Investigation report for roughness changes after HOKKAIDO IBURI earthquake Japan, by using Smartphone roughness measurement by YAGI, Koichi BumpRecorder Co., Ltd. yagi@bumprecorder.com www.bumprecorder.com RPUG-PDRG 1st Joint Meeting Past


  1. Investigation report for roughness changes after HOKKAIDO IBURI earthquake Japan, by using Smartphone roughness measurement by YAGI, Koichi BumpRecorder Co., Ltd. yagi@bumprecorder.com www.bumprecorder.com RPUG-PDRG 1st Joint Meeting

  2. Past Earthquake in Japan Chuetu oki 2007 Chuetu 2004 Iburi 2018 & 2019 Kobe 1995 The great east Japan Kumamoto 2011 2016 RPUG-PDRG 1st Joint Meeting

  3. IBURI earthquake 2018 Sep. 100km 100km RPUG-PDRG 1st Joint Meeting

  4. Seismic intensity map Sapporo City Higashi Ward Sapporo Station New Chitose Airport Atsuma Mukawa Town Town RPUG-PDRG 1st Joint Meeting

  5. IBURI earthquake 2019 Feb. RPUG-PDRG 1st Joint Meeting

  6. Research distance up to 1,600km RPUG-PDRG 1st Joint Meeting

  7. Measurement Method and Evaluation Index RPUG-PDRG 1st Joint Meeting

  8. Smartphone type measurement Vibration data is collected under driving situations. RPUG-PDRG 1st Joint Meeting

  9. IRI Class 2 calculation process Measure acceleration (a) Suspension estimation (b) Inverted QC simulation (c) Calculate profile (d) RPUG-PDRG 1st Joint Meeting

  10. Using profile, compute indexes HEITANSEI sigma 平たん性 σ IRI - International Roughness Index JRI - Japanese Roughness Index Average of suspension expansion & Standard deviation of 3m compression under 80km/h driving profilometer measurement value. It situation. It includes longer wave indicate shorter wave length situation. length. (3) Calculate IRI 3m (2) QC simulation (1) Measured profile RPUG-PDRG 1st Joint Meeting

  11. Using profile, compute indexes IRI / JRI - Roughness Representative value on the segment. BBI - Boeing Bump Index Pointed information of the bump size and location. 10m straight edge is used, and deepest depth is defined Bump Height. 10m Straight edge Bump Height RPUG-PDRG 1st Joint Meeting

  12. Measurement Results around Atsuma Town and Mukawa Town RPUG-PDRG 1st Joint Meeting

  13. Measurement result after earthquake Is this affect from quake? Only current data, judgment is difficult RPUG-PDRG 1st Joint Meeting

  14. Result before and after 2018 This is not affect from quake. Comparison is effective to understand. After earthquake roughness situation draw by red line. Before earthquake draw by blue line. RPUG-PDRG 1st Joint Meeting

  15. Result before and after 2019 RPUG-PDRG 1st Joint Meeting

  16. JRI before earthquake RPUG-PDRG 1st Joint Meeting

  17. JRI after earthquake RPUG-PDRG 1st Joint Meeting

  18. BBI before earthquake RPUG-PDRG 1st Joint Meeting

  19. BBI after earthquake RPUG-PDRG 1st Joint Meeting

  20. Bump situation RPUG-PDRG 1st Joint Meeting

  21. Bump situation RPUG-PDRG 1st Joint Meeting

  22. Comparison IRI and JRI IRI JRI after IRI < JRI → shorter wave length damage before before < after → damage RPUG-PDRG 1st Joint Meeting

  23. Measurement Results around Sapporo City Higashi Ward RPUG-PDRG 1st Joint Meeting

  24. Measurement result after earthquake RPUG-PDRG 1st Joint Meeting

  25. Result before and after 2018 RPUG-PDRG 1st Joint Meeting

  26. Result before and after 2019 RPUG-PDRG 1st Joint Meeting

  27. Comparison IRI and JRI IRI JRI after IRI < JRI → shorter wave length damage before RPUG-PDRG 1st Joint Meeting

  28. Conclusion RPUG-PDRG 1st Joint Meeting

  29. Conclusion - By using Smartphone, roughness condition can be measured quick, easy and wide area, low cost. - Roughness situation is changed after earthquake. - Comparison before and after is clearly indicate road damage. - IRI, JRI, BBI can indicate road damage, and sometime their characteristic is not same. Important is - not only after but also before, collecting data. - not only IRI but also JRI, BBI also using. RPUG-PDRG 1st Joint Meeting

  30. Question(s)? YAGI, Koichi BumpRecorder Co., Ltd. yagi@bumprecorder.com http://www.bumprecorder.com RPUG-PDRG 1st Joint Meeting
