CE419 Session 26: NoSQL Databases Web Programming The Relational - PowerPoint PPT Presentation

CE419 Session 26: NoSQL Databases Web Programming The Relational Model Relational database management systems require defined and clearly set schemas. Use SQL to query for data. Despite their strict nature of forming and handling


  1. CE419 Session 26: NoSQL Databases Web Programming

  2. The Relational Model • Relational database management systems require defined and clearly set schemas. • Use SQL to query for data. • Despite their strict nature of forming and handling data, relational databases can become extremely flexible and offer a lot, granted with a little bit of effort.

  3. NoSQL • A NoSQL database provides a mechanism for storage and retrieval of data that is modeled in means other than the tabular relations used in relational databases. • NoSQL database systems do not come with a model as used (or needed) with structured relational solutions. • NoSQL databases do not have a common way to query the data and each solution provides its own query system.

  4. SQL vs. NoSQL • Structure and type of data being kept • Querying • Scaling • Reliability • Support • Complex data keeping and querying needs

  5. NoSQL (cont'd) • Types • Key-Value stores • Graph • Column-oriented • Document • Multi-model

  6. Key-Value Stores • A key-value store, or key-value database, is a computer program designed for storing, retrieving, and managing associative arrays (dictionaries). • Redis: SHOWTIME. • Example usages?

  7. Graph Databases • A graph database is a database that uses graph structures for semantic queries with nodes, edges and properties to represent and store data. • Examples: • Neo4j • FlockDB

  8. Column-oriented Databases S120LondonSmith;S210Paris Jones;S330ParisBlake;S420 LondonClark;S530AthensAda ms SNO STATUS CITY SNAME --- ------ ---- ----- S1 20 London Smith S2 10 Paris Jones S3 30 Paris Blake S4 20 London Clark S5 30 Athens Adams S1S2S3S4S5;2010302030;Lon donParisParisLondonAthens ;SmithJonesBlakeClarkAdam s

  9. Column-oriented Databases (cont'd)

  10. Document Databases • Sometimes data is not easy to describe with relational databases. • Example: a product search engine. { { name: "Peugeot 206", name: "Seagate HDD", price: 36000000, price: 210000, hp: 105, capacity: "500GB", top_speed: 180, rpm: 7200, gearbox: "manual", ports: ["SATA", "USB"], color: "White" color: "Red" } }

  11. Document Databases (cont'd) • Documents may be addressed in the database via a unique key that represents that document. • Auto-increment integer? • UUID, ObjectId

  12. UUID • Universally Unique Identifier • A UUID is simply a 128-bit value. The meaning of each bit is defined by any of several variants. • Human readable display de305d54-75b4-431b-adb2-eb6b9e546014 • The intent of UUIDs is to enable distributed systems to uniquely identify information without significant central coordination.

  13. UUID Variants • Version 1 (MAC Address & date-time) • Single point in time & space • Version 4 (Random) • udid library in Python.

  14. MongoDB • MongoDB is the most popular NoSQL, document based, database system. • MongoDB can still hold various databases of different names within one installation package. • But inside databases are collections , not tables. • A collection may be considered a table except there are no aligned columns.

  15. What does it mean? • Consider a collection of users . • Now each of these entries or rows inside a collection is called a document . • They are basically JSON data blocks.

  16. Querying MongoDB • mongo command opens MongoDB shell. • It's a JavaScript shell!

  17. Querying MongoDB (cont'd) • db.collection.find() • db.collection.insert() • db.collection.update() • etc… • Let's see something in action!

  18. CAP Theorem • CAP theorem states that there are three basic requirements which exist in a special relation when designing applications for a distributed architecture: • Consistency, Availability, Partition Tolerance
