “tikz” and “tikz-qtree”

PDF score evaluation (requires AcroRead)

• List of increasing complexity classes
• Random O, Ω or Θ
• Multiply/divide with random constant
• Added minor terms (terms permuted)
• Weight parameters
• Flip left/right expression uniformly

• Manually made 71 loop codes
• Simple ASCII-> LaTeX
• Hardness parameter (2, 1, 1)
• Favourite:

• Generate random skewed tree
• Fun with tikz

• Max-Heap-Insert options
• correct Max-Heap-Insert
• apply Build-Max-Heap
• insertion order
• decreasing order
• buggy Build-Max-Heap (wrong loop)
• Build-Max-Heap question
• same options
• Heap-Extract-Max
• correct ExtractMax
• buggy ExtractMax (leave hole at leaf)
• buggy ExtractMax (shift left to the right of hole)
• buggy ExtractMax (swap last into leaf hole)
• apply BuildMaxHeap after extraction

• Input
• random numbers
• must include max digit
• sorted suffix should have an

appropriate number of repetitions

• Options
• correct stable sorted
• unstable
• sort on prefix
• reversed suffix sorting
• totally sorted
• Requires many retries

• Input requirements
• must have initial collisions
• some updates must warp around
• updates not all identical hash values
• at least 2 different answers
• Quadratic and double hashing
• same

• Generate all colorings
• Options
• valid colorings
• root red
• red color of a node in a valid

solution moved to children

• Random tree
• Compute random colorings
• Select random insert
• Options
• correct restructuring
• red leaf without rebalancing
• black leaf without rebalancing
• random valid red-black tree

• Random union tree
• Options
• correct union find
• no path compression during union
• meld path compresses to new root
• link left below right, ignoring rank

• Random graph
• predefined set of families of graphs
• at least 6 nodes
• bidirectional 20 %
• Options
• BFS
• buggy BFS, push random order
• buggy BFS, pushed reversed 2nd half
• DFS

• Compute all valid BFS
• Check all nodes reachable
• Check at least 3 solutions
• For each valid solution add

random spanning tree

• Select 5 random from above

• Graph
• 6-10 nodes
• bidirectional 20 %
• check all nodes reachable
• 50-50 if finishing or discovery order
• 4 random edges
• check at least three edge types

• Options
• Dijkstra
• Dijkstra with missing distance

updates for the 2nd half

• BFS
• DFS

• Options
• correct MST by Prim
• Dijkstra
• buggy Prim (DFS version of Prim)
• Dijkstra on MST tree

• Random graph with max 5 nodes
• Compute all topological orders
• Check if DAG
• At most 3 correct topological orders
• Incorrect = correct + random swap

• Random graph
• edges bidirectional = 15 %
• If only 1 SCC, retry with 90 %
