City of O’Fallon O’Day Park Bid Summary and Budget Update December 14, 2017
Site Plan
Buildings and Structures Amphitheater Activity Center Family Shelter Comfort Station Maintenance Facility Activity Center Family Shelter Amphitheater Comfort Station Maintenance Facility
Playground Water Play 2-5 Climber 2-5 Climber Water Play Water Play Hillside Ball Hillside Ball Climbers Cloud 9 Swing Climbers Bridge Net Climber Cloud 9 Swing Land Bridge Slide Rope Parallel Climber VIP Swing Land Bridge Slide Bridge Net Climber VIP Swing Rope Parallel Climber
Base Bid Day Recap Project Advertised: 10/16/17 Bidder Total Base with Bonds Bids Received: 11/16/17 KCI $8,272,000 Total Number of Bidder: 10 Layne Co. $8,350,701 Demien $8,468,000 Wright $8,683,000 Brinkmann $8,712,554 Hankins $8,913,209 ICS $9,117,147 Kozeny Wagner $9,167,974 L. Keely $9,328,023 Lamb Co. $9,455,320
Summary of Bid Alternates
Alternate #2 - $55,000 Additional Parking at Activity Center Alternate: Furnish and install pavement, light poles, foundations, striping, wheel stops, soils, planting, and all incidentals as indicated on Sheets C-120 and C-130, L-610, L-611, L- 612, L-613 Base Bid: Grade site to finish grades indicated on plans and seed area. Install conduit to location of southern parking area light pole for future use as indicated on Sheets C-320 and C-330, and E-100. Plan View
Alternate #3 - $40,000 Teen Structure Alternate: Rendering Furnish and install pre-fabricated shelter, footings, concrete retaining wall, concrete pad, concrete walk extending from parking lot perimeter walk to shelter pad, electrical work, soils, plantings, and all incidentals including clearing and grubbing as indicated on Enlargement C/L-400 Concept Sketch Base Bid: No clearing or grading work included in base bid. Site grading for parking lot shall tie into existing grading at tree line. Provide conduit for future use per Sheet E-100, stub out conduit to pull box located outside of tree line within limits of disturbance for parking lot construction, no wiring or other electrical work included in base bid. Seed area disturbed for Plan View parking lot and conduit construction per landscape plans. Section
Alternate #4 – 33,000 Playground Overlook Structure Alternate: Furnish and install pre-fabricated shelter, footings, concrete retaining wall, concrete pad and pavement, electrical work, and all Section Rendering incidentals as indicated on Sheet L-402. Provide credit for plant material omitted from this area. Base Bid: Grade site to receive concrete pad for shelter, smoothly blend grading into adjacent landscape area. Install conduit from comfort station electrical panel to location of shelter for future use, stub out to pull box located in landscape area north of proposed pad area as indicated on Sheet E-100, no wiring included in base bid. Area shall receive plantings and irrigation per sheet L-154. Plan View
Alternate #5 - $23,000 Terminus Structure Alternate: Furnish and install pre-fabricated shelter, footings, concrete retaining wall, concrete Rendering Section pad and pavement, electrical work, and all incidentals as indicated on Sheet L-404. Provide credit for plant material omitted from this area. Base Bid: Grade site to receive concrete pad for shelter. Install conduit to location of shelter for future use, stub out to pull box located in seeded landscape area adjacent to proposed pad area as indicated on Sheet E-100, no wiring included in base bid. Area shall receive turf seed. Plan View
Alternate #6 - $132,000 Playground Water Feature Recirculation System Alternate: Provide engineered shop drawings with all necessary piping and equipment for a water harvesting and storage system for distribution of captured water for irrigation use. Furnish and install all materials, equipment, storage reservoirs, pumps, piping, controls, and incidentals. Water storage reservoir shall have a capacity of 5,400 cubic feet. Reservoir and equipment location to be located east of walk at terminus of water runnel. Base Bid: Provide equipment as indicated on drawings for flow thru potable water system. as indicated on Sheets F1.0 and F2.0.
Alternate #7 - $75,000 Single Picnic Table Structures Alternate: Furnish and install pre-fabricated shelter, footings, concrete pad, and all incidentals as indicated on Enlargement B/L-400. Total of 9 locations. Provide bid pricing on a per each basis. Provide deduct amount to per each price for acceptance of all 9 locations if applicable. Rendering Base Bid: Grade proposed picnic shelter locations as Plan View indicated on Sheet C-320, C-330, C-350, C-360. Areas shall receive seeded landscape per adjacent areas shown on L-160 series landscape drawings. Install soil per adjacent areas indicated on L-135.
