Community detection in complex networks Vinh Loc DAO

Summary 1 Introduction 2 Datasets and Benchmarks 3 Community detection in network 4 Evaluating partition quality 5 Objectives and Perspectives 2/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Summary 1 Introduction What is a network or a graph ? Some notions Structure properties of real networks 2 Datasets and Benchmarks 3 Community detection in network 4 Evaluating partition quality 5 Objectives and Perspectives 3/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

What is a network or a graph ? Example : Internet, transport network, power grid, food web, social network Figure – A very simple network G ( V , E ) with | V | V ertices and | E | E dges Node : Entity in real life Edge : Relation between two entities to which it connects A natural language to describe complex systems. 4/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

A local mesh network - very small network Node : Computer Edge : Connection between two computer 5/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Student network in a university - relatively small network Node : Student Edge : Relation (Could be any kind of relation) 6/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

The French highway network - large network Node : City Edge : Highway 7/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

The Internet - international network 8/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Some notions Complex network : Graph with non-trivial topology features Network analysis : Studies of graph to extract non-trivial features Community detection algorithm : Divide nodes into groups called communities whose members are connected densely. Figure – Uncover graph modules without specifying clusters’ size 9/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Structure properties of real networks - Graph representing real systems are normaly neither regular nor random . - Degree (nb of connections of a node) distribution often follows a power law , as connections often follow preferential patterns. - Nodes are often found to cluster into high density groups . Figure – Regular lattice graph Figure – Graph with modular structure 10/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Why community detection ? - Comprehend network global organization - Reveal modular structures - Reveal hidden properties between nodes - Understand information diffusion process throughout network APPLICATIONS : - Detect web clients with similar interests - Prevent epidemic transmission - Managing collaboration network - etc, - You name it 11/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Summary 1 Introduction 2 Datasets and Benchmarks Datasets - Real networks Datasets - Artificial networks 3 Community detection in network 4 Evaluating partition quality 5 Objectives and Perspectives 12/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Datasets - Real networks - Social network of friendships between 34 members of a karate club at a US university in the 1970s. (left) - An identity graph with 25 vertices and 31 edges. An identity graph has a single graph auto-morphism, the trivial one. (right) Figure – Zachary karate network Figure – Walther network 13/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Datasets - Artificial networks Parameters : Graph size, node distribution, link distribution, density distribution, etc. Figure – LFR benchmark network Figure – GN benchmark network 14/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Summary 1 Introduction 2 Datasets and Benchmarks 3 Community detection in network Dense structure in modular network From dense structure to community 4 Evaluating partition quality 5 Objectives and Perspectives 15/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

An example of graph partitioning by K-means Apply K-means graph partitioning on karate club network (K = 2) Figure – K-means partition on the Figure – The Zachary karate network Zachary karate club - Good solution ? - How do we know the club has 2 communities ? - Wait, tell me again what is a community ? 16/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Did we say a ”community” ? Isn’t it a ”cluster” ? - What is a community ? - Answer : ”I know it when I see it” - No universal accepted definition. - More edges inside the community than edges linking its vertices with the rest of the network. - Many detection methods : overlapping/non-overlapping, fast/slow, single-scale/multi-scale. Figure – The karate club is separated due to a conflict coach/president Figure – A graph division 17/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Summary 1 Introduction 2 Datasets and Benchmarks 3 Community detection in network 4 Evaluating partition quality 5 Objectives and Perspectives 18/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Partition quality - What is a good partition of a network into modules ? - Quality function : assigns score to each partition of a graph - The most popular quality function is modularity 1 Q = 2 | V | Σ ij ( A ij − P ij ) δ ( C i , C j ) A ij : Adjacency matrix, P ij : Expected connection adjacency matrix Q = Fraction of edges within communities - expected fraction of such edges in a random Modularity favors inter community links. 19/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Community detection on the karate club Leading eigenvector O ( | V | 2 + | E | ) Edge betweenness O ( | V || E | 2 ) Fast greedy O ( | V || E | log ( | V | )) Modular optimization (NP-complete) Label propagation O ( | V | + | E | ) Infomap O ( | V | ( | V | + | E | )) Walktrap O ( | E || V | 2 ) Louvain method O ( | V | log ( | V | ) 20/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Community detection on the Walther network Many possible meaning divisions on a less modular network. 21/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Quality is relative ? Goodness is subjective - Community characteristics : Community density Community connectiveness Robustness to perturbation, etc Question : How to choose appropriate method to satisfy certain characteristics and utilizing as much as possible available information ? Ex : Which method to chose to : - Divide students into the most cohesive groups. - Establish geographic sites to minimize remote works of collaborators. - Compromise between community density and calculation time. - Maximize range of ages in a dancing community. 22/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Summary 1 Introduction 2 Datasets and Benchmarks 3 Community detection in network 4 Evaluating partition quality 5 Objectives and Perspectives 23/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks

Objectives and Perspectives Guide to choose best methods base on expected quality indicators, graph characteristics and available resources Create generative model to summarize community characteristics Create a benchmark base on generative model Construct criteria for evaluating partition quality base on end user point of view Propose methods to improve detection quality Tools : - R for network analyzing, data analyzing, visualization - Gephi : Visualization 24/24 04/05/2016 Vinh Loc DAO Community detection in Complex Networks
