DB ES Experiment Support DDM Dashboard 2.0 ATLAS SW&C - PowerPoint PPT Presentation

Apr 16, 2023 •140 likes •307 views

DB ES Experiment Support DDM Dashboard 2.0 ATLAS SW&C Workshop April 2011 David Tuckett IT-ES-DNG CERN IT Department CH-1211 Geneva 23 Switzerland www.cern.ch/ i t ES Overview SW&C Dec 2010 Review DDM Dashboard 1.0

  1. DB ES Experiment Support DDM Dashboard 2.0 ATLAS SW&C Workshop April 2011 David Tuckett IT-ES-DNG CERN IT Department CH-1211 Geneva 23 Switzerland www.cern.ch/ i t

  2. ES Overview • SW&C Dec 2010 Review – DDM Dashboard 1.0 – 2.0 PROTOTYPE • Recent Developments – 2.0 M1 • Next steps – Feature Comparison – Roadmap • Summary CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 2 Switzerland www.cern.ch/ i t

  3. ES SW&C Dec 2010 Review • DDM Dashboard 1.0 – Key tool for shifters to identify/investigate failures – Proved to be reliable and scalable – Issues • No view by source • Limited filtering • Poor quality plots • Ageing UI • Slow to develop CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 3 Switzerland www.cern.ch/ i t

  4. ES SW&C Dec 2010 Review • 2.0 PROTOTYPE (December 2010) – Matrix for view by source & destination – Error samples – New UI based on AJAX / jQuery – Leverages existing server framework – Complements 1.0 CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 4 Switzerland www.cern.ch/ i t

  5. ES Recent Developments • 2.0 M1 (April 2011) – Matrix of transfers by source & destination – Error samples – Client-side Model-View-Controller architecture – Full bookmarking support – Plots of transfers by source & destination – Filtering by activity – Filtering by tier / cloud / site / token – Grouping by tier / cloud / site / token CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 5 Switzerland www.cern.ch/ i t

  6. ES 2.0 M1: Matrix & Error Samples Transfer matrix Error samples Activity filter CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 6 Switzerland www.cern.ch/ i t

  7. ES 2.0 M1: Source & Destination Plots Destination plots Source plots CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 7 Switzerland (Smoke and mirrors disclaimer: plot data are not real) www.cern.ch/ i t

  8. ES 2.0 M1: Filtering by Source Source filters: Cloud = ES Grouping = CLOUD_SITE CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 8 Switzerland www.cern.ch/ i t

  9. ES 2.0 M1: Filtering by Source Source filters: Cloud = ES Grouping = CLOUD_SITE CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 9 Switzerland (Smoke and mirrors disclaimer: plot data are not real) www.cern.ch/ i t

  10. ES 2.0 M1: Filtering by Destination Destination filters: Cloud = DE Grouping = CLOUD_SITE CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 10 Switzerland (Smoke and mirrors disclaimer: plot data are not real) www.cern.ch/ i t

  11. ES 2.0 M1: Complex Filtering & Grouping Source filters: Cloud = CERN DE ES FR UK Grouping = CLOUD_TIER Destination filters: Cloud = ES Grouping = CLOUD_TOKEN CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 11 Switzerland www.cern.ch/ i t

  12. ES 2.0 M1: Complex Filtering & Grouping Source filters: Cloud = CERN DE ES FR UK Grouping = CLOUD_TIER Destination filters: Cloud = ES Grouping = CLOUD_TOKEN CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 12 Switzerland (Smoke and mirrors disclaimer: plot data are not real) www.cern.ch/ i t

  13. ES 2.0 M1: Complex Filtering & Grouping Source filters: Cloud = CERN DE ES FR UK Grouping = CLOUD_TIER Destination filters: Cloud = ES Grouping = CLOUD_TOKEN CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 13 Switzerland (Smoke and mirrors disclaimer: plot data are not real) www.cern.ch/ i t

  14. ES Next Steps: Feature Comparison Key Features 1.0 2.0 2.0 M1 Prototype    Transfer statistics by source    Transfer statistics by destination    Transfer error samples    Transfer plots by source    Transfer plots by destination    Filter transfers by activity   Filter source by tier/cloud/site/token limited  Filter destination by tier/cloud/site/token limited limited    Group statistics by tier/cloud/site/token    Registration statistics   limited Customizable historical plots    Event details CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 14 Switzerland www.cern.ch/ i t

  15. ES Next Steps: Roadmap • 2.0 M1 – April 2011 – Plots: source, destination – Filters: activity, tier, cloud, site, token – Grouping: tier, cloud, site, token – Complements DDM Dashboard 1.0 UI • 2.0 M2 – July 2011 – QA and Tuning – Transpose: sources  destinations – Customizable historical plots – Complements DDM Dashboard 1.0 UI • 2.0 FINAL– Oct 2011 – See comparison on previous slide – Replaces DDM Dashboard 1.0 UI CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 15 Switzerland www.cern.ch/ i t

  16. ES Summary • DDM Dashboard 2.0 M1 – Plots by source & destination – Flexible filtering, grouping and sorting – April 2011 release • Roadmap – Incremental releases – Currently complements DDM Dashboard 1.0 UI – Ultimately replaces DDM Dashboard 1.0 UI • Feedback – david.tuckett@cern.ch CERN IT Department CH-1211 Geneva 23 DDM Dashboard 2.0 - 16 Switzerland www.cern.ch/ i t
