DXA studio 40 Greene Avenue October 17, 2017
GREENE AVENUE 4 STORY 4 STORY 4 STORY 4 STORY BUILDING BUILDING BUILDING BUILDING CARLTON AVENUE ADELPHI AVENUE ADJ. 6 STORY BUILDING ADJ. 2 STORY 40 GREENE AVE BUILDING EX'G 1 STORY ADJ. 2 STORY COMMUNITY BUILDING GARDEN 1 STORY BUILDING 1 STORY N — 40 GREENE AVE SCALE As Noted 01 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
15 15 1940 TAX PHOTO 1976 HISTORIC PHOTO 2017 PHOTO 40 GREENE AVE · HISTORIC PHOTOS SCALE As Noted 02 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
PHOTOS CIRCA 1959 40 GREENE AVE · HISTORIC STAINED GLASS SCALE As Noted 03 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
REMOVE CROSSES RESTORE CAST IRON STEEPLE RESTORE WOODEN LOUVERS RESTORE DECORATIVE FINIALS RESTORE WOODEN WINDOW TRACERY AT ROSE WINDOW RESTORE STAINED GLASS, INCLUDING LEAD CAMES, GLAZING, AND COVER. DONATE “PAUL ROBESON THEATRE” SIGN TO LOCAL HISTORICAL SOCIETY REFURBISH HISTORIC WOOD DOORS AND ALL HISTORIC HARDWARE EAST DOOR TO BECOME INOPERABLE TO ALLOW FOR ADA ACCESIBLE ENTRY RAISE BASE OF RECESS 4” TO ALLOW FOR TRANSOM ABOVE NEW DOOR/WINDOWS REPAIR EXISTING STAIRS REMOVE BOARDED UP WINDOWS AND REPLACE WITH ADA ACCESIBLE ENTRY AND NEW WINDOWS REMOVE METAL GATE TO ALLOW FOR ADA ACCESIBLE ENTRY CELLAR ENTRYWAYS TO BE SEALED AND REPLACED WITH ADA ACCESIBLE ENTRY . BLOCKED DRAIN TO BE REPLACED 40 GREENE AVE · NORTH ELEVATION SCALE As Noted 04 894 6th Avenue — CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
40 GREENE AVE · EXISTING STOOP CONDITIONS SCALE As Noted 05 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
EXISTING CELLAR LEVEL EXISTING FIRST LEVEL N PROPOSED CELLAR LEVEL PROPOSED FIRST LEVEL N 40 GREENE AVE · PLANS SCALE As Noted 06 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
EXISTING SECOND LEVEL N PROPOSED SECOND LEVEL N 40 GREENE AVE · PLANS SCALE As Noted 07 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
EXISTING SECTION PROPOSED SECTION 40 GREENE AVE · SECTIONS SCALE As Noted 08 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
8” 8” EXISTING ENTRANCE ELEVATION PROPOSED ENTRANCE ELEVATION EXISTING ENTRANCE PLAN PROPOSED ENTRANCE PLAN 40 GREENE AVE · PROPOSED ACCESSIBLE ENTRANCE SCALE As Noted 09 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
EXISTING ENTRY PROPOSED ACCESSIBLE ENTRY 40 GREENE AVE · PROPOSED ACCESSIBLE ENTRANCE: AXON SCALE As Noted 10 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
EXISTING FACADE PROPOSED FACADE 40 GREENE AVE · PROPOSED FACADE, WITH ACCESSIBLE ENTRANCE SCALE As Noted 11 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
! Application Wall luminaire with two-sided light output. For illumination and design tasks in architecture. The light directed downwards is intended to illuminate the wall and the horizontal surface in front of it. The light directed upwards is intended to illuminate the wall and ceiling surfaces. The used LED technique offers durability and optimal light output with low power consumption at the same time. Product description Luminaire made of aluminium alloy, aluminium and stainless steel Clear safety glass Silicone gasket Reflector made of anodised pure aluminium Mounting plate with 2 fixing holes ø 5.3 mm 160 x 14 mm spacing 2 cable entries for through-wiring of mains supply cable up to ø 10.5 mm max. 3 x 1.5 @ Plug connection Connecting terminal 2.5 @ Earth conductor connection LED-Power supply unit 220-240 V x 0/50-60 Hz DC 176-264 V Safety class I Protection class IP 65 Dust tight and protection against water jets c – Conformity mark www.bega.com Weight: 1.2 kg Light technique Half beam angle 20° Montageplatte Mounting plate Contre-plaque Luminaire data for the light planning program 35 DIALux for outdoor lighting, street lighting and 25 160 200 indoor lighting as well as luminaire data in 60 200 275 EULUMDAT and IES-format you will find on the BEGA web page www.bega.com. Ø 5,3 105 14 40 LIGHT FIXTURE INFORMATION SHEET SIGNAGE ELEVATION 1/2” = 1’ SIGNAGE PLAN TYPICAL SIGNAGE SECTION 1-1/2” = 1’ 3” = 1’ 40 GREENE AVE · SIGNAGE AND LIGHTING DETAIL SCALE As Noted 12 894 6th Avenue CLIENT PINESTONE GREENE LLC 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE OCTOBER 17, 2017 dxastudio.com T 212 874 0567
APPENDIX: ROSE WINDOW SCALE As Noted 23 894 6th Avenue CLIENT EVENHAR 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE MAY 10, 2017 dxastudio.com T 212 874 0567
40 GREENE AVE · STAINED GLASS EXISTING CONDITIONS SCALE As Noted 24 894 6th Avenue CLIENT EVENHAR 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE MAY 10, 2017 dxastudio.com T 212 874 0567
40 GREENE AVE · ROSE WINDOW STABILIZATION SCALE As Noted 25 894 6th Avenue CLIENT EVENHAR 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE MAY 10, 2017 dxastudio.com T 212 874 0567
Simon Berasaluce 1914-1993 Simon Berasaluce, born in Deva, was a resident of San Sebastian in the Basque country of Spain. His artistic training was received at the Royal Academies in Madrid and Barcelona. He apprenticed in Madrid before moving to Paris. It was in Paris that Mr. Berasaluce found his place in the art of stained glass. He worked with Maumejean for some years and received awards for his works. Among these was an international competition of design for Sacre Cour Church in Paris. He won the competition but a French studio executed the work. During 1951, Mr. Berasaluce came to the United States and practiced his art at Hiemer & Company in Clifton, NJ. He brought with him the knowledge of the emerging medium of faceted glass and the then innovative European liturgical decorative arts. His wide experience in design, painting, and color ranged from Romanesque to modern experimental. A man of genteel culture, he possessed a high energy level and worked rapidly. Although he preferred contemporary expression, his portraiture was outstanding. During his career, he created works of great beauty for churches throughout this country. His innovative style and mastery of color sets him among the great masters of the stained glass craft. After twenty-two years in the United States, Mr. Berasaluce and his family returned to their beloved Basque Country. In 1980, he was coaxed out of retirement to design a total of 8,731 square feet of stained glass for one hundred twenty windows at St. Cecilia Church in Leominster, MAS. This was the last project he did with Hiemer & Company. Simon Berasaluce will be sorely missed but his beautiful works will stand as testimony to his life for generations. He is survived by his wife Maria and daughter Patricia. 40 GREENE AVE · STAINED GLASS HISTORY SCALE As Noted 26 894 6th Avenue CLIENT EVENHAR 5th Floor PROJECT NUMBER 16.31 NYC 10001 DATE MAY 10, 2017 dxastudio.com T 212 874 0567