Alternate #8 - $104,000 Additional Gabion Bench Walls Alternate: Furnish and install gabion bench terraced walls, additional grading to create terraced areas behind walls, and all incidentals. as Section indicated on Sheet L-112. Base Bid: No work in base bid, grade site as indicated on Sheet C-330. Plan View
Alternate #9 - $37,000 Operable Wall at Activity Center Alternate: The alternate bid shall contain the cost for material and labor to install an operable partition in the location indicated. This shall include all components to complete the assembly as illustrated and specified in the contract documents. Refer to Sheet A-112 Activity Center Plan View Reflected Ceiling Plans and specifications 102239 Folding Panel Partitions and 064216 Wood-Veneer Paneling Base Bid: The steel beam and decorative wood wrap shall be installed as illustrated in the contract documents. All necessary concealed blocking and subframing for the support of the operable partition shall be provided; excluding fasteners, track and all other components of the operable partition system. Refer to Sheet A-112 Activity Center Reflected Ceiling Plans
Alternate #10 - $202,000 Special Soil Prep at Native Seed Areas Alternate: Scrape off and dispose of top 3” of soil from all areas designated to receive native seed that are not being disturbed by grading activities. Spread 3” of compost over extent of area and incorporate to a depth of 6” by tilling. For all areas to receive native seed that are being disturbed by grading, do not install stockpiled topsoil, instead establish finish grade using subgrade material with 3” of compost tilled into the top 6”. Refer to Sheet L-615 for extent of area. Base Bid: Furnish and install soil per the contract documents. Plan View
Alternate #11 - $85,000 Gabion Entry Features Alternate: Furnish and install 3 additional gabion walls without signage panels, including footings, soils, plantings, irrigation, and all Concept Sketch incidentals. as indicated on Enlargement A/L-400. Base Bid: Furnish and install one front entry sign wall and signage panels as indicated on Enlargement A/L- 400. Plan View Sign Section
Alternate #12 - $39,000 Playground Entry Feature/Poles Alternate: Elevation Furnish and install entry feature elements, footings, and all incidentals. as indicated on Sheet L-402. Base Bid: Base bid as indicated on Sheet L-402. Plan View Concept Sketch
Alternate #13 - $5,000 Empty Conduit from Activity Center to Comfort Station for Future Fiber Alternate: Provide a 1” empty PVC conduit with pull wire Emptu from the Activity Center to the Comfort Station at the playground for future fiber optic. Conduit to share trenching with lighting conduits and other telecommunications conduits. Pathway to utilize telecommunications handholes already shown on site plan for pulling purposes and to include one additional handhole between the Comfort Station and telecommunications handhole near the C.R.E.C. sectionalizer. 3” RGS sleeves will be required where crossing creeks. 1” RGS conduit will be required where routing beneath roads and parking lots. Base Bid: Base bid as indicated on Sheet E-100. Plan View
Alternate #1 - $320,000 Salt Storage & Associated Hardscape Alternate: Furnish and install salt storage building, walls, concrete pad, and all incidentals as Elevations indicated on Sheet C-110. See architectural sheets A-311, A-321, A-331, A-332, A-340. Base Bid: Grade site to provide drainage around maintenance area, no change to limits of clearing and grading. as indicated on Sheet C-310. Provide gravel lot within area of building pad and pavement as shown on C-110. Plan View
Base Bid Day Recap with Alternates Bidder Total Base with Total Base Bid with Bonds and Bonds Recommended Alternates 2-13 KCI $8,272,000 $9,102,000 Layne Co. $8,350,701 $8,981,727 Demien $8,468,000 $9,401,500 Wright $8,683,000 $9,735,000 Brinkmann $8,712,554 $9,421,196 Hankins $8,913,209 $9,570,609 ICS $9,117,147 $10,004,147 Kozeny Wagner $9,167,974 $9,988,974 L. Keely $9,328,023 $10,460,223 Lamb Co. $9,455,320 $10,425,320
Contractor Evaluation • Interviewed three low bidding contractors • KCI, Layne Co, Demien • Four key factors considered for deciding “Lowest Responsible Bid” • 1. Experience with projects of this type/size • 2. Capacity of the contractor • 3. Backlog of the contractor • 4. Technical expertise and experience of the contractor • Determined that the “Lowest Responsible Bid” was received from KCI for $9,102,000
