Coonamessett Farm Foundation Dredge Research Program Ronald - PowerPoint PPT Presentation

Coonamessett Farm Foundation Dredge Research Program Ronald Smolowitz Matthew Weeks Timeline of Scallop Fishery Dredge Bycatch Research Pre 1994: Flounder catch in scallop dredges was considered a target; not unwanted bycatch. Research


  1. Coonamessett Farm Foundation Dredge Research Program Ronald Smolowitz Matthew Weeks

  2. Timeline of Scallop Fishery Dredge Bycatch Research Pre 1994: Flounder catch in scallop dredges was considered a target; not unwanted bycatch. Research concentrated on ring-size increase to improve scallop selectivity. 1994 :Groundfish closed areas on Georges Bank include scallop dredge vessels. 1995: S-K program funds Coonamessett Farm research on larger mesh twine tops to improve fish escapement. 1999: Ten-inch twine top becomes regulation in certain scallop access areas 2002: NMFS becomes aware that turtles are being caught in scallop dredges. 2004: Turtle Chains developed and tested by Coonamessett Farm and VIMS 2005: Forward cutting bar dredge frame designed by Coonamessett Farm to reduce impact on turtles begin to be tested. 2006: The excluder dredge frame underwent a series of successful tests on sea turtle carcasses and at sea trials . Tests demonstrate the need to remove bale bars. NMFS makes chain mats mandatory. 2007: ROV first utilized to observe turtle behavior. CFarm contracts with NEFSC to perform a dredge comparison study of CFarm Turtle Excluder Dredge. 2008: . Field trial results of Cfarm Turtle Excluder Dredge show reductions in fish bycatch rates. 2010: Testing begins on low profile version of the Cfarm Turtle Excluder Dredge. 2011: Continued testing and development of the low profile dredge

  3. Coonamessett Farm Scallop Dredge Project Summary • NOAA Grant # Title Lead Budget • NA03NMF4540344 Turtle Chain Tests VIMS • NEFSC Contract 2004 Turtle Video Cfarm $ 25,000 • NEFSC Contract 2005 Turtle Video CFarm • NEFSC Contract 2005 Panama City NEFSC • NA05NMF4541293 Turtle Excluder Dredge Cfarm $ 84,400 • NEFSC Contract 2006 Panama City NEFSC • NA06NMF4540263 Sea Turtle Interaction Cfarm $ 94,282 • NA06NMF4540258 New Dredge Design Cfarm $149,206 • NA07NMF4540029 Field Testing of Dredge Cfarm $ 89,144 • NEFSC Contract 2008 Turtle Run-over CFarm $ 25,000 • NA08NMF4540663 Turtle-Dredge ROV Cfarm $134,624 • NA09NMF4540131 Turtle Oceanography Cfarm $199,929 • NA09NMF4720414 Low Profile Excluder Dredge Cfarm $ 30,000 • Totals $806,585

  4. Standard New Bedford Sea Scallop Dredge

  5. Fish Excluding Concepts Tested by C-Farm (2) Sorting (2) Sorting (1) Mechanical Blocking (1) Mechanical Blocking - Blocking of Frame Windows Blocking of Frame Windows - Chain Mat Attachment to Frame Chain Mat Attachment to Frame - - - Toothed Dredges Toothed Dredges - 4) Escapement 4) Escapement ) Avoidance Behavior (3 ) Avoidance Behavior (3 - Modified Twine Top Mesh Sizes - Modified Twine Top Mesh Sizes - Tickler Chains Tickler Chains - - Hanging Ratios Hanging Ratios - - Drop Chains Drop Chains - - Windows in Twine Top Windows in Twine Top - - Frame Design - Frame Design - Fish Eyes in Twine Top Fish Eyes in Twine Top - - Rollers Rollers - - - Apron length Apron length

  6. Fish Bycatch Reduction Project

  7. Modifications to Dredge Frame

  8. Challenges to Dredge Modifications

  9. Deck Operations

  10. Turtle Chains

  11. Demonstration of Possible Interaction of Sea Turtle on the Seafloor with a Standard New Bedford Scallop Dredge

  12. Standard New Bedford Dredge C-Farm Excluder Dredge

  13. Development of C-Farm Excluder Dredge Over 4,000 comparison tows conducted Industry currently voluntarily implementing

  14. Examples of C-Farm Excluder Dredge / Sea Turtle Interaction 9 out of 9 encounters were excluded with no injuries observed

  15. Testing of of C-Farm Excluder Dredge on Hard Bottom

  16. Observed Fish Behavior C-Farm Turtle Excluder Dredge C-Farm Low Profile Excluder Dredge Twine Top

  17. Cfarm Turtle Excluder Dredge Catch Results (N=1632 tow pairs) Species Total Catch % Change Significant (Pt) Scallops 33131 bu 3% 0.000 Skate 131938 -0.3% 0.000 Monkfish 14378 1% 0.057 Summer fl. 2552 -10% 0.004 Grey sole 1237 4% 0.265 Yellowtail fl. 10034 -46% 0.000 Winter fl. 88 -69% 0.000 Barndoor sk. 1725 -18% 0.000 Winter sk. 1339 -20% 0.006 Sand dab 1617 -48% 0.000 Fourspot fl. 4382 -20% 0.000 American pl. 305 114% 0.000

  18. Low Profile Dredge

  19. Low Profile Dredge

  20. Low Profile Dredge Catch Results N=32 pair tows Species Total Catch % Change Significant Pt(a=0.05) Scallops 40 bu -13% 0.040 Skate 10589 -88% 0.000 Monkfish 232 11% 0.220 Summer fl. 278 -55% 0.000 Yellowtail fl. 52 -8% 0.410 Winter fl. 216 -122% 0.010 Barndoor sk. 106 -30% 0.050 Winter sk. 459 -27% 0.090 Sand dab 578 -116% 0.000 Fourspot fl. 49 -72% 0.130

  21. Turtle Behavior Observation Using an ROV Masthead view of turtle being tracked by ROV ROV being deployed from scallop vessel Total number of video hours of turtles followed for >30 minutes = 53.5 hours Total number of turtles recorded for >30 minutes = 23 turtles 7 ROV trips on the scallop fishing grounds during spring/summer/fall 2007-2010

  22. Foraging Dives to Seafloor Example of Descent Example of Ascent 10 turtles have been observed diving to the sea floor 17 dives to the seafloor have been observed 15 of those dives were foraging dives, 2 were avoidance dives Observed distinct “ pre-dive ” and “ post-dive ” behavior Depths of 46 – 70 meters , temperatures of 7-11.5 C , up to at least 38 minutes Often become negatively buoyant at ~ 30 meters and begin rapid glide

  23. Benthic Foraging Feeding on crabs Feeding on scallops 1 turtle observed feeding (or attempting to feed) on sea scallops on 9 occasions during 2 different dives

  24. Positions of Observed Benthic Foraging

  25. Pelagic Foraging

  26. Example of Potential Avoidance Behavior to Dredge During Haul Back

  27. Social Behavior Total number of social groups observed = 14

  28. Turtle / Oceanographic Study

  29. Oceanographic Work

  30. Possible Association with “Cold Pool”

  31. Loggerhead Turtle Aerial Survey Study

  32. Satellite Tag Study 16 turtles captured in the scallop access areas and tracked with satellite tags during 2009 and 2010 25 more planned to be tagged during spring 2011

  33. 2009 - 2010 Tag Data

  34. 2010 – 2011 Tag Data

  35. Dive Patterns and Profiles

  36. Data from Satellite Tags: Synchronized Movements
