Data Analysis Tutorial for the Fermi Gamma-ray Burst Monitor (GBM)

Hoi-Fung Yu (MPE) for the Fermi GBM team

4th FAN Workshop, University of Hong Kong, Hong Kong (12 July 2013)

Contents

• Basic facts of the Fermi GBM
• GBM data types
• Analysis tool: RMFIT
• Retrieving GBM data
• Spectral analysis using RMFIT

What is Fermi GBM?

• Fermi GBM is a joint project of MPE and UAH
• Joint analysis of spectra and time histories of Gamma-ray

Bursts (GRBs) observed by both the GBM and LAT (Meegan et al. 2009)

• Provide near-real time burst locations onboard to

permit repointing of the spacecraft to obtain LAT

• bservations of delayed emission from bursts, and to

disseminate burst locations rapidly to the community of ground-based observers

• 12 thallium activated sodium iodide, NaI(Tl), scintillation

detectors and 2 bismuth germanate, BGO, scintillation detectors

• NaIs cover lower energy spectrum (~8 keV - ~1 MeV),

BGOs cover higher energy spectrum (~200 keV - ~40 MeV)

• The axes of the NaI detectors are oriented such that

the positions of GRBs can be derived from the measured relative counting rates, a technique previously employed by CGRO BATSE

NaI detector (Meegan et al. 2009) Locations and orientations of the GBM detectors (Meegan et al. 2009) BGO detector (Meegan et al. 2009)

These detectors and the data read-out systems were actually built at MPE!

GBM data types

• TTE (Time-tagged events): Event data. Individual photons (or

count rates) with time tag and energy. 128 Energy channels (adjustable boundaries). Each row in event extension in the FITS file is a time and an energy channel.

• CSPEC: 4.096 s (nominal) and 1.024 s (during burst) temporal

resolution, 128 energy channels (adjustable boundaries, same as TTE). Each row in spectrum extension in the FITS file is a 128 energy channel spectrum.

• CTIME: 0.256 s (nominal) and 64 ms (adjustable from 64 ms to

1.024 s during burst) temporal resolution, 8 energy channels (adjustable boundaries). Not suitable for spectroscopy.

Which data type should I use?

• Look at the quicklook lightcurve to determine the

approximate duration of the burst.

• Spectral analysis:
• For short (~< few seconds) or highly structured events,

choose TTE data. (TTE data has only time range from ~T0-25 s to ~T0+300 s, and is slower to process.

• For longer or less structured events, choose CSPEC data.
• PHA files from other experiments, e.g. Swift BAT, can also be

analyzed using RMFIT, providing they have a single associated response file, and conform to standard FITS format. BAT files are single PHA files, i.e. one spectrum per file. CSPEC/CTIME files are PHA2 files, i.e. multiple spectra per file, each spectrum belonging to a time bin.

• Naming convention of GRB: GRB yymmddX
• If there is IPN/Swift detection, X = A, B, C...
• For GBM detection only, X is a three digit number
• For each GRB, at the FSSC you can find...
• 14 TTE files (per each version, e.g.

glg_tte_b0_bnyymmddxxx_v01.fit) [FIT]

• 14 CSPEC files (per each version, e.g.

glg_cspec_b0_bnyymmddxxx_v01.pha) [PHA]

• 14 CTIME files (per each version, e.g.

glg_ctime_b0_bnyymmddxxx_v01.pha) [PHA]

• 1 Trigdat file (e.g. glg_trigdat_all_bn130601547_v02.fit) for burst

localization

• Various GIF and PDF files for quicklook to the lightcurves
• and TCAT files for internal use of burst information

Analysis tool: RMFIT version 4.3.2

(should have installed before this tutorial!)

• Operating system: Mac OS X (10.6 or newer), Linux
• Supporting softwares: IDL 8.1 (virtual machine) [Good news: this is a self-contained distribution, no

external library is needed!]

• Download the RMFIT package (version 4.3.2) and the installation instructions at the FSSC user

contribution page: http://fermi.gsfc.nasa.gov/ssc/data/analysis/rmfit/

• Choose The Mac OS X Package if you are using OS X
• Choose The Linux Distribution if you are using Linux
• Extract the tarball and follow the installation instructions
• To run RMFIT do one of the following options:
• Double click the rmfit432.command file in /Applications/rmfit_v432/
• At a terminal prompt cd into the rmfit_v432 directory and type ./rmfit432.command
• Create an alias: alias rmfit=$directory_to_file/rmfit432.command. Then at the command

prompt type rmfit. Put this inside your .bashrc to use from all terminals.

