Colorization using Optimization Anat Levin Dani Lischinski Yair - PowerPoint PPT Presentation

Colorization using Optimization Anat Levin Dani Lischinski Yair Weiss

Colorization Colorization : a computer-assisted process of adding color to a monochrome image or ) movie. (Invented by Wilson Markle, 1970

Motivation • Colorizing black and white movies / TV shows • Recoloring color images for special effects

Color 101 • Typically represented by points in a three dimensional color space : • ( Red , Green , Blue ) • Another option: [Y, U, V ] • Y - intensity • U, V - chromatic channels • A simple transformation exists: [R, G, B] ⇔ [Y, U, V ]

Typical Colorization Process Images from: “Yet Another Colorization Tutorial ” http://www.worth1000.com/tutorial.asp?sid= 161018

Typical Colorization Process • Delineate region boundary Images from: “Yet Another Colorization Tutorial ” http://www.worth1000.com/tutorial.asp?sid= 161018

Typical Colorization Process • Delineate region boundary • Choose region color from palette Images from: “Yet Another Colorization Tutorial ” http://www.worth1000.com/tutorial.asp?sid= 161018

Typical Colorization Process • Delineate region boundary • Choose region color from palette Images from: “Yet Another Colorization Tutorial ” http://www.worth1000.com/tutorial.asp?sid= 161018

Typical Colorization Process • Delineate region boundary • Choose region color from palette Images from: “Yet Another Colorization Tutorial ” http://www.worth1000.com/tutorial.asp?sid= 161018

Process Limitations • Requires expertise and time consuming • Selecting detailed or fuzzy boundaries is difficult • Tracking regions is difficult (for video )

Our Approach Let the user focus on the creative goals, without having to worry about selection !

Our Approach Colors are propagated to every pixel in the image . Grayscale channel Chroma channels

Pixel Affinity Assumption: Neighboring pixels with similar intensities should have similar colors .

Pixel Affinity s w rs r Minimize :

Optimization • Find a function U that minimizes : (subject to the user’s color scribbles) • Boils down to solving a system of linear equations . • Do the same for V .

Colorizing Stills

Colorizing Stills Original Colorized

Colorizing Stills

Colorizing Video out of 92 frames 13
