Designing Cypher (a graph query language) Narrated by Tobias Lindaaker, Developer at Neo Technology tobias@neotechnology.com #neo4j,#cypher @thobe

Once upon a time… ~2001

in the kingdom of Sweden ~2001

there was a DBMS that had some interesting things going for it… ~2001

a few years later… This presentation has been given at StrangeLoop, the video is online: youtu.be/l-n8yj6_RgU This is a Stand-Alone Sequel ~2016

The Precursors to Cypher First release of Cypher 2001 2006 2010 2011 (July) Embedded Custom code Java API HTTP API
 deployment server model

The Origin of Cypher

The Origin of Cypher (query)--[MODELED_AS]--->(drawing) ^ | | | [IMPLEMENTS] [TRANSLATED_TO] | | | v (code)<-[IN_COMMENT_OF]-(ascii art)

The Origin of Cypher (query)--[MODELED_AS]--->(drawing) ^ | | | [IMPLEMENTS] [TRANSLATED_TO] | | | v (code)<-[IN_COMMENT_OF]-(ascii art) MATCH (query)-[:MODELED_AS]->(drawing), (code)-[:IMPLEMENTS]->(query), (drawing)-[:TRANSLATED_TO]->(ascii_art) (ascii_art)-[:IN_COMMENT_OF]->(code) WHERE query.id = {query_id} RETURN code.source

v1: Read Only START john=node:Person(name="John") MATCH (john)-[:KNOWS]-(friend)-[:KNOWS]-(foaf) WHERE NOT (john)-[:KNOWS]-(foaf) RETURN foaf July 2011 ( neo4j 1.4 )

v2: Graph write no update of search structures START john=node:Person(name="John") MATCH (john)-[:KNOWS]-(friend)-[:KNOWS]-(foaf) WHERE NOT (john)-[:KNOWS]-(foaf) AND NOT (john)-[:RECOMMENDATION]->(foaf) CREATE (john)-[:RECOMMENDATION]->(foaf) RETURN foaf Oct 2012 ( neo4j 1.8 )

Neo4j 2.0: labels and proper indexes Cypher “feature complete” MATCH (john:Person{name:"John"}), (john)-[:KNOWS]-(friend)-[:KNOWS]-(foaf) WHERE NOT (john)-[:KNOWS]-(foaf) MERGE (john)-[:RECOMMENDATION]->(foaf) ( neo4j 2.0 ) Dec 2013

A brief Cypher overview Pattern matching:
 Carrying results from a query into a new
 MATCH (n), (a)-[:REL]->(b)
 MATCH (a)-[:KNOWS]->(b)
 + filtering:
 WITH a, avg(b.age) AS frAge
 WHERE n=b AND a.val < n.val WHERE frAge > 15
 MATCH (a)<-[:FOLLOWS]-(c)
 Returning results
 RETURN c.name RETURN x.name AS name
 ORDER BY x.score LIMIT 10 OPTIONAL MATCH
 Creating data:
 CREATE (p:Person{name:”Tobias”}) Match-or-null Updating data:
 SET n.name = ”John” MERGE
 Match-or-create
 Deleting data:
 with ON MATCH and ON CREATE
 REMOVE p.age
 DELETE n to perform updates

CYPHER 2.0 MATCH (n) RETURN n Multiple versions Put the version in the query, and support multiple versions of Cypher in the Neo4j Server

Improve based on user feedback … good, but not as good as we hoped… photo credits: Columbia Journalism Review

Query caching - amortise cost of optimisation

Whole program analysis MATCH (john:Person{name:"John"}), (john)-[:KNOWS]-(friend)-[:KNOWS]-(foaf) RETURN friend.name

Whole program analysis MATCH (john:Person{name:"John"}), (john)-[:KNOWS]-(friend)-[:KNOWS]-(foaf) -[:KNOWS]-(foaf) RETURN friend.name

Recent additions: Procedures CALL dbms.listProcedures()
 YIELD name, signature, description MATCH (me:Person{name:{myName}}),
 (me)-[:KNOWS]-()-[:KNOWS]-(foaf)
 WHERE NOT (me)-[:KNOWS]-(foaf)
 CALL apoc.load.jdbc('mysql:…',
 "SELECT * FROM people WHERE id = "
 + foaf.id) YIELD row
 RETURN foaf.name, row.address

it isn’t all roses

Semantically different things look similar MATCH (n:Measurement) RETURN abs(n.value) MATCH (n:Measurement) RETURN avg(n.value) MATCH (a:Foo{key:{a}}), (b:Foo{key:{b}}),
 p=(a)-[:BAR*1..]-(b)
 WHERE all(n in nodes(p) WHERE n.value > {m})
 RETURN length(p)

Constructs with intricate semantics Deprecated:
 MATCH (a:Foo{key:{a}}), (b:Foo{key:{b}})
 CREATE UNIQUE (a)-[:KNOWS]-(u)-[:KNOWS]-(b) Better:
 MATCH (a:Foo{key:{a}}), (b:Foo{key:{b}})
 MERGE (a)-[:KNOWS]-(u)-[:KNOWS]-(b)