• You cannot use idl -vm to call RMFIT.

You must use one of the two options above. The IDL virtual machine included in this install can only be accessed by RMFIT through the rmfit432.command file. If RMFIT will not run make sure you have X11 installed.

Retrieving GBM data

• Directly by FTP at: http://heasarc.gsfc.nasa.gov/FTP/fermi/data/gbm/triggers if you know the full name
• f the burst e.g. 080916009. Look for the files you want under the “current” directory for the burst.
• Using the FSSC interface: http://fermi.gsfc.nasa.gov/ssc/data/access/ under “GBM Burst Catalog”.

You will see a page with explanations about GBM data. Click the “Browse this Table” at the top left-hand

• corner. Search for your burst by entering “GRB080916*” under the “name” field in the table. Select

your burst from the returned triggers using your knowledge of the trigger time. “Preview and Retrieve” will allow you to generate the directory listing the available data files for this burst, or you can just retrieve the whole available data package in a tar file.

• CSPEC (CTIME) files are

“glg_cspec_nx_bn080916009_v0y.pha” (“glg_ctime_nx_bn080916009_v0y.pha”) where x is the NaI detector number 0-9, a, b or “glg_cspec_bx_bn080916009_v0y.pha” (“glg_ctime_bx_bn080916009_v0y.pha”) with x =0 or 1. Choose b0 if you have low-numbered NaI, b1 for NaI with x>5. If you have a mixture, select both BGOs and choose better one after looking at data.

• TTE files are “glg_tte_nx_bn080916009_v0y.fit” or “glg_ctime_bx_bn080916009_v0y.pha”)...
• In either case, you will need a detector response file for each detector you are analyzing

“glg_cspec_nx_bn080916009_v0y.rsp” or “glg_cspec_bx_bn080916009_v0y.rsp”. CSPEC response files apply to both CSPEC and TTE data files: the number of energy channels is 128 for both.

• Quicklook lightcurves are called glg_lc_all_bn080916009.gif
• The version number v0y is unimportant and can be different for each file type.

From the spectroscopy tutorial: http://fermi.gsfc.nasa.gov/ssc/data/analysis/user/vc_rmfit_tutorial.pdf (RMFIT team, April 2010)

Spectral analysis

I will use a recent burst GRB 130305A (130305486) as an example (a Fermi and Swift detected burst): http://fermi.gsfc.nasa.gov/ssc/data/access/

GBM Products

• 1. Choose the brightest 3-4 NaIs, and also the suitable BGO.

Usually the triggered NaIs are bright. Use the blocked BGO.

• 2. Open RMFIT, then load all the desired CSPEC files [PHA].

You can toggle to switch between the lightcurve and energy channel display windows. You can rebin according to temporal resolution (must be integer multiple of the finest bin) or S/N ratio, or click “Rebin: Full Resolution” to return to full resolution.

• 3. Zoom to around the trigger time. (You can do this just once and then load the lookup files to all
• ther detectors!)

• 4. Click on the right-most region to

delete the current selection or click

• n “EXIT” at the bottom-left corner
• f the display window to confirm

selection. For NaIs, usually we use ~8-900 keV. Avoid the overflow channels.

• 3. Toggle to the energy channels display, click

“Select Source: Source Interactive” in order to select usable energy ranges.

• 5. In the lightcurve display, click “Fit

Background” and then select the background intervals before and after the burst.

• 6. Click on the right-most region to delete the

current selection or click on “EXIT” at the bottom-left corner of the display window to confirm selection.

• 7. Choose the order of polynomial used to

fit the background intervals (RMFIT will then extrapolate the fit into the burst region).

• 8. Look at the reduced Chi2 values for each energy channel,

they should be all around the value 1. Click “Dismiss” to return to the lightcurve display.

• 9. Zoom closer to the burst to check whether the fitted background (blue dotted line) is
• reasonable. If not, repeat the background fitting process by selecting another pair of intervals.
• 10. Click “Select Source: Source Interactive”

to select the source interval. Click “Exit” to confirm or the right-most region to cancel

• selection. In this tutorial I just choose a ~15

s interval containing the brightest part of the burst. Important: The source interval interval must not intercept with the background intervals!