Constructs with intricate semantics MATCH (a)-->(b)<--(c)
 RETURN a.key,b.key,c.key vs key:y key:x MATCH (a)-->(b)
 MATCH (b)<--(c)
 RETURN a.key,b.key,c.key

Constructs with intricate semantics <no rows> MATCH (a)-->(b)<--(c)
 RETURN a.key,b.key,c.key vs key:y key:x MATCH (a)-->(b)
 MATCH (b)<--(c)
 RETURN a.key,b.key,c.key a.key:’x’, b.key:’y’, c.key:’x’

Constructs with intricate semantics <no rows> MATCH (a)-->(b)<--(c)
 RETURN a.key,b.key,c.key vs key:y key:x MATCH (a)-->(b)
 MATCH (b)<--(c)
 RETURN a.key,b.key,c.key a.key:’x’, b.key:’y’, c.key:’x’ MATCH (a)-[x]->(b)
 MATCH (b)<-[y]-(c)
 WHERE x <> y
 RETURN a.key,b.key,c.key

“Syntactic sugar” vs single canonical syntax MATCH (n) WHERE n.foo = "bar"
 vs
 MATCH (n{foo: "bar"}) MATCH (n WHERE foo < 10)
 vs
 MATCH (n) WHERE n.foo < 10

Predicates on variable length paths MATCH (a)-[r*]->(b)
 WHERE all(x IN r WHERE x.weight > 0) would be simpler if it could be written as: MATCH (a)-[r* WHERE weight > 0]->(b) although there are other problems that would come from that…

LOAD CSV will be replaced LOAD CSV WITH HEADERS FROM "some.csv" AS line CALL apoc.load.csv("some.csv")
 YIELD map AS line

Parameters avoid SQL injection

Labels and Relationship Types cannot be passed as parameters MATCH (n:{label}) SET n:{label}

openCypher 6/20/2016 https://s3.amazonaws.com/artifacts.opencypher.org/railroad/Cypher.svg QueryOptions CREATE Index Opening the language design process ; DROP Index CREATE UniqueConstraint DROP UniqueConstraint CREATE NodePropertyExistenceConstraint Implementations for other platforms DROP NodePropertyExistenceConstraint CREATE RelationshipPropertyExistenceConstraint DROP RelationshipPropertyExistenceConstraint Compatibility test suite LoadCSV Start Match Unwind Grammar specification Merge Create Set Delete Reference implementation Remove Foreach With Defining the next version of Cypher Return ALL UNION https://github.com/openCypher/openCypher BulkImportQuery https://s3.amazonaws.com/artifacts.opencypher.org/railroad/Cypher.svg 1/1

Future features Cypher keeps evolving You can get involved through openCypher



 Sub queries are powerful MATCH (me:Person{name:{myName}}),
 (me)-[:FRIEND]-(friend)
 WITH me, collect(friend) AS friends
 MATCH (me)-[:ENEMY]-(enemy)
 RETURN me, friends, collect(enemy) AS enemies


 Sub-queries for side effects MATCH (me:Person{name:{myName}}),
 (me)-[:FRIEND]-(friend)
 WITH me, collect(friend) AS friends
 MATCH (me)-[:ENEMY]-(enemy)
 DO {
 UNWIND friends AS friend
 MERGE (friend)-[:ENEMY]-(enemy)
 } DO will replace FOREACH

Existential sub-queries MATCH (actor:Actor)
 WHERE EXISTS {
 (actor)-[:ACTED_IN]->(movie),
 (other:Actor)-[:ACTED_IN]->(movie)
 WHERE other.name = actor.name
 AND actor <> other
 }
 RETURN actor



 More Sub-queries MATCH (me:User{name:{username}})-[:FOLLOWS]->(user)
 WHERE user.country = {country}
 MATCH {
 // authored tweets
 MATCH (user)<-[:AUTHORED]-(tweet:Tweet)
 RETURN tweet, tweet.time AS time
 UNION
 // favorited tweets
 MATCH (user)<-[:HAS_FAVOURITE]-(favorite)-[:TARGETS]->(tweet:Tweet)
 RETURN tweet, favourite.time AS time
 }
 RETURN DISTINCT tweet
 ORDER BY time DESC
 LIMIT 100




 Projections and comprehension MATCH (person:Person{ssn:{mySSN}}),
 Inspired by Facebook’s GraphQL
 (person)-[emp:EMPLOYED_BY]->(employer)
 WHERE NOT exists(emp.endDate)
 Returns a single column ‘person’ containing:
 WITH person, employer.name AS employer
 ORDER BY emp.startDate DESC LIMIT 1
 RETURN person{
 {
 .ssn,
 ssn: “192168-0001”,
 .firstName,
 firstName: “John”,
 .lastName,
 lastName: “Smith”,
 employer,
 employer: “The Company, Inc.”,
 friends: [
 friends: [
 MATCH (person)-[:FRIEND]-(friend)
 {ssn: “009933-1126”,
 WHERE friend.age > 12
 firstName: “Marty”,
 RETURN friend{
 lastName: “McFly”},
 .ssn,
 {ssn: “123987-4506”,
 .firstName,
 firstName: “Emmet”,
 .lastName
 lastName: “Brown”},
 }
 ]
 ]} }

The End