You can also toggle to the energy channel display to see the fitted background rates for each energy channel (remember the energy channel display reveals mainly the effective area effect). RMFIT will display the selected energy range at the upper-right corner, and the bottom, and the source time interval at the bottom.

• 11. Click “File” and then “Lookup -> Save

Lookup” to save the current binning, zooming, background and source selections. The lookup file will be saved with the same name as your current CSPEC/ TTE file with extension “.lu”. You can also choose your desired name for it.

• 12. Read the lookup file to every other

detectors. For consistency you should always use the same lookup file for all detectors!

• 13. For the BGO, the energy selection

will be wrong. Toggle to the energy channels display and click “Zoom: Zoom Out: Full Range” to view the full energy range. Avoid energy ~< 200 keV and the

• verflow channel. In this tutorial I

use ~240 keV to ~40 MeV.

• 14. From one of the detector windows,

select “Spectral Fitting: Fit Selections”. This produces a fit of the entire source interval (which you selected) with some model you will choose. You will be prompted for the detector response file, one per

• detector. Select and click “Ok”.

You will be asked which detectors to include in the fit. Press “Accept” to select all of

• them. This will cause the fit to
• ccur jointly over all the

detectors, i.e. your fitting statistic will be optimized using information from all detectors.

15. You have many models to choose from. If you click “Restore” you will get even more models which are not offered by default. Clicking a model selects it. Select “C-Stat” to use the Cash- Castor statistics (Cash 1979) instead of the Chi2 statistics, since for GBM data the background should be Poissionian. Combined models can be used by clicking individual model when holding the <ctrl> key. Clicking “Accept” will then fit the data. If you chose “Set parameters” the RMFIT will prompt you a window to initialize the parameters before starting the fit. We will fit models 1, 7, & 5, i.e. Power-law (Pl), Comptonized (Comp), & the famous Band’s GRB function (Band Function, Band 1993) in this tutorial: Note that the Band Function reduces to the Comptonized model when the high-energy power-law index goes to -ve infinity.

Points are the NaIs and BGO data rates blue curve is the model rates (expected rate convolved to the DRMs assuming the model is “correct”) “Zoom” let you zoom the plots “Fit Results” let you write fit results to file “Redo Last Fit” let you redo the fit, you can also change the photon model(s) You can control the fitting process in “Spectral Fitting”, e.g. setting the error interval “Fit Display Options” let you convert the plot to different space, e.g. photon counts, energy, vFv etc.

C-Stat [-2log(likelihood)] cannot be used to estimate goodness of fit, only compared to C-Stat for other (nested) models. Look at the Fit Log and the residuals to decide if the fit is a good fit or not. Fitting a power-law model:

Fitting a Comptonized model: Residuals reduced, C-Stat is much less (for 1 more parameter), i.e. a better model (higher probability to produce the observed spectrum)

Fitting a Band model: Similar residuals, C-Stat is ~40 less, (for 1 more parameter) i.e. best among the 3 models

To show more clearly the fitted model and the data rates, you can rebin the spectrum by combining spectral bins (usually do for the BGO since most of the data points are upper-limits) After rebinning, click “Spectral Fitting: Fit Selections” instead of “Redo Last Fit” since you have already changed the input data.

Comparing to the Band model, you can see that the Comp model has too-deep decay at >1 MeV range. [Note that both the data and the model binnings changed]

If there is any normalization issues, use the “Effective Area Correction” together with the chosen

• model. Select “Redo Last Fit” and hold <ctrl> key to select from the model window, in addition to
• ption “5”, option “40”. Click “Set Parameters” to choose which detector areas to vary. Click

“Accept” to redo the fit.

With much worse likelihood, and 4 extra parameters, this does not seem to be a necessary addition to the

• model. These corrections are for NaIs

relative to BGO.

You have already gone through the basic analysis procedures using RMFIT and can now play around with the data! For long and bright bursts, you can try to do time-integrated and time-resolved spectral analysis. Work hard and have fun with GRBs! More details about the usage of RMFIT can be found at the FSSC’s RMFIT Tutorial: http://fermi.gsfc.nasa.gov/ssc/data/analysis/rmfit/ You may also have a look at more GRB spectral fitting papers from the Fermi GBM team: Time-integrated spectral catalogs: Goldstein et al. 2012, Gruber et al. 2013 (in prep.) Time-resolved spectral analysis: Burgess et al. 2013 (in prep.), Yu et al. 2013 (in prep.)
